- Page 1 SMCBR24Q User Manual...
-
Page 2: Table Of Contents
SMCBR24Q Utility User Manual Table of Contents Login..............................3 Topology ............................. 3 Connection Status ........................ 3 Bandwidth Control ........................ 5 PassPort Configuration......................5 Internet Passport..........................6 Router Information........................ 6 WAN Configuration....................... 7 Family Member’s Internet Passport..................10 On Line Scheduler ........................10 Hit Rate ............................11 Usage ............................ -
Page 3: Login
SMCBR24Q Utility User Manual Utility – Internet Passport The SMCBR24Q provides the Utility – Internet Passport for home users. The Internet Passport provides Parents the Family Member’s passport for doing parental control, and it includes On-Line Scheduler, Web Site Hit Rate, Real Time Application Usage and Performance Optimization. - Page 4 SMCBR24Q Utility User Manual to view and edit the WAN configuration. As you change the WAN port, the topology will change accordingly. If dual WANs are used, you can see who go through WAN 1 and who go through WAN 2 from the topology. The default is WAN 1.
-
Page 5: Bandwidth Control
SMCBR24Q Utility User Manual Bandwidth Control You can control the left slider for guaranteeing bandwidth, and right slider for limiting bandwidth for individual family member, and percentage and bandwidth (kbps) of min and max will display accordingly. The default will be no guarantee and limit bandwidth, so the default min rate is 0% and max rate is 100%. -
Page 6: Internet Passport
SMCBR24Q Utility User Manual Old Password: Enter the old password. The default Password is ‘admin’ when you first log in the Utility. (Note: The password cannot be recovered if it is lost or forgotten. If the password is lost or forgotten, you have to reset the Router to its factory default state.) New Password: Enter a new password for the Utility. -
Page 7: Wan Configuration
SMCBR24Q Utility User Manual WAN Configuration ISP Bandwidth: Fill in the upstream and downstream bandwidth provided by ISP. The default is 512Kbit/sec. Internet Connection Type: There are four types of Internet connection. Obtain and IP automatically, Static IP, PPPoE and PPTP. Page 7... - Page 8 SMCBR24Q Utility User Manual 1. Obtain an IP automatically: If your ISP is running a DHCP server, select Obtain an IP automatically option. Your ISP will assign these values, includes DNS Server automatically. Or users can check the box of Use the Following DNS Server Addresses, and enter the specific DNS Server IP.
- Page 9 SMCBR24Q Utility User Manual Enter your Username and Password. If you select Connect on Demand option, the PPPoE connection will be disconnected if it has been idle for a period longer than the Max Idle Time setting. If you select Keep Alive option, the Router will keep the connection alive by sending out a few data packets at Redial Period, so your Internet service thinks that the connection is still alive.
-
Page 10: Family Member's Internet Passport
SMCBR24Q Utility User Manual Family Member’s Internet Passport Click the selected Family Member’s PC and the Internet Passport will display. You can click the arrow button to close the Internet Passport screen. The SMCBR24Q provides four parental control tools, On Line Scheduler, Hit Rate, Usage and Performance Optimization. -
Page 11: Hit Rate
SMCBR24Q Utility User Manual Click the Save Changes button to save the settings, click the Cancel button to undo your changes or click the Refresh button to update the data. For more information on this tab, you can click the Help button. Hit Rate The Hit Rate tab shows the top 10 websites by frequency the selected family member has visited by the end of today and their related information, Today’s Ranking and Web site. - Page 12 SMCBR24Q Utility User Manual Add to Block List: Click the lock icon to block the web site, and it will turn to locked and red. Click again to unblock the site. The blue open lock icon means “unblock” and the red locked lock means “block”. The default is “unblock”.
- Page 13 SMCBR24Q Utility User Manual Number: This show how many websites are blocked. Web site: Click the website address and Internet Explorer will open at that address to find out the site contents. Unblock: You can cancel your settings by clicking the lock icon, and the website will turn to unblock. View One Week History: Click the button and you will see the dates of the last six days.
- Page 14 SMCBR24Q Utility User Manual Date: The date you’re viewing is displayed. Ranking: The rankings of the top 10 websites of the selected date are in a descending order. Web site: Click the website address and Internet Explorer will open at that address to find out the site contents. Add to Block List: Click the lock icon to block the site.
-
Page 15: Usage
SMCBR24Q Utility User Manual Usage This Usage tab shows the current usage of the top 20 applications. You can know what applications consume most bandwidth currently. Ranking: The rankings of the top 20 applications by bandwidth consumption are in a descending order. Application: The field shows the top 20 application names. - Page 16 SMCBR24Q Utility User Manual open lock icon means “unblock” and the red locked lock means “block”. The default is “unblock”. View Application Block List: Click the button to see the blocked applications. Move the scroll button down the bar to see all applications. Number: This show how many applications are blocked.
- Page 17 SMCBR24Q Utility User Manual View One week History: Click the button and you will see the dates of the last six days. Put your mouse over the selected date and click to view the usages of the top 20 applications for that date and their related information.
- Page 18 SMCBR24Q Utility User Manual Click the Save Changes button to save the settings, click the Cancel button to undo your changes or click the Refresh button to update the data. For more information on this tab, you can click the Help button. Page 18...
-
Page 19: Performance Optimization
SMCBR24Q Utility User Manual Performance Optimization The screen displays the built-in 19 suggested applications where you can optimize their performance and view their Application names and the usage Quality. Before enable the bandwidth suggestion, please make sure you have allocated the min bandwidth for this family member. Suggestion: You can see the total number of the suggested applications Application: The field shows the 19 suggested application names. - Page 20 SMCBR24Q Utility User Manual Enable: To enable Performance Optimization click the dot once. Click again to undo your setting. If enabled, the dot is blue. If disabled, the dot is white. The default is “disable”. If you set up new rule of Performance Optimization via UI, the new rule will be also displayed here. Performance Optimization Cross-Reference Table The table below shows the built-in bandwidth information for each application.
- Page 21 SMCBR24Q Utility User Manual or click the Refresh button to update the data. For more information on this tab, you can click the Help button. Page 21...
- Page 22 Fax (65) 238 6466 Korea: 82-2-553-0860 Fax 82-2-553-7202 Japan: 81-45-224-2332 Fax 81-45-224-2331 Australia: 61-2-8875-7887 Fax 61-2-8875-7777 India: 91-22-8204437 Fax 91-22-8204443 If you are looking for further contact information, please visit www.smc.com. Model Number: SMCBR24Q 38 Tesla Irvine, CA 92618 Phone: (949) 679-8000...
