Data Sheet
Tiger Media Converters
SMC-12MCC
SMC-FLST, SMC-FXSC, SMC-FXST,
SMC-FSSC, SMC-GSSC, SMC-GLSC
SMC´s line of media converters offers a flexible and affordable solution
for quick and efficient media conversion. Compatible with IEEE standards,
SMC´s 12-slot, Media Converter Chassis gives the user a dedicated and secure
environment for multiple media conversion applications. SMC provides a
variety of media converters that can be incorporated into the 19" rack-mount
Media Converter Chassis or may be used individually as single, stand-alone
media converters. Each media converter is sold separately and comes with an
external power adapter for stand-alone use.
Flexibility - The Chassis supports up to 12 individual media converters
covering 10BASE-T to 10BASE-FL, 10BASE-T/100BASE-TX to 100BASE-FX
and Gigabit 1000BASE-T to Gigabit SX / LX, conversion. In addition, both
multimode and single-mode options are supported.
Reliability - The Chassis also supports two high quality hot swappable power
supplies. Either Power unit can be removed without disturbing the Chassis's
operation – offering total efficiency, maximum redundancy and minimum
down time. Each module is supplied from a common shared power bus –
but as an added precaution, each is individually protected in the event of a
problem on the bus or from the power supply. Each Converter can also be
changed without power down.
Functionality - The Chassis was carefully designed to offer a lifetime of
operation. Incorporated into the Chassis are three long life cooling fans to
ensure a cool operating environment. Each fan is monitored and connected
Features and Benefi ts
High Performance & Functionality
•
High quality 19" Rack-mountable Chassis
•
Supports up to 12 media converters
•
Supports two load sharing, hot swappable power supplies
•
Three high volume cooling fans ensure perfect operating environment
•
LED Status panel with fan and bay power status LEDs
•
Supports bay power isolation - ensures each bay is electrically isolated from the next
•
Supports 10/100/1000BASE, Copper, Fibre, Single/Multi-mode, ST, SC, connectors
•
Avoids network downtime and protects your converter investments
•
Ideal for mission-critical networks such as Large Offi ce Complex, Banks, Military etc.
Product Model No Description
Tiger Media
SMC-12MCC
Converter Chassis
Tiger Media Converters
SMC-FLST*
SMC-FSSC*
SMC-FXSC*
SMC-FXST*
SMC-GSSC*
SMC-GLSC*
SMC-MCCRPU
*all converter come with 1 x AC adapter, 4 x self-adhesive feet, manual
1 x Media Converter Chassis incl. power supply, 19" rack
1 mounting kit, 12 blank panels (fitted), 12 converter
mounting panels, 4 self-adhesive feet, manual
10BASE-T to 10BASE-FL media converter (ST-type; multi-mode)
10BASE-T/100BASE-TX to 100BASE-FX converter
(SC-type; single-mode)
10BASE-T/100BASE-TX to 100BASE-FX converter
(SC-type; multi-mode)
10BASE-T/100BASE-TX to 100BASE-FX converter
(ST-type; multi-mode)
1000BASE-T to 1000BASE-SX converter (SC-type; multi-mode)
1000BASE-T to 1000BASE-LX converter (SC-type; single-mode)
75W modular power supply pack for SMC-12MCC
