LENCO DVD-517 H Quick Manual

Preparation / installation:
Connect the loudspeakers to the speaker connectors
as shown on image 1 - 5.
For optimal results position the loudspeakers as shown
on the image below.
Use a SCART cable for easy connecting your TV.
TV
1. Peel off approximately 1/ 2 of cable insulation
2. Tighten the wire end
3. Open cable terminal by pressing back on tab
4. Insert wire end into terminal (use grey wire for the red
connector and grey/black wire for the black connector)
5. Release tab; make sure wire is in terminal securely
AVOID SHORT CIRCUIT !
DO NOT CONNECT SPEAKERS AS SEEN BELOW
QUICK-GUIDE DVD-517 H
Basic operation:
Sound Source Selection:
On the remote press TUNER, DVD or AUX
Automatic Tuning:
1.
2.
3.
4.
Select PresetStations:
1.
2.
3.
Playing a DVD/CD:
1.
2.
3.
4.
5.
Please refer to the manual for a more detailed description of
how to operate the unit or how to setup the unit to your
personal taste.
Press "tuner" button on the remote
Press the "auto" button, automatic tuning mode is
activated
When a station is stored, the memory storage
number, as well as the station's frequency, will
flash for four seconds in the display
When the total number of stations reaches
40, no further station in that wave band will be
saved
Press "tuner" button on the remote
Press "Pres/Tune" button
Press any of the numbered buttons to
select the desired station's memory number
You can also use the CH + / - buttons to select
PresetStations
Press "DVD" button on the remote
Press "Open/Close" button (on the unit or remote)
Insert a DVD/CD disc with the label facing upwards
Press "Open/Close" button again, tray will close
Once the disc is read, the unit will automatically
start playback
