INSTRUCTIONS FOR USE
WARNING
Before departure, always carry on a pre-
liminary check of the vehicle to make sure
that it works safely and correctly, see the
following table (TABLE OF PRELIMINARY
CHECKS). The non-performance of such
operations can cause serious injuries to
people or damages to the vehicle.
Do not hesitate to contact your aprilia
Official Dealer if you do not understand
the working of the controls or if you sus-
pect or discover some irregularities.
It does not take long to carry on a check-
ing operation and the resulting safety is
considerable.
TABLE OF PRELIMINARY CHECKS
Component
Check the working, the idle stroke of the control levers,
Front and rear disk
the fluid level and make sure that there are no leaks. Check
brakes
the wear of the pads. If necessary, carry on the topping
up of the brake reservoir.
Brake levers
Make sure that they work smoothly.
If necessary, lubricate the articulations.
Make sure that it works smoothly and that it can be
Accelerator
opened and closed completely, in all steering positions.
Adjust and/or lubricate it, if necessary.
Engine oil
If necessary, check it and/or top up the oil reservoir.
Check the tyre surface, the inflation pressure, wear and
Wheels/tyres
any damage.
Make sure that it rotates smoothly, without any clear-
Steering
ance or slackening.
Make sure that they work smoothly and that the spring
Side stand and cen-
tension brings them back to their normal position. If nec-
tral stand
essary, lubricate joints and articulations.
Fastening elements Make sure that the fastening elements are not loose. If
necessary, adjust or tighten them.
Check the fuel level and top up, if necessary. Make sure that
Fuel tank
there are no leaks or occlusions in the circuit. Make sure
that the fuel filler cap is correctly tightened.
The coolant level in the expansion tank must be included
Coolant
between the MIN and MAX marks.
Engine stop switch
Check the correct working.
(
-
)
Lights, warning lights,
Make sure that the acoustic and visual devices work
injection warning light,
correctly. Replace the bulbs or carry out the neces-
sary repairs in case of failure.
horn and electric devices
Injection pump
Make sure it works correctly.
Check
use and maintenance Atlantic 500
Page
26, 48
–
55
26
30
51
49
–
24, 65
28, 29
19
57 - 64
–
33
