Quantum LTO 1U Quick Start Manual

1U Rackmount
Quick Start Guide
CONTENTS
English ................................1
German ...............................6
Spanish ..............................11
French ................................16
Japanese ...........................21
Korean ...............................26
Simplified Chinese ............31
Class A Device
Declarations ......................36
For More Information .......36
Introduction
This guide provides instructions for installing the 1U Rackmount enclosure in an
equipment rack, and for installing tape drives into the 1U Rackmount.
The 1U Rackmount accommodates the following tape drives:
• DAT-72 (models CD72 and CD144)
• DLT-V4 (models CV1303 and CV1304)
• DLT VS160 (models BHFCA-EO, BHFCA-EY, BHGCA-EO and BHGCA-EY)
• LTO-2 HH (models CL1003 and CL1004)
• LTO-3 HH (models TC-L33CX-EO and TC-L33CX-EY)
Power requirements for the 1U Rackmount are as follows:
• 100-240 Volts AC / 4-2 Amps
• 47-63 Hz
The 1U Rackmount comes with either one or two tape drives installed. If yours
came with one, you may add another in the future (you may use any of the above-
mentioned tape drive types). See
Installing the 1U Rackmount in an Equipment Rack
1 The packing box contains the 1U Rackmount enclosure, mounting kit, and
accessories.
2 Use the mounting kit to install the 1U Rackmount into your equipment rack.
Refer to the installation instructions included with mounting kit.
W : For maximum stability, the equipment rack should be securely bolted
ARNING
to the floor per the rack manufacturer's recommendations.
After installing components in the equipment rack, do not pull out more
than one component on its slide rails at a time. If the equipment rack is not
securely bolted to the floor, the weight of more than one extended
component could cause the equipment rack to become unstable, tip over,
and cause damage, serious bodily injury, or death.
Installing a Second Tape Drive
0
for instructions.
