- Page 1 ENGLISH T ABLE DVD PLAYER Please read this manual before operating U NIV ER SAL SER IA L BU S...
-
Page 3: Table Of Contents
Table of Contents Table of Contents..................................1 Safety Information..................................2 Remote Control..................................3 Description....................................4 Using the Remote Control................................5 Connecting Earphones (Optional Accessory)..........................6 Connecting to an External Component ............................7 Connecting to a TV..................................8 Connecting to a Stereo Component.............................9 Using USB Port..................................10 Using the AC Adaptor................................11 Using the Battery Pack................................12 Cautions in Using Battery Pack..............................13 Playing a Disc..................................14-16... -
Page 4: Safety Information
Safety Information Please read all of the safety and operating instructions before operating this Player, follow all warnings placed on the Player and in the user's manual. These safety and operating instructions should be retained for future reference. Safety Information Do not expose the system to excessive moisture, rain, sand, or heat sources. -
Page 5: Remote Control
Remote Control Remote Control 14.DVD/USB Button 1.MENU/PBC Button Switches between DVD and USB Brings up the disc menu. mode. 2.L/R Button 15.DISPLAY Button Selects left, right and stereo Displays the current disc playback sound tracks. information. 3.P/N Button 16.MUTE Button Selects PAL/NTSC/AUTO TV systems. -
Page 6: Description
Description Right View Front View 1.LCD 5.LCD on/off switch 2.OPEN 6.CURSOR(UP/DOWN/LEFT/ RIGHT), 3.DISC COVER ENTER( 1.OPEN 6.AUDIO IN/OUT 4.PLAYBACK BUTTONS 7.MENU/PBC 2.EARPHONE / SPEAKER VOLUME 7.VIDEO OUT PLAY/POWER ON( 8.DISPLAY 3.DC IN 12V 8.SPDIF: Digital audio signal SKIP-PREVIOUS/FAST 4.POWER ON/OFF output jack REVERSE( SKIP-... -
Page 7: Using The Remote Control
Using the Remote Control Installing the battery Using the remote control Point the remote control directly at the remote sensor 1.Press down the battery compartment on the front of the DVD Player. cover and turn counter-clockwise to open the cover. 2.Insert a 3V lithium battery into the Battery battery compartment with the polarity... -
Page 8: Connecting Earphones (Optional Accessory)
Connecting Earphones (Optional Accessory) You can attach an earphone with a stereo mini-jack plug to the phone jack ( ) for private listening. The volume can be adjusted using VOL + and VOL - on the remote control. Note: When the earphone is connected to the Phone Jack ( ), the speaker will be disconnected. -
Page 9: Connecting To An External Component
Connecting to an External Component You can enjoy video from VCR or camcorder on your DVD player. 1. Turn off DVD player, VCR and other components. 2. Connect the audio and video cables as illustrated below. 3.Turn on power. VCR or other component equipped with external output connectors AUDIO VIDEO Video out: Yellow... -
Page 10: Connecting To A Tv
Connecting to a TV You can enjoy DVD quality video on TV screen. 1. Turn off DVD player and other components. 2. Connect the audio and video cables as illustrated below. 3.Turn on power. 4.Repeatedly press TV/Video button on your TV to select the input from the DVD player. Connect to a TV equipped with external connection jacks AUDIO VIDEO... -
Page 11: Connecting To A Stereo Component
Connecting to a Stereo Component By connecting the digital output (SPDIF) on the DVD player through a coaxial cable (optional accessory) to a Dolby Digital/DTS amplifier or processor, you can enjoy full 5.1 channel surround sound. Follow these steps for making the connection. 1.Turn off both DVD player and your stereo system. -
Page 12: Using Usb Port
Using USB Port The player accepts most USB devices such as MP3, DSC, USB- drive, Digital Camcorder etc. The USB in this Player supports version 1.1/2.0. USB slot Pluging a USB device 1.Plug in the USB device to the USB port on the player. 2.Repeatedly press DVD/USB to select USB mode. -
Page 13: Using The Ac Adaptor
Using the AC Adaptor This portable DVD player can be powered by AC through the supplied switching power AC adaptor. It can also use the supplied battery pack to power. When the AC adaptor is connected to the unit and powered, the unit will be automatically and electrically disconnected from the battery pack and powered by the AC power. -
Page 14: Using The Battery Pack
Using the Battery Pack Installing the battery pack Removing the battery pack <1>.Align and insert the battery <2>.Slide the battery pack to the <1>.Slide down the latch. <2>.Slide the battery pack to the pack into the corresponding left until it clicks into place. right, and remove. -
Page 15: Cautions In Using Battery Pack
Cautions in Using Battery Pack Danger! Strictly follow these safety information when using the battery pack, otherwise, a short circuit, overheating, smoke, fire, or damage to the product may result. Never disassemble or modify the battery pack in any way. Do not touch the terminal of the battery pack with a metal object. Do not place the battery pack in direct sunlight, dashboard of a vehicle, or high temperature place. -
Page 16: Playing A Disc
Playing a Disc Preparation for Playback Stop 1.Press (on the remote or on the player) to temporarily stop 1.Make sure the Player has the power either from the battery the playback, " " appears on the screen. pack or the AC adaptor. 2.Press again to stop the playback. - Page 17 Playing a Disc pressing to start playing the bookmarked scene. The Slow Motion Playback continues until the end of the disc. Repeat the above 1.During playback, repeatedly press SLOW to play at 1/2, 1/4, to play the other marked scenes. 1/8, 1/16, 1/32 speeds.
- Page 18 Playing a Disc Mute TITLE Press MUTE to silence the audio, press MUTE again to restore Press TITLE, it takes you to the very beginning of the title and play, or to the MENU if it has title menu. Menu/PBC DISPLAY During DVD playback, press MENU/PBC to return to the disc's Start Menu.
-
Page 19: Playing Mp3 And Regular Audio Cd
Playing Mp3 and Regular Audio CD Valid MP3 CD Your MP3 files should be ISO 9660 or JOLIET format. Play In most cases, when a MP3 or audio disc is placed into the player, the first song file of the first folder plays. In other cases, the file manager appears. -
Page 20: Playing Picture Cd
Playing Picture CD Valid Picture Rotate The player can play both Kodak Picture CD that you order from The picture can be rotated and flipped. photo processing store, and home-made CD by burning JPEG 1.During playback, use direction keys ( ) to files onto a CD-R or CD-RW disc. -
Page 21: Displaying And Sorting Files
Displaying and Sorting Files Displaying files Sorting files You can list the file in the order according to its type, name or When a disc or USB device contains multiple file types, date. can select and display only certain file types. 1. -
Page 22: Setting Language For Osd, Menu, Audio, Subtitle
Setting Language for OSD, Menu, Audio, Subtitle 1. Press SETUP on the remote control. Changing voice language 2. Use the direction keys ( ) to select Language Setup and its sub-menu. 3. Press to confirm your selection. Language Setup 4. Press SETUP to exit. English Menu Chinese... -
Page 23: Setting Screen For Display Format, Screen Saver, Tv System
Setting Screen for Display Format, Screen Saver, TV System 1. Press SETUP on the remote control. Turning on/off screen saver 2. Use the direction keys ( ) to select Screen Setup and its sub-menu. 3. Press to confirm your selection. Screen Setup 4. -
Page 24: Setting Audio For Downmix
Setting Audio for Downmix 1. Press SETUP on the remote control. Change Downmix 2. Use the direction keys ( ) to select Audio Setup and its sub-menu. 3. Press to confirm your selection. Audio Setup 4. Press SETUP to exit. Digital Out Lo/Ro Downmix... -
Page 25: Setting Parental Control, Password, Camera Angle, Default
Setting Parental Control, Password, Camera Angle, Default 1. Press SETUP on the remote control. Turning on/off camera angle 2. Use the direction keys ( ) to select Custom Setup and its sub-menu. When ON is selected, the player will display multi-angle mark 3. -
Page 26: Adjusting Lcd Screen
Adjusting LCD Screen You can adjust screen"s Brightness, Contrast, Color, as well as to reverse the screen image 180 degrees. Adjusting Brightness, Contrast and Color 1.Press and hold MENU/PBC/LCD adj. for few seconds to display the adjustment menu. 2.Use to select the Brightness ( ), Contrast ( ),Color( ), and use... -
Page 27: Troubleshooting
Troubleshooting If your DVD player dose not seem to be functioning properly, check the items below before you contact a service center. Symptom Check Power does not turn on Make sure the AC Power cord is securely plugged into an AC outlet. or suddenly turns off Turn the power off and then back on. -
Page 28: Troubleshooting
Troubleshooting Symptom Check While in the input mode, no picture is Check that the video or audio cable is securely connected. output from the external component to the DVD player Battery pack won't charge Check that the DVD player is turned on. You cannot charge the battery pack with the player turned off. -
Page 29: Specifications
Specifications Power Requirements Input AC 100V~240V, 50/60 Hz, Output DC 12V General Power Consumption 15 W Weight 1155.5g (without battery pack) Dimensions 255mm ( W ) x 179mm ( D ) x 32.2mm ( H ) Operating T emperature Range +10 C~ +40 C Readable DVD, DVD-R, DVD+R, DVD-RW,DVD+RW, VCD, CD, HDCD, Picture CD, CD-R, CD-RW,... - Page 30 ~ 27 ~...
