Quick Start
Product Registration
Registering your product ensures you receive the most appropriate service and product support
available. You can register your product during installation or at www.creative.com/register.
Please note that your warranty rights are not dependent on registration.
Creative Knowledge Base
Resolve and troubleshoot technical queries at Creative's 24-hour self-help Knowledge Base.
Go to www.creative.com, select your region and then select Support.
Customer Support Services & Warranty
For details on Customer Service Support and Warranty, refer to the booklet included with your
Creative Internet DECT Handset.
Keep this document for future reference.
Copyright © 2006 Creative Technology Ltd. All rights reserved. The Creative logo is a registered trademark of Creative
Technology Ltd. in the United States and/or other countries. Skype, SkypeOut, Skype VoiceMail and the Skype logo are
trademarks of Skype Technologies S.A.
PN 235-10283 Rev.A
Package Contents
Your Creative Internet DECT Handset package contains the following items:
(a) Cordless handset
(b) Handset charger
(c) Two rechargeable AAA batteries
Step 1: Insert Batteries and Charge your Handset
The supplied rechargeable batteries need to be fully charged before you use them. The
batteries are fully charged in approximately 14 hours.
To charge your handset's batteries, connect the handset charger's power adapter to a
wall outlet as shown.
Recharge your phone when an alert tone is heard and the battery low icon
appears.
WARNING: The cord(s) included with this product
may contain chemicals known to the
State of California to cause cancer and
birth defects or other reproductive harm.
Wash hands after handling.
1
2
3
Using incorrect batteries or charging non-rechargeable AAA batteries may result in
damage to your phone or even battery explosion.
Before proceeding to Step 2, make sure your Creative Internet DECT Phone is
already installed and working.
Step 2: Set up your Creative Internet DECT Handset
1.
Turn on your computer.
Make sure the Creative Internet DECT Phone icon
on the taskbar lights up in
green. The following icon colors indicate the status of your Internet DECT Phone.
Green - Logged on to Skype. Base station connected.
Red - Not logged on to Skype. Base station connected.
Grey - Base station* not connected.
and select Menu → System →
2.
On your handset, press the End Call/Power button
Register.
3.
On your base station, press and hold the Page button
(see below) for 4 seconds until
the In Use LED flashes.
4.
On your handset, enter your Creative Internet DECT Handset's PIN (Personal Identification
Number): 0000, and select Ok. A message confirming your registration appears.
Base Station
1.
Power LED
Lights up when driver and software have been installed
successfully, and the base station is connected to your computer.
2.
Page button
1
Press to locate your handset.
2
Your handset will not beep during a call or if it is powered off.
3
3.
In Use LED
Flashes when a connection is being established.
Lights up when a connection is established.
* The base station can be found with your Creative Internet DECT Phone.
Your Creative Internet DECT Handset
Cordless Handset
1. Call LED
Lights up during a call.
Flashes when a call is incoming.
1
2. Navigation control
3. End Call/Power button
4. Lock/Shift button
5. Call Records button
Press to display call durations, missed, dialed and
received calls.
6. Skype button
2
7. Intercom button
3
9
Press to speak with another handset (optional)
registered to the same base station.
Each base station supports up to 4 handsets.
10
8. Mute button
9. Call button
8
4
10.
2.5 mm (3/32")
7
5
Headphone jack
6
(Earphones available separately)
Your Handset Icons
13. Volume
1. Reception
14. Name
2. Call in progress
15. Number
3. Batteries are full
4. Batteries are 60% full
16. Contrast
5. Batteries are 30% full
17. Voicemail indicator
18. Home phone
6. Batteries are nearly empty.
Charge at earliest opportunity.
19. Mobile phone
7. Speakerphone
20. Gender
8. Alarm on
21. Address (Country, Province, City)
9. Ring tone muted
22. Base station registered
10. Handset buttons locked
23. Office phone
11. Internal melody
24. Birthday
25. Language
12. External melody
Using Your Creative Internet DECT Phone
To turn your handset on or off
Press and hold the End Call/Power button
.
To conserve power, your handset automatically turns off after 30 minutes if the base station is
disconnected from the computer.
Making and Receiving Calls
Do not use your Internet DECT Phone to make emergency calls.
To make a Skype-to-Skype call
1.
Make sure your computer is connected to the Internet.
2.
Double-click the Skype icon
on the desktop. For more information about adding Skype
contacts, refer to Skype's online Help.
3.
In the main menu, press the Skype button
OR the top or bottom edge of the Navigation
control
. Your Skype contact list appears on your handset's screen.
4.
Use the Navigation control
to select the contact you want, and press the Call button
.
To end a Skype call
Press the End Call/Power button
.
To make a Skype-to-ordinary-phone call
TM
To use this feature, make sure you have an active SkypeOut
account. For more information on
SkypeOut, visit skype.com.
1.
Press the Call button
. A dial tone is heard.
2.
Press <00> OR <+><country code><phone number>, and press the Call button
.
To receive a Skype call
When your handset rings, press the Call button
.
To answer a call automatically when you pick up your handset from the handset charger
Select Menu → Advanced → Auto Answer → On.
During a Skype call
To adjust volume
Press the top or bottom edge of the Navigation control
.
To activate speakerphone
Select Options → Speaker.
To answer a second incoming call
Press the Call button
.
To make a second outgoing call
Press the Call button
.
To make a Skype-to-ordinary-phone call, see "To make a Skype-to-ordinary-phone call".
●
●
To make a Skype-to-Skype phone call, press the Skype button
to select your Skype
contact and select Details → Dial.
To switch between calls
Press the Call button
.
Managing Your Internet DECT Phone
To add up to 100 phonebook entries to your handset
Select Names → Private → Add Entry.
1.
To share up to 20 phonebook entries between handsets, select Names →
Share → Add Entry.
2.
Use the handset buttons to enter a name next to Name
.
To change uppercase or lower case letters, press the Lock/Shift button
.
●
To enter special characters, press the Mute button
OR 0+ button
.
●
To enter a space, press and release the 1 button
.
●
3.
Press the bottom edge of the Navigation control to select Number
.
4.
Enter a phone number OR Speed-Dial number (set in Skype).
5.
Press the bottom edge of the Navigation control
to select Melody
.
6.
Press the left and right edges of the Navigation control
to associate an incoming call
melody with the entry and select Save.
To view and call your private phonebook contacts
To make a Skype-to-ordinary-phone call, make sure you have an active SkypeOut account.
In the main menu, select Names → Private → View.
1.
2.
Select the contact you want and press the Call button
.
To redial numbers
To redial the last dialed number, press the Call button
and select Redial.
1.
In the main menu, press the right edge of the Navigation control
.
2.
Select the contact you want and press the Call button
.
To change your Skype online status from your handset
OR select Menu → Skype.
1.
Press the left edge of the Navigation control
Select User Status → online status that you want.
2.
To assign quick dial numbers
Select Names → Private → Quick Dial.
To assign a number to all your handset buttons (except Cancel button
and End Call button
)
for one touch dialing
Select Menu → Advanced → Touch & Dial.
To use your handset as an alarm clock, timer or stop watch
Select Menu → Advanced → option that you want.
To listen to your Skype voicemail
To use this feature, make sure you have a Skype Voicemail
TM
subscription.
OR select Menu → Skype.
1.
Press the left edge of the Navigation control
Select Voicemail → View → message that you want → Play.
2.
Personalizing Your Internet DECT Phone
To configure your handset's language, display or clock settings
Select Menu → Display → option that you want.
To change your handset and key tones
Select Menu → Sounds → option that you want.
To reset your handset to its original settings
Select Menu → System → Reset.
Using Multiple Handsets
To transfer a call or enter a three-way conference call during an external call
1.
Press the Intercom button
.
2.
Select the handset you want and select Ok.
●
To transfer a call
OR select Options →
When the other party picks up the phone, press the End Call button
Transfer → Ok.
To enter a three-way conference call
●
When the other party picks up the phone, select Options → Conference → Ok.
To copy private or shared phonebook entries
Select Names → Private OR Shared → Ok.
1.
Select View → entry that you want.
2.
Select Options → Details → Options → To Private OR To Shared → Save.
3.
Frequently Asked Questions
Why does my Creative Internet DECT Phone not receive incoming calls?
●
Creative Internet DECT Phone is not connected to the computer, or your computer is in standby mode.
Make sure the drivers are running. Select Start → Programs → Creative → Creative Internet
●
DECT Phone → Creative Internet DECT Phone.
"Unavailable" appears on my handset screen OR I do not hear a dial tone when making a
Skype-to-ordinary-phone call. What do I do?
●
Make sure you are logged-on to a Skype account and the base station is connected to your computer.
My device is prompting me to enter a PIN (Personal Identification Number). What do I do?
Enter your Creative Internet DECT Phone's PIN: 0000. To change your PIN, select Menu →
●
System → Change PIN.
What is the optimal operating distance between my handset and base station?
When using your Creative Internet DECT Phone, make sure the distance between your handset and
●
base station remains within 300 meters (984 feet). If the Reception icon
flashes on the handset
screen and you hear an alert tone, your handset is out of range. Move your handset closer to your
base station.
Your Creative Internet DECT Phone works best when there are no obstructions (for example, walls
or other electronic devices) between your handset and base station. If you use your Internet DECT
Phone near certain electronic devices, you may hear a humming noise. This is normal and
considered acceptable for radio devices.
Safety Information
Refer to the following information to use your product safely, and to reduce the chance of
electric shock, short-circuiting, damage, fire or other hazards.
Improper handling may void the warranty for your product.
For more information, read the warranty available with your product.
Do not dismantle or attempt to repair your product, batteries, handset charger or power adapter.
●
Refer all servicing to Creative or authorized repair agents.
Do not expose your product or batteries to temperatures outside the range of 0°C to 50°C
●
(32°F to 122°F).
Do not pierce, crush or set fire to your product or batteries.
●
●
Keep your product or batteries away from strong magnetic objects.
Do not subject your product to excessive force or impact.
●
●
Do not expose your product or batteries to water or moisture.
The batteries must be recycled or disposed of properly. Contact local agencies for recycling
●
and disposal information.
Do not allow metal objects to touch the terminals of your batteries or handset charger.
●
Do not attempt to charge the batteries by heating them.
●
If there is leakage, an offensive odor, discoloration or deformation during charging or use,
●
remove the batteries and do not use them again. Clean your hands well before touching food
or sensitive areas, for example, your eyes.
Make sure your power supply has the correct voltage as indicated on the power adapter.
●
●
Do not overload wall outlets and extension cords.
Avoid using your product during an electrical storm.
●
●
Do not use this product near sensitive medical equipment or if you wear a pacemaker.
RF Radiation Exposure
This phone has been tested and meets the FCC RF exposure guidelines when used with the
supplied belt clip. Usage of other accessories may not comply with FCC RF exposure guidelines.
This product must not be operated together with other antennas or transmitters.
Advertisement
