Note: The method of manual override can either be selected to operate from the valet switch or operate as custom
code. Be certain to place a check mark indicating the method used in the box located on the last page of the
owner's manual.
Note: When both Passive Arming and Voltage Sensing are selected, you must hardwire the driver's door pin
switch in order to begin the passive arming sequence.
RF Programmable Features :
Feature Selection
1st Door L/UL
2nd Accy Lock
3rd Accy. UL
4th Headlights
5th Passive Locks
6th Passive/Active Arm
7th Voltage Sense
8th Siren/Horn
9th Horn Chirp
10th Override Method
11th Two Step Unlock
12th Chirp Delete From Tx On
To program these selectable features;
Action
Turn ignition on
Press and release the valet switch 3 times
Within 3 seconds, turn ignition Off
First
Then On
Press transmitter Lock button to change
Press transmitter Lock button to change
or
Second Press and release the valet switch
Press transmitter Lock button to change
or
Third
Press and release the valet switch
Press transmitter Lock button to change
Press transmitter Lock button to change
or
Fourth
Press and release the valet switch
Press transmitter Lock button to change
Press transmitter Lock button to change
Press transmitter Lock button to change
or
1 Chirp
2 Chirps
1 Sec.
3.5 Sec.
Auto Lock On
Auto Lock Off
Auto UL Dr
Auto UL All
On Arm
On Disarm
Passive
Active
Passive Arm
Active Arm
Voltage Sense Hardwire
Siren/Horn
Siren Only
10mS
16mS
Custom Code
Valet
On
Off
Off
Model APS-510a
Installation Manual
3 Chirps
4 Chirps
1 Sec L, Dbl. U/L
Auto UL Off
On Both
Off
Horn Only
30mS
System Response
No response
1 Chirp - LED 1 flash
Short chirp, then long chirp
1 chirp = 1 second door locks
2 chirps = 3.5 second door locks
3 chirps = 1 sec. lock, dbl 1 sec. unlock
2 chirps = auto locks off
1 chirp = auto locks on
3 chirps = auto unlock off
1 chirp = auto unlock drivers door only
2 chirps = auto unlock all doors
3 chirps = headlight output when arming and disarming
4 chirps = headlight output off
1 chirp = headlight output when arming
2 chirps = headlight output when disarming
Default
1 Sec.
Auto Lock Off
Auto UL Off
Both
Active
Active Arm
Hardwire
Siren/Horn
16mS
Valet
Off
Off
128-6520
1 of 8
Advertisement
Related Manuals for Prestige 1286520
Summary of Contents for Prestige 1286520
- Page 1 Model APS-510a Installation Manual Note: The method of manual override can either be selected to operate from the valet switch or operate as custom code. Be certain to place a check mark indicating the method used in the box located on the last page of the owner's manual.
- Page 2 Fifth Press and release the valet switch 2 chirps = active locks Press transmitter Lock button to change 1 chirp = passive locks Sixth Press and release the valet switch 2 chirps = active arming Press transmitter Lock button to change 1 chirp = passive arming Seventh Press and release the valet switch 2 chirps = hardwire...
-
Page 3: Wiring The System
Do not mount the control module in the engine compartment, as it is not waterproof. You should also avoid mounting the unit directly onto factory installed electronic components. These components may cause RF interference, which can result in poor transmitter range or intermittent operation. Siren: Select a mounting location in the engine compartment that is well protected from access below the vehicle. - Page 4 Note: This is a normally closed starter cut arrangement, and when power is removed from the security system, the starter disable feature will not operate, allowing the vehicle to start. Audiovox does not recommend using the Orange wire to interrupt anything but the starting circuit of the vehicle.
- Page 5 Note: This is a normally opened starter cut arrangement, and when power is removed from the security system, the starter disable feature will remain operational, and the vehicle will not start. Audiovox does not recommend using the Orange w/ White trace wire to interrupt anything but the starting circuit of the vehicle.
- Page 6 after a first unlock command was issued. This is used for second step unlock or all doors unlock in a two step circuit. In this arrangement, Red, or Green is used to control the drivers door unlock relay, and the Red/ Black will be used to control unlock of all other doors.
-
Page 7: Completing The Installation
These applications require the use of additional components which may include relays, fixed resistors, or for convenience, the AS 9159 Door Lock Interface. Refer to the AUDIOVOX Door Lock Wiring Supplement and or the Audiovox fax back service for information on your particular vehicle for properly connecting to these types of circuits. - Page 8 © 2003 Audiovox Electronic Corporation, 150 Marcus Blvd., Hauppauge, N.Y. 11788 128-6520 128-6520 8 of 8...
