Dimension
GS-1116 and GS-1124
Gigabit Switches
User's Guide
March 2004
Version 0.1

Advertisement

Table of Contents
loading

Summary of Contents for ZyXEL Communications Dimension GS-1116

  • Page 1 Dimension GS-1116 and GS-1124 Gigabit Switches User’s Guide March 2004 Version 0.1...
  • Page 2 Published by ZyXEL Communications Corporation. All rights reserved. Disclaimer ZyXEL does not assume any liability arising out of the application or use of any products, or software described herein. Neither does it convey any license under its patent rights nor the patents rights of others.
  • Page 3: Zyxel Limited Warranty

    ZyXEL shall in no event be held liable for indirect or consequential damages of any kind of character to the purchaser.
  • Page 4: Interference Statements And Warnings

    Taiwanese BCIQ A Warning Certifications 1. Go to www.zyxel.com 2. Select your product from the drop-down list box on the ZyXEL home page to go to that product's page. Select the certification you wish to view from this page. Interference Statements and Warnings...
  • Page 5: Customer Support

    Dimension GS-1116/GS-1124 Gigabit Switch Customer Support If you have questions about your ZyXEL product or desire assistance, contact ZyXEL Communications Corporation offices worldwide, in one of the following ways: Contacting Customer Support When you contact your customer support representative, have the following information ready: •...
  • Page 6 WEB SITE REGULAR MAIL SALES E-MAIL FTP SITE LOCATION NORWAY support@zyxel.no +47 22 80 61 80 www.zyxel.no ZyXEL Communications A/S Nils Hansens vei 13 sales@zyxel.no +47 22 80 61 81 0667 Oslo Norway SWEDEN support@zyxel.se +46 31 744 7700 www.zyxel.se ZyXEL Communications A/S Sjöporten 4, 41764 Göteborg...
  • Page 7: Table Of Contents

    Dimension GS-1116/GS-1124 Gigabit Switch Table of Contents Chapter 1 Getting to Know the Switch ....................1-1 Introduction...........................1-1 Features..........................1-2 Package Contents........................1-3 Gigabit Switch Network Applications ..................1-3 Chapter 2 Hardware Description and Installation.................2-1 Desktop Installation ......................2-1 Rack-mounted Installation....................2-2 Rear Panel ..........................2-3 Front Panel..........................2-3 Chapter 3 Troubleshooting ........................3-1 Introduction...........................3-1 Improper Network Cabling and Topology................3-2...
  • Page 9 Dimension GS-1116/GS-1124 Gigabit Switch List of Figures Figure 1-1 GS-1116 ..........................1-1 Figure 1-2 GS-1124 ..........................1-1 Figure 1-3 Gigabit Switch for Server Farm ..................1-4 Figure 1-4 Gigabit Switch for Super User Work Groups ..............1-5 Figure 2-1 Attaching Rubber Feet ......................2-1 Figure 2-2 Attaching Mounting Brackets and Screws................2-2 Figure 2-3 Switch Mounting to an EIA Standard 19-inch Rack............2-2 Figure 2-4 GS-1116/GS-1124 Rear Panel ....................2-3 Figure 2-5 GS-1116 Front Panel......................2-3...
  • Page 10: About Gigabit Ethernet

    The Dimension GS-1116 or GS-1124 Gigabit Switch may be referred to as the switch in this manual except where we refer to a specific switch. Related Documentation ZyXEL Web Site The ZyXEL download library at www.zyxel.com contains additional support documentation and an online glossary of networking terms.
  • Page 11: Chapter 1 Getting To Know The Switch

    Dimension GS-1116/GS-1124 Gigabit Switch Chapter 1 Getting to Know the Switch This chapter describes the key features, benefits and applications of the switch. Introduction The switch is designed for the campus or building environment as a high bandwidth backbone. The GS-1116 has 16 100/1000 Mbps RJ-45 ports.
  • Page 12: Features

    Dimension GS-1116/GS-1124 Gigabit Switch Both ports 15 and 16 in the GS-1116 (or 23 and 24 in the GS-1124) support 3.3V Mini GBIC. The GBIC port auto detects between Giga copper and Mini GBIC. The Mini GBIC module is optional. When the Mini GBIC module is not installed, these act as Giga copper connections.
  • Page 13: Package Contents

    Dimension GS-1116/GS-1124 Gigabit Switch When the Mini GBIC module is installed, the Mini GBIC (Giga fiber) port has higher priority than Giga copper port. When the Mini GBIC port is connected, the Giga copper port is disabled. Package Contents Compare the contents of your GS-1116/GS-1124 Gigabit Switch package with the checklist below. If any item is missing or damaged, please contact your local dealer.
  • Page 14: Figure 1-3 Gigabit Switch For Server Farm

    Dimension GS-1116/GS-1124 Gigabit Switch Figure 1-3 Gigabit Switch for Server Farm 1.4.2 Gigabit Switch for “Super User” Work Groups You can use the GS-1116 or the GS-1124 to connect servers, switches, workstations and computers (the Gigabit 1000Base-T NIC must be installed onto the computer) to each other. The following figure depicts a typical backbone application of the switch in an enterprise environment.
  • Page 15: Figure 1-4 Gigabit Switch For Super User Work Groups

    Dimension GS-1116/GS-1124 Gigabit Switch Figure 1-4 Gigabit Switch for Super User Work Groups Getting to Know the GS1116/GS-1124...
  • Page 17: Chapter 2 Hardware Description And Installation

    Dimension GS-1116/GS-1124 Gigabit Switch Chapter 2 Hardware Description and Installation This section discusses switch installations, hardware and functional overview. The switch is suited to an office environment where it can be rack mounted on standard EIA racks or placed as a standalone switch on a desktop. For proper ventilation, allow at least 4 inches (10 cm) of clearance at the front, 3.4 inches (8 cm) at the back of the switch.
  • Page 18: Rack-Mounted Installation

    Dimension GS-1116/GS-1124 Gigabit Switch Do not block the ventilation holes. Leave space between switches when stacking. Rack-mounted Installation The switch can be mounted on an EIA standard size, 19-inch rack or in a wiring closet with other equipment. Follow the steps below to mount your switch on a standard EIA rack using the included rack-mounting kit.
  • Page 19: Rear Panel

    Dimension GS-1116/GS-1124 Gigabit Switch Rear Panel The ventilation fan and three-pronged power receptacle are located on the rear panel of the switch. Figure 2-4 GS-1116/GS-1124 Rear Panel 2.3.1 Rear Panel Power Connection Connect one end of the supplied power cord to the power receptacle on the back of the switch and the other end to the 100-240 VAC, 50-60 Hz power source.
  • Page 20: Table 2-2 Mini Gbic Slots Led Descriptions

    Dimension GS-1116/GS-1124 Gigabit Switch • 100Mbps or 1000Mbps in full-duplex mode depending on your Ethernet network. 2.4.2 Auto-sensing (Auto MDI/MDIX) Ports You can connect each RJ-45 auto-sensing port to a computer, hub or switch using either a straight through or a crossover Ethernet cable. 2.4.3 Mini GBIC Slots These are slots for Mini GBIC (Gigabit Interface Converter) transceivers.
  • Page 21: Figure 2-7 Transceiver Installation Example

    Dimension GS-1116/GS-1124 Gigabit Switch Figure 2-7 Transceiver Installation Example Figure 2-8 Installed Transceiver Transceiver Removal Use the following steps to remove a mini GBIC transceiver (SFP module) from the GBIC port. Remove the fiber-optic cables from the transceiver. Unlock the transceiver’s latch (latch styles vary). Pull the transceiver out of the slot.
  • Page 22: Figure 2-9 Opening The Transceiver's Latch Example

    Dimension GS-1116/GS-1124 Gigabit Switch Figure 2-9 Opening the Transceiver’s Latch Example Figure 2-10 Transceiver Removal Example Keep the dust cover on a fiber optic module until you connect it. Use the appropriate Ethernet or fiber-optic cables to connect the module to an Ethernet switch. With a fiber-optic module, remove the dust covers from the connectors.
  • Page 23: Figure 2-11 Gs-1116 Front Panel Leds

    Dimension GS-1116/GS-1124 Gigabit Switch Table 2-3 Network Cable Types SPEED NETWORK CABLE TYPE 100Mbps 100Ω 2-pair UTP/STP Category 5 1000Mbps 100Ω 4-pair UTP/STP Category 5 Make sure the cable length between connections does not exceed 100 meters (328 feet). 2.4.5 Front Panel LEDs The LEDs give real-time status information.
  • Page 24: Table 2-4 Front Panel Led Descriptions

    Dimension GS-1116/GS-1124 Gigabit Switch Table 2-4 Front Panel LED Descriptions SYSTEM COLOR STATUS DESCRIPTION The switch is turned on and receiving power. Green The switch is off or not receiving power. 1000 BASE-T ETHERNET PORTS COLOR STATUS DESCRIPTION A link to a 1000Mbps Ethernet device is up. 1000 Green The port is not connected to a 1000Mbps Ethernet device.
  • Page 25: Chapter 3 Troubleshooting

    Dimension GS-1116/GS-1124 Gigabit Switch Chapter 3 Troubleshooting This section describes common problems you may encounter with the switch in your network and possible solutions. Introduction Troubleshoot the switch using the LEDs to detect problems. 3.1.1 PWR LED The PWR LED on the front panel does not light up. Table 3-1 Troubleshooting PWR LED STEPS CORRECTIVE ACTION...
  • Page 26: Improper Network Cabling And Topology

    Dimension GS-1116/GS-1124 Gigabit Switch 3.1.4 FDX/COL LED What is the duplex mode of the Ethernet device? Table 3-4 Troubleshooting FDX LED STEPS CORRECTIVE ACTION The Ethernet device is connected at full-duplex mode if the FDX LED is yellow but not blinking. The Ethernet device is connected at half-duplex mode if the FDX LED is off but the LNK/ACT LED is on or blinking.
  • Page 27: Product Specifications

    Dimension GS-1116/GS-1124 Gigabit Switch Product Specifications This section provides the specifications of the switch. GENERAL IEEE802.3 IEEE802.3u 100BASE-TX Standards IEEE802.3z Gigabit fiber IEEE802.3ab 1000Base-T IEEE802.3x Flow Control GS-1116: 16x 1000Base-T Ethernet Ports GS-1124: 24x 1000Base-T Ethernet Ports Two 3.3V mini-GBIC slots, provide gigabit fiber connectivity Uplink Interface Connector type: RJ-45 Auto-MDIX...
  • Page 28 Dimension GS-1116/GS-1124 Gigabit Switch SYSTEM PWR (Green): On/Off 16/24 x 1000BASE-T ETHERNET PORTS 1000 (Green): On/Off LNK/ACT (Link/Activity), (Green): On/Blinking/Off FDX/COL (Full-duplex), (Yellow): On/Blinking/Off MINI-GBIC SLOTS LNK (Green): On/Off ACT (Green): Blinking 440(W) x 161(D) x 44(H) mm Dimensions 19” rack mountable enclosure Power Supply 100 - 240V AC, 50/60Hz internal universal power supply GS-1116: 47W max...
  • Page 29 Dimension GS-1116/GS-1124 Gigabit Switch Index 1000/ 100 Ethernet LED ......2-4 Installation 802.3x ............1-2 Desktop ............2-1 About the Dimension Gigabit Switch... xii Network Application Auto MDI/MDIX......... 2-4 Backbone Switch........1-3 Auto-negotiation .......... 2-4 Network Cable Length Limit .......2-7 Cabling Length ..........3-2 Network Cable Types........2-7 Campus Environment ........
  • Page 30 2-1 100, 1000 LEDs ........3-1 Ventilation Fan..........2-3 FD LED............3-2 Warranty............iii Troubleshooting Work Groups..........1-4 Improper Network Cabling and Topology.3- ZyXEL Limited Warranty ......iii Note ............iii LK/ACT LED ..........3-1 ZyXEL Web Site...........xii PWR LED ..........3-1 Index...
