CD Stereo System
NSX-TR77
U
OWNER'S RECORD
Record the model number and serial number of your set (found at the
rear of your set) below. Refer to them when contacting your Aiwa dealer.
Model No. _____________________________
Serial No. _____________________________
For assistance and information
(United States and Puerto Rico)
OPERATING INSTRUCTIONS
MANUAL DE INSTRUCCIONES
MODE D'EMPLOI
En
(English)
E
(Español)
F
(Français)
8C-NFT-903-01
020520AKH-U-BF
Advertisement
Table of Contents
Related Manuals for Aiwa NSX-TR77
Summary of Contents for Aiwa NSX-TR77
- Page 1 CD Stereo System NSX-TR77 OWNER'S RECORD Record the model number and serial number of your set (found at the rear of your set) below. Refer to them when contacting your Aiwa dealer. Model No. _____________________________ Serial No. _____________________________ For assistance and information...
-
Page 2: Important Safety Instructions
WARNING To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture. Explanation of Graphical Symbols: The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage”... -
Page 3: Table Of Contents
CD OPERATIONS ... 10 RADIO OPERATIONS ... 12 TAPE OPERATIONS ... 14 SOUND ADJUSTMENTS ... 17 TIMER OPERATIONS ... 18 REFERENCE ... 20 System and accessories NSX-TR77 CX-NTR77 CD stereo cassette receiver SX-NTR77 Front speakers Remote control FM antenna AM antenna... -
Page 4: Preparations
PREPARATIONS Connection Plug in the AC power cord to the AC power outlet after all other connections are made. 1 Connect the front speakers. Connect the right front speaker to the SPEAKERS R terminals and place it on the right side of the unit. Connect the left to the SPEAKERS L terminals and place it on the left side.The speaker cords with the white stripes go to the 0 terminals. -
Page 5: Parts And Controls
PARTS AND CONTROLS Main unit: rear 1 AM LOOP, FM 75 Ω terminals Plug in the supplied AM and FM antennas here. 2 VIDEO/AUX jacks Accepts analog sound signals from external equipment. Connect using an optional connecting cable with RCA phono plugs (red plug to R jack, white plug to L jack). - Page 6 Main unit: front 1 TAPE/DECK 1/2 Selects Tape function, and deck 1 or 2. TUNER/BAND Selects Radio function and the radio band. VIDEO/AUX Selects the function of external equipment connected to VIDEO/AUX jacks. Selects CD function. 2 POWER 6STANDBY/ON Switches the unit on and off (standby). 3 SYNC DUB Starts dubbing a whole tape.
- Page 7 Remote control Buttons with the same or similar names with the main unit basically have the same function. 1 POWER 2 0-10, +10 CD: selects a CD track of the specified number. Radio: tunes in to the station with the specified preset number.
-
Page 8: Adjustments Before Operations
ADJUSTMENTS BEFORE OPERATIONS Power Turning the unit on Press POWER 6STANDBY/ON (POWER on the remote control). Pressing TAPE, TUNER, VIDEO/AUX or CD also turns the unit on (Direct Play Function.) When a disc or tape is inserted, the playback will start automatically. Turning the unit off Press POWER 6STANDBY/ON again. - Page 9 ECO mode Reduces power consumption with the following operations, etc. - The unit blacks out when the unit is turned off. Only the red indicator lights up. (Only when the clock is set.) - If dimmer mode is set to on, the unit illumination brightens (for 10 seconds) only when you operate the unit.
-
Page 10: Cd Operations
CD OPERATIONS This unit plays back finalized CD-R/RW discs as well as audio CDs. Playback 1 Press CD and load disc(s). Press zOPEN/CLOSE to open the disc compartment and place one or two disc(s) with the labelled side up. To place three discs, press DISC CHANGE so that the trays rotate, then place the third one. -
Page 11: Programed Playback
Programed playback Plays back up to 30 selected tracks in programed order. 1 Press SHIFT+PROGRAM on the remote control during stop. "PRGM" lights up on the display. 2 Press DISC DIRECT PLAY 1-3 to select a disc. Go to the next step when the tray stops rotating. 3 Press the numbered buttons on the remote control to program a track. -
Page 12: Radio Operations
RADIO OPERATIONS Manual tuning 1 Press TUNER/BAND (BAND on the remote control) repeatedly to select a band (FM or AM.) 2 Press f or g to tune in to a station. "TUNE" is displayed when a station is tuned in. "1"... - Page 13 Adjustments Antennas Keep antennas away from metallic objects, electrical equipment and cords. FM antenna: Extend fully and position for the best reception. If receiving condition is poor, connect optional outdoor antenna to FM 75 Ω terminal. Be sure to connect the shield braid of the antenna to the 2 terminal.
-
Page 14: Tape Operations
TAPE OPERATIONS Playback Use only type I (normal) tapes. 1 Press TAPE/DECK 1/2 (DECK 1/2 on the remote control) and insert the tape in either deck. Press zPUSH EJECT/CLOSE on either side (DECK 1 and DECK 2) to open the outer cassette holder and insert the tape in the deck. -
Page 15: Basic Recording
Basic recording Use only type I (normal) tapes. DECK 2 is the recording deck. Only one side of the tape can be recorded at a time. 1 Insert the recording tape in DECK 2. Press zPUSH EJECT/CLOSE to open the outer cassette holder, and insert with the exposed side down and the side to be recorded on facing out from the unit. - Page 16 8 Turn over the tape and press wREC/REC MUTE to start recording on side B. •AI Edit Recording cannot be used with discs with more than 30 tracks. "TR OVER" is displayed. •Recording cannot start from a point halfway in the tape. Programed Edit Recording As you program the CD tracks to record, Programed Edit Recording displays the remaining recording time for each side...
-
Page 17: Sound Adjustments
SOUND ADJUSTMENTS Graphic equalizer Selects a sound equalization curve to match the music type. Press HEAVY, VOCAL, SALSA, TECHNO, HIP HOP or MANUAL. On the remote control, press GEQ and then press PRESET M or N repeatedly within 4 seconds. The selected equalization curve is displayed. -
Page 18: Timer Operations
TIMER OPERATIONS Sleep timer Turns off the unit automatically after a specified time. 1 Press SHIFT+SLEEP on the remote control. "SLP" appears on the display. 2 Press f or g repeatedly to set the sleep timer duration. With each press, the timer duration changes in 5-minute steps between 5 to 240 minutes. - Page 19 To display the timer setting Press SHIFT+TIMER on the remote control. The timer-on time, the source and the timer-activated duration are displayed for 6 seconds. Tip: Timer setting can be displayed even while the unit is turned off, and at that time if you press ENTER or a within 6 seconds after SHIFT+TIMER is pressed, you can enter the timer setting mode and change the setting.
-
Page 20: Reference
REFERENCE Care and maintenance Occasional care and maintenance of the unit and the software are needed to optimize the performance of your unit. To clean the cabinet Use a soft and dry cloth. If the unit surfaces are extremely dirty, use a soft cloth lightly moistened with mild detergent solution. -
Page 21: Specifications
Specifications MAIN UNIT CX-NTR77 TUNER FM tuning range 87.5 MHz to 108 MHz FM usable sensitivity (IHF) 13.2 dBf FM antenna terminal 75 ohms (unbalanced) AM tuning range 530 kHz to 1710 kHz (10 kHz step) 531 kHz to 1602 kHz (9 kHz step) AM usable sensitivity 350 µV/m AM antenna... - Page 22 NOTE This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
