MSI MEGA Book
L610I Notebook PC
User's Guide
G52-B1002X1
I

Advertisement

Table of Contents
loading

Related Manuals for MSI L610

Summary of Contents for MSI L610

  • Page 1 MSI MEGA Book L610I Notebook PC User’s Guide G52-B1002X1...

  • Page 2: Regulations Information

    Regulations Information FCC-B Radio Frequency Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.

  • Page 3: Safety Guideline For Using Lithium Battery

    Safety Guideline for Using Lithium Battery (Danish) ADVARSEL! Lithiumbatteri – Eksplosionsfare ved fejlagtig (Danish) ADVARSEL! Lithiumbatteri – Eksplosionsfare ved fejlagtig (Danish) ADVARSEL! Lithiumbatteri – Eksplosionsfare ved fejlagtig (Danish) ADVARSEL! Lithiumbatteri – Eksplosionsfare ved fejlagtig (Danish) ADVARSEL! Lithiumbatteri – Eksplosionsfare ved fejlagtig h å...

  • Page 4: Caution On Using Modem

    Caution on Using Modem Never install telephone wiring during a lightning storm. Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations. Never touch uninsulated telephone wires or terminals unless the telephone line has been disconnected at the network interface. Use caution when installing or modifying telephone lines.

  • Page 5: Safety Instructions

    Safety Instructions Read the safety instructions carefully and thoroughly. Save this User’s Guide for possible use later. Keep this equipment away from humidity and high temperature. Lay this equipment on a stable surface before setting it up. The openings on the enclosure are used for air convection and to prevent the equipment from overheating.

  • Page 6: Technical Support

    * PCMCIA and CardBus are registered trademarks of the Personal Computer Memory Card International Association. Technical Support Visit the MSI website for FAQ, technical guide, driver and software updates, and other information: http://www.msi.com.tw/. Contact our technical staff at: support@msi.com.tw. Release History...

  • Page 7: Table Of Contents

    Table of Contents Getting Started 1.1 Before You Begin ..............1-2 Unpacking ................... 1-2 Features and Benefits ..............1-3 1.2 Quick Components Guide ............. 1-4 Top-open View ................1-4 Front View .................. 1-6 Right-side View ................1-8 Left-side View ................1-9 Rear View ................
  • Page 8 Basics of Using Notebook PC 2.1 Safety and Comfort Tips ............2-2 Set Up Your Work Environment ..........2-2 Have a Good Work Habit ............2-3 2.2 Knowing the Keyboard ............2-4 Typewriter Keys ................. 2-5 Cursor Keys ................2-6 Numeric Keys ................
  • Page 9 SMI BlueBird Playlist Editor ............3-6 - How to create a playlist by BlueBird ............3-7 MSI Live Update™ 3 ..............3-8 - Using MSI Live Update 3 ................3-8 - Updating BIOS .................... 3-9 - Updating Driver ..................3-10 - Updating Utility ..................
  • Page 10 Power Management 4.1 Introduction to the Power Source ........4-2 The AC Adapter ................. 4-2 The Battery Pack ............... 4-3 - Charging the Battery ..................4-3 - Changing the Battery Pack ................4-5 - Replacing the battery pack ................4-6 4.2 Managing the Power ..............
  • Page 11 Expanding and Upgrading 6.1 Connecting the External Devices ........6-2 Connecting the Peripheral Devices ..........6-2 - Using the LAN ..................... 6-5 Connecting the Communication Devices ........6-5 - Using the LAN ..................... 6-7 - Using the Modem ..................6-7 Installing the PC Card ..............

  • Page 12: Getting Started

    Getting Started Congratulations on purchasing MSI MEGA Book - L610I Note- book PC! This chapter first provides a general introduction on your Note- book PC, to let you know the hardware components well and start to work easily. Why wait? Read on to learn more about the powerful features and multimedia function of your Note- book PC.

  • Page 13: Before You Begin

    Also, keep the box and packing materials in case you need to ship the unit in the future. The package should contain the following items: One Notebook PC - MSI MEGA Book L610I. One Recovery CD. One Software CD containing the drivers and utilities.

  • Page 14: Features And Benefits

    Features and Benefits Next Generation CPU Support. Your Notebook PC is equipped with one of the latest CPU (central processing unit) that supports Intel® Pentium Prescott FSB-800/533 (up to 3.4GHz) and Intel® Pentium Northwood FSB- 800/533 and Intel® Celeron FSB-400 (up to 3.6GHz). Integrated Wireless LAN Solution.

  • Page 15: Quick Components Guide

    L610I Series Notebook PC 1.2 Quick Components Guide This section provides the multi-views of your Notebook PC, and briefly intro- duces the function of each component. Top-open View Press the Cover Latch to open the top cover (see page 1-7), and you can find the main operating area of your computer.
  • Page 16 Display Panel: The 15.4-inch WXGA TFT color LCD screen displays the output of the computer. Quick Launch Buttons and Power Button: - Power Button: to turn the computer power ON and OFF. - Quick Launch Buttons: one-touch buttons, allowing you to launch specific software application easily (see Quick Launch Buttons in Chapter 2 for more information).

  • Page 17: Front View

    L610I Series Notebook PC Front View Knowing the components on the front side of your computer. 4-in-1 Card Reader The built-in card reader supports MMC (multi-media card), SD (secure digital), SM (smart media), and MS (memory stick) cards. IEEE 1394 Port The IEEE 1394 port is a high-speed bus that allows you to connect high-end digital devices such as the DV (digital video camera).
  • Page 18 Front Panel Control Buttons: a. Mode selection to switch CD/MP3, HDD or Radio mode. b. Eject/Stop (memory recall button) HDD - stop; CD/MP3 - eject/stop CD; Radio - radio channel memory recall. c. Backward (decrease button) HDD,CD/MP3 - play backward; Radio - turning up. d.

  • Page 19: Right-Side View

    L610I Series Notebook PC Right-side View Knowing the components on the right side of your computer. HDD Device The hard disk drive properly fixed upper to the Optical Storage Device. Optical Storage Device A slim CD-ROM/ DVD-ROM/ CD-RW/ DVD Combo/ DVD Dual drive is available in the computer, depending on the model you purchased.

  • Page 20: Left-Side View

    Left-side View Knowing the components on the left side of your computer. Kensington Lock This port is used to lock the computer to a location for security (see Caring Your Notebook PC in Chapter 7 for more information). Ventilator The ventilator is designed to cool the system. DO NOT block the ventilator for air circulation.

  • Page 21: Rear View

    L610I Series Notebook PC Rear View Your Notebook PC provides many I/O ports on the rear panel. Battery Unlock Button If you want to replace a battery, press and slide the button to remove the battery pack. RJ-45 Connector The 100/10 Ethernet connector is used to connect a LAN cable for network connection.
  • Page 22 S-Video Connector: By using a Super VHS (S-Video) cable, this connector allows you to connect a television (NTSC/PAL system) for a great view of the computer display. USB Port: The USB 2.0 port allows you to connect USB-interface peripheral devices, such as the mouse, keyboard, modem, external hard disk module, printer, and more.

  • Page 23: Bottom View

    L610I Series Notebook PC Bottom View Carefully put the computer upside down, and you can find the core compo- nents of the computer. 1 - 12...
  • Page 24 Battery Pack To supply power to your computer when the AC adapter is not connected (see Introduction to the Power Source in Chapter 4 for more information). Optical Storage Device s l i m C D - R O M / D V D - R O M / C D - R W / D V D C o m b o / DVD Dual drive is available in the computer, depending on the model you purchased.

  • Page 25: Preparing To Operate

    L610I Series Notebook PC 1.3 Preparing to Operate Connecting the Power Your Notebook PC is equipped with a high-capacity 12-cell Li-ion battery pack, and it can operate either on the battery’s power or AC power. However, for the first time to use your Notebook PC, it is recommended to connect the AC adapter and use the AC power.

  • Page 26: Disconnecting The Ac Power

    Notebook PC; using other adapter model may damage the computer or other devices on the computer. When unplugging the power cord, always hold the connector part of the cord , never pull the cord MSI reminds you... 1 - 15...

  • Page 27: Turning On/Off The Notebook Pc

    L610I Series Notebook PC Turning On/Off the Notebook PC Now, when the AC adapter is connected, you are ready to use your computer. Opening the Top Cover First, open the top cover by sliding the cover button on the front side of the computer, and then lifting the top cover gently.

  • Page 28: Turning Off The Computer

    Turning Off the Computer In Windows operating system, always use the “Shut Down” command of the system to turn off the computer. This is the normal operating procedure that can prevent the system problems. Click Start ( ) from the taskbar, and then select the Turn Off Computer option ( ).
  • Page 29 Also, remember to remove any CD disk from the drive. Gently tilt down the top cover when you are closing the cover, and make sure that the cover latches click into place securely. MSI reminds you... 1 - 18...

  • Page 30: Basics Of Using Notebook Pc

    Basics of Using Notebook PC This chapter introduces the operating basics for your Notebook PC, including the use of keyboard, touchpad, LCD panel, hard disk drive, and optical storage device. It also includes the advanced features such as audio and communication functions.

  • Page 31: Safety And Comfort Tips

    L610I Series Notebook PC 2.1 Safety and Comfort Tips If you are a beginner to the Notebook PC, please read the following tips to make yourself safe and comfortable during the operation. Set Up Your Work Environment The Notebook PC is a portable platform that allows you to work anywhere. However, choosing a good workspace is important if you have to work with your Notebook PC for long periods of time.

  • Page 32: Have A Good Work Habit

    Keep your hands and feet with optimal comfort. Sit straight and keep a good posture. Adjust the angle and position of LCD panel. Adjust the desk’s height. Adjust the chair’s height. Setting up your work environment Have a Good Work Habit Have a good work habit is important if you have to work with your Notebook PC for long periods of time;...

  • Page 33: Knowing The Keyboard

    L610I Series Notebook PC 2.2 Knowing the Keyboard The Notebook PC’s keyboard provides all the functions of a full-sized 87/88- key keyboard, and an additional [Fn] key for specific functions on the computer. How to use keyboard can divide into four categories: Typewriter keys, Cursor keys, Numeric keys, and Function keys.

  • Page 34: Typewriter Keys

    Typewriter Keys The Typewriter Keys The function of these Typewriter keys is the major function of the keyboard, which is similar to the keys on a typewriter. It also provides several keys for special purposes, such as the [Ctrl], [Alt], and [Esc] keys. When the lock keys are pressed, the corresponding LEDs will light up to indicate their status: Num Lock: Press and hold the [Fn] key, and then press this key to toggle...

  • Page 35: Cursor Keys

    L610I Series Notebook PC Cursor Keys The keyboard provides four cursor (arrow) keys and [Home], [PgUp], [PgDn], [End] keys at the lower right corner, which are used to control the cursor movement. The Cursor Keys Move the cursor left for one space. Move the cursor right for one space.

  • Page 36: Numeric Keys

    The Numeric Keys The numeric keys may lose function in some specific software applications. If so, you may use the typewriter keys to input the numbers, or connect an external numeric keypad. MSI reminds you... 2 - 7...

  • Page 37: Function Keys

    L610I Series Notebook PC Function Keys Windows Keys You can find the Windows Logo key ( ) and one Application Logo key ( on the keyboard, which are used to perform Windows-specific functions, such as opening the Start menu and launching the shortcut menu. For more information of the two keys, please refer to your Windows manual or online help.

  • Page 38: Quick Launch Buttons

    2.3 Quick Launch Buttons With these four Quick Launch Buttons, you can easily access the Internet, read your E-mail, or launch your frequently used software application. Email: to launch the E-mail application (such as Outlook Express) to receive and send your E-mail. Internet: to launch the web browser (such as Internet Explorer) to surf the Internet.

  • Page 39: Knowing The Touchpad

    L610I Series Notebook PC 2.4 Knowing the Touchpad The touchpad integrated in your computer is a pointing device that compatible with the standard mouse, allowing you to control the computer by pointing the location of the cursor on the screen and making selection with its two buttons. The Touchpad Cursor Movement Area The pressure-sensitive area of the touchpad, allows you to place your fin-...

  • Page 40: Using The Touchpad

    Using the Touchpad The following table and diagrams provide some tips that you should know when using the touchpad: Positioning and Moving: Place your finger on the touchpad (usually using the forefinger), and the rectangular pad will act as a miniature dupli- cate of your display.
  • Page 41 Clean the touchpad with soft dry cloth regularly to prevent the dust and liquids on it. When using the touchpad, keep your fingers and the touchpad clean and dry for optimal performance. Do not use excessive force when tapping on the touchpad. MSI reminds you... 2 - 12...

  • Page 42: Configuring The Touchpad

    Configuring the Touchpad You can customize the pointing device to meet your personal needs. For example, if your are a left-hand user, you may want to swap the functions of the two buttons. In addition, you can change the size, shape, moving speed, and other advanced features of the cursor on the screen.

  • Page 43: Using The Optical Storage

    The optical storage devices are classified as a Class 1 Laser products. Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. Do not touch the lens inside the drive. MSI reminds you... 2 - 14...

  • Page 44: Inserting The Cd

    Inserting the CD The following instruction describes the general procedure when operating the optical storage device, including the DVD-ROM drive. Confirm that the computer is turned on. Press the Eject Button on the drive’s panel ( ), and the CD tray will slide out partially.

  • Page 45: Removing The Cd

    Hold the CD by its edge with your fingers, and then lift it up from the tray. Push the tray back into the drive. Confirm that the CD is placed correctly and securely in the tray before closing the tray. Do not leave the CD tray open. MSI reminds you... 2 - 16...

  • Page 46: Releasing The Cd Manually

    Releasing the CD Manually If unfortunately you can not release the CD tray by pressing the Eject Button, you can release it manually: Confirm that the computer is turned off. Insert a pointed object (e.g. a straightened clip) into the Emergency Eject Hole ( ), and the CD tray will slide out partially.

  • Page 47: The Hard Disk Drive

    LED is on. Do not remove or install the hard disk drive when the computer is turned on. The replacement of hard disk drive should be done by an authorized retailer or service representative. MSI reminds you... 2 - 18...

  • Page 48: Using The Video Function

    CD of your computer to take full advantage of the video subsystem. When using the external CRT monitor as the display output device, the resolution depends on the specification of the connected CRT monitor. MSI reminds you... 2 - 19...

  • Page 49: Configuring The Display Settings

    L610I Series Notebook PC Configuring the Display Settings Your Notebook PC has been set to a default resolution and colors when shipping: Now, you can change the settings to meet your needs through the operating system. Changing the Resolution and Colors Quality Click Start from the taskbar, and select Control Panel to open the Control Panel window.

  • Page 50: Changing The Display Output Device

    Changing the Display Output Device Click Start from the taskbar, and select Control Panel to open the Control Panel window. Double-click the Display item to open the Display Properties window. Click the Advanced button to bring up the following window that contains more settings.

  • Page 51: Using The Audio Function

    L610I Series Notebook PC 2.8 Using the Audio Function Connecting Audio Devices Your Notebook PC is equipped with a audio subsystem. However, you can also connect the external audio devices for a better audio quality when enjoy- ing your music and movie on the computer. The audio-out jack allows you to connect the speakers and headphones;...

  • Page 52: Hi-Fi Function

    CD of your computer to take full advantage of the audio subsystem. When you connect the external speakers or microphone and use them as your audio subsystem, the built-in audio device will be disabled. MSI reminds you... 2 - 23...

  • Page 53: Button Definition

    L610I Series Notebook PC MS-1002 (project name) is a special feature for playback video audio and FM radio. User can playback AV, audio, mp3 from HDD, CD, DVD and listen radio on power on mode, and playback audio,MP3 files from CD-ROM and HDD or listen FM radio on power off mode without turn on system.

  • Page 54: Using The Software Applications

    Using the Software Applications Your Notebook PC provides you with the useful software applications, as well as the required drivers for the system. It also provides a Recov- ery CD that allows you to resume your operating system easily and quickly.

  • Page 55: Using The Recovery Cd

    L610I Series Notebook PC L610I Series Notebook PC 3.1 Using the Recovery CD The Recovery CD is a compact disk that records the sources of operating system and important data and can be used to restore the hard disk to its original state.

  • Page 56: Using The Software Cd

    3.2 Using the Software CD The Software CD is a compact disk which provides the necessary drivers and software applications for your Notebook PC. When do I Need the Software CD? You want to install the operating system from your Windows Setup CD, but not from the Recovery CD that included in the package.
  • Page 57 If not, you may need to install the drivers manually from the Software CD included in the package. Please contact your local dealer or visit our website for driver update information. MSI reminds you...

  • Page 58: Activating Your System

    3.3 Activating Your System Before using your computer, you need to activate the Windows XP operating system by the following steps. Welcome to Microsoft Windows. After the computer is ready for the pre-use configuration, the screen will show the Welcome to Microsoft Windows message. Click Next to continue.
  • Page 59 L610I Series Notebook PC L610I Series Notebook PC Do you want to set up Internet access now? You’ve finished setting up Windows and your computer is now ready to use. You can click Yes to set up your computer to connect to the Internet now, or click No to set up later.

  • Page 60: Advanced Features

    3.4 Advanced Features The advanced features provided by your Notebook PC include: BlueBirdd Playlist Editor, MSI Live Update™ 3, MSI Search Key, Trend Micro PC-cillin 2002, and InterVideo WinDVD 4. This section provides you with the common instructions on using these features; for more information, please refer to their manuals or online help.

  • Page 61: How To Create A Playlist By Bluebird

    L610I Series Notebook PC L610I Series Notebook PC How to create a playlist by BlueBird After starting BlueBird, the screen shows like figure below: Click on Create button and enter a name you want in the column of Playlist Name to create a new playlist. Database File Drive is default to C:/, this is the only recognizable path for Hi-Fi Function.

  • Page 62: Msi Live Update™ 3

    MSI Live Update™ 3 MSI Live Update™ 3 is a useful utility for you to enhance the performance of your Notebook PC. With its auto-search and scheduling function, Live Up- date 3 saves you the efforts and time of surfing through websites to find the desired BIOS or drivers.

  • Page 63: Updating Bios

    4. Click the MSI Live Update Series Server button. 5. It will connect to MSI’s database automatically to search the supported BIOS, and then shows the results in the page. 6. If it has found one (or more) supported BIOS for your system, click the InstallShield Wizard button on the right side of the table to download and update the desired BIOS automatically.

  • Page 64: Updating Driver

    2. It will check and list the system information of your computer. 3. Click the MSI Live Update Series Server button. 4. It will connect to MSI’s database automatically to compare the version of driver in the database. It may take several minutes to detect the required drivers.

  • Page 65: Trend Micro™ Pc-Cillin™ 2002

    L610I Series Notebook PC L610I Series Notebook PC Trend Micro™ PC-cillin™ 2002 Trend Micro™ PC-cillin™ is a powerful anti-virus application that pre-installed in your system, which will be launched automatically as the operating system starting up. Registering Your PC-cillin 2002 For the first time to use, it is recommended to take a few minutes to register your software online and receive the benefits.

  • Page 66: Using Pc-Cillin 2002

    Using PC-cillin 2002 When you turn on the computer and login the system, the Real-time Monitor function of PC-cillin 2002 is automatically launched and shows an icon ( ) on the taskbar. Double-click the icon to open the main window of PC-cillin 2002. You can choose Scan All Drives to start scanning your system immediately.

  • Page 67: Intervideo Theater

    L610I Series Notebook PC L610I Series Notebook PC InterVideo Theater it is a powerful tool to make your PC more useful! You can watch TV, VCD, DVD, listen to music and radio, view and edit pictures and video clips and you can even have fun with playing Karaoke on your PC.

  • Page 68: Music Function

    Music Function This function let you arrange your favorite music easily. You can go directly to the location where you put your music collection and view all the music data- base by using View Library function. When you listen to music, you can open View Playlists to check which song is playing.

  • Page 69: Video Clips Function

    L610I Series Notebook PC L610I Series Notebook PC Video Clips Function Edit your motion films and group them in easy-found way. You can view collections by tumbnails to find what you need. DVD/VCD Function It is a powerful play tool for DVD and VCD playing. You can easily choose language by single button without confused options.

  • Page 70: Karaoke Function

    Karaoke Function It will be one of your favorite function. You don’t have to buy another Karaoke machine. Karaoke Function on you PC makes you have fun at home with your friends and family. 3-17...
  • Page 72 Basics of Using Notebook PC This chapter introduces the operating basics for your Notebook PC, including the use of keyboard, touchpad, LCD panel, hard disk drive, and optical storage device. It also includes the advanced features such as audio and communication functions.

  • Page 73: Introduction To The Power Source

    Notebook PC; using other adapter model may damage the computer or other devices on the computer. When unplugging the power cord, always hold the connector part of the cord, never pull the cord. MSI reminds you... 4 - 2...

  • Page 74: The Battery Pack

    The Battery Pack The rechargeable Li-ion battery pack is an internal power source of the computer. A fully charged battery pack can supply power to the computer up to 2.5 hours, depending on the actual use of your computer. Charging the Battery The battery pack can be charged while it is installed in the Notebook PC.
  • Page 75 The operating time allowed depends on the actual use of your computer. For more instructions on using and caring the battery pack, please refer to Taking Care of Your Computer in Chapter 7. MSI reminds you... 4 - 4...

  • Page 76: Changing The Battery Pack

    Changing the Battery Pack You can purchase an additional battery pack from your local dealer, so that you can use it as a spare when traveling. To remove the battery pack: Confirm that the computer is turned off. Locate the Battery Unlock Button on the rear side of the computer. Push the Unlock Button upwards ( ).

  • Page 77: Replacing The Battery Pack

    Slide the battery cover into place and then push downwards to secure the battery pack. Do not try to disassemble the battery pack. Please follow your local laws and regulations to dump your used battery pack. MSI reminds you... 4 - 6...

  • Page 78: Managing The Power

    4.2 Managing the Power The Windows XP operating system supports ACPI (Advanced Configuration and Power Interface), which allows you to manage the computer power easily and efficiently. With the ACPI function, the power can be distributed to different components individually according to their ne eds.
  • Page 79 L610I Series Notebook PC Under the Alarms tab, you can activate the battery alarm function by checking the options in Low battery alarm and Critical battery alarm fields. Once activated, adjust the slide bar to set up the low or critical power level (the default setting is 10%).
  • Page 80 Do not use the card reader or other storage devices when the battery power is low. The access time may be longer than the time you can operate. Otherwise, you may lose your critical data or files. MSI reminds you... 4 - 9...
  • Page 81 L610I Series Notebook PC Under the Hibernate tab, you can activate Hibernation function by checking the Enable hibernation option. Check this option Hibernation is a very useful function of the Windows operating system. When you activate this function, the current and programs are saved to the hard disk drive.

  • Page 82: Intel® Speedstep™ Technology

    Intel® SpeedStep™ Technology You Notebook PC is equipped with an Intel Mobile Processors with Intel SpeedStep technology, which allows you to customize high performance computing on your computer. When the computer is connected to the AC adapter, it can run the most complex business and Internet applications with maximum speed of processor.
  • Page 83 MS-XXXX Notebook...

  • Page 84: Bios Setup

    BIOS Setup BIOS (Basic Input/Output System) is a program for setting up the configuration of the computer. To take full advantage of your computer and connected peripheral devices, you should configure the system through BIOS Setup. This chapter provides the information of BIOS Setup Utility, and guides you to configure the system for optimal use.

  • Page 85: Using Bios Setup Utility

    [Ctrl]+[Alt]+[Delete] keys to restart. The screen snaps and setting options in this chapter are for your references only. The actual setting screens and options on your computer may be different because of BIOS update. MSI reminds you... 5 - 2...

  • Page 86: Control Keys

    Control Keys You can use only the keyboard to control the cursor in the BIOS Setup Utility. Move the cursor left to select one menu title. Move the cursor right to select one menu title. Move the cursor up to select one item under the menu title. Move the cursor down to select one item under the menu title.

  • Page 87: Main Menu

    L610I Series Notebook PC L610I Series Notebook PC 5.2 Main Menu Once you enter the BIOS Setup Utility, the Main menu will appear on the screen. The Main menu displays the system information, including the basic configuration. System Overview Use this menu for basic information of BIOS version and Processor and system configurations, such as time, date etc.
  • Page 88 Use this menu to choose whether saving your changes or not. Available settings for “1st/2nd Boot Device” vary depending on the bootable devices you have installed. For example, if you did not install a floppy drive, the setting “Floppy” does not show up. MSI reminds you... 5 - 5...

  • Page 89: System Overview

    L610I Series Notebook PC L610I Series Notebook PC 5.3 System Overview AMIBIOS This menu first shows AMIBIOS information including Version, Build Date, VGA version and EC version. Processor The second filed shows Processor Type and Speed. System Memory The third field shows information of System Memory Size. System Time The status is [hour:minute:second].
  • Page 90 Minute The value is set from 00 to 59. It won’t make any change to the value of hour by increasing or decreasing value of minute. Second The value is set from 00 to 59. It won’t make any change to the value of hour and minute by increasing or decreasing value of second.

  • Page 91: Advanced Settings

    L610I Series Notebook PC L610I Series Notebook PC 5.4 Advanced Settings The Advanced menu contains CPU Configuration, IDE Configuration , SuperIO Configuration and USB Configuration. First it shows the warning message about malfunction may cause because of your error settings. Therefore, you must be careful before changing any default value.
  • Page 92 IDE Configuration Once you press [Enter], it will show the screen below: Primary IDE Master It shows information of Primary IDE Master including Device, Vendor, Size, LBA Mode, Block Mode, PIO Mode, Async DMA, Ultra DMA and S.M.A.R.T. Primary IDE Slave It shows information of Primary IDE Master including Device, Vendor, Size, LBA Mode, PIO Mode, Async DMA and Ultra DMA.
  • Page 93 L610I Series Notebook PC L610I Series Notebook PC SuperIO Configuration Once you press [Enter], it will show the screen below: OnBoard FIR Port Allows BIOS to Disable or select FIR Port. There are three options available: [Disabled], [7F8H] and [7E8H]. Default setting is [7F8H]. FIR Port IRQ Allows BIOS to select FIR Port IRQ.
  • Page 94 Parallel Port Mode Allows BIOS to select Parall Port Base Addresses. There are four options available: [Normal], [Bi-Directional], [EPP] and [ECP]. Default setting is [Normal]. Parallel Port IRQ Allows BIOS to select Parall Port IRQ. There are two options available: [IRQ5] and [IRQ7].

  • Page 95: Boot Settings

    L610I Series Notebook PC L610I Series Notebook PC 5.5 Boot Settings Boot Settings Press <Enter> and the following sub-menu appears. Quick Boot It allows BIOS to skip certain tests while booting. It will save time to boot the system. There are two options available: [Disabled] and [Enabled]. Default setting is [Enabled].
  • Page 96 1st Boot Device It specifies the boot sequence from the available devices. There are three options available: [PS-QSI CD-RW/DVD-ROM SBW242B], [PM-TOSHIBA MK40255GAS] and [Disabled]. Default setting is [PM-TOSHIBA MK40255GAS]. 2nd Boot Device It specifies the boot sequence from the available devices. There are three options available: [PS-QSI CD-RW/DVD-ROM SBW242B], [PM-TOSHIBA MK40255GAS] and [Disabled].

  • Page 97: Power Settings

    L610I Series Notebook PC L610I Series Notebook PC 5.6 Power Settings Power Settings Press <Enter> and the following sub-menu appears. Wake on LAN Wake on Broadcom LAN. There are two options: [Disabled] and [Enabled]. Default setting is [Enabled]. Wake on MDC There are two options: [Disabled] and [Enabled].

  • Page 98: Security Settings

    5.7 Security Settings Security Settings Press <Enter> and the following sub-menu appears. It first shows the status of Password Installation. It will show “Not Installed” if there is no password installed. Change Supervisor Password To install or change Supervisor Password by enter new passord. Change User Password To install or change User Password by enter new passord.

  • Page 99: Exit Options

    L610I Series Notebook PC L610I Series Notebook PC 5.8 Exit Options Exit Options Press <Enter> and the following sub-menu appears. Save Changes and Exit Exit system with saving the changes. Discard Changes and Exit Exit system setup without saving any change. Press Enter or ESC can set up this option.

  • Page 100: Expanding And Upgrading

    Expanding and Upgrading You can expand the capabilities of your Notebook PC and upgrade your system for your necessary. This chapter introduces the installation of optional devices/components for your Notebook PC.

  • Page 101: Connecting The External Devices

    L610I Series Notebook PC L610I Series Notebook PC 6.1 Connecting the External Devices The I/O (input/output) ports on the rear panel of the computer allow you to connect peripheral devices. For the information of these I/O ports, please refer to Quick Components Guide in Chapter 1. Connecting the Peripheral Devices Connecting the Peripheral Devices Connecting the Printer...
  • Page 102 Connect the power cord and turn on the printer. Turn on the computer, and the system will detect a new device. Install the required driver. For further instructions, please refer to your printer’s manual. Connecting the External Monitor You can connect an external monitor to your computer through the VGA port for a larger view with higher resolution.

  • Page 103: Connecting The Communication Devices

    MIS staff or network manager for help. Connecting the LAN Devices You are strongly recommended to install the LAN driver included in the software CD of your computer to take full advantage of the LAN feature. MSI reminds you... 6 - 4...

  • Page 104: Using The Modem

    To reduce the risk of fire, use only No. 26 AWG or larger telecommunication line cord. You are strongly recommended to install the modem driver included in the software CD of your computer to take full advantage of the modem feature. MSI reminds you... 6 - 5...

  • Page 105: Installing The Pc Card

    L610I Series Notebook PC L610I Series Notebook PC Installing the PC Card The PC card slot of your computer allows you to install comprehensive Type- II PC cards that support various functions for your necessary, including the LAN/WLAN card, modem card, and memory card. The following instruction provides you with a basic installation for the PC card, including how to install and remove it.

  • Page 106: Removing The Pc Card

    Do not hold the “golden finger” when installing the PC card; otherwise, it may cause interference or damage to the PC card. Before removing the PC card, you should stop the device in Windows operating system. MSI reminds you... 6 - 7...

  • Page 107: Safely Remove Hardware

    L610I Series Notebook PC L610I Series Notebook PC 6.2 Safely Remove Hardware If you connect any peripheral device to your system, the Safely Remove Hardware icon ( ) will appear on the taskbar. Double-click the icon to bring up the Safely Remove Hardware dialog box. You can see all connected peripheral devices here.

  • Page 108: Upgrading Your System

    6.3 Upgrading your System You can upgrade your Notebook PC through the following ways: 1) adding memory to a maximum of 2GB. 2) replacing the hard disk drive. 3) replacing the CPU. 6 - 9...
  • Page 109 MS-XXXX Notebook...

  • Page 110: Caring Your Notebook Pc

    Caring Your Notebook PC To ensure a trouble-free operation and reduce the risk when working, you should take good care of your computer. This chapter provides the basic guidelines to protect your computer and critical data. 2 - 1...

  • Page 111: Protecting Your Notebook Pc

    L610I Series Notebook PC 7.1 Protecting Your Notebook PC We understand that the Notebook PC is a valuable investment and how important the data stored in your system meant to you. Therefore, we provide the following suggestions to protect your system. Locking Your Computer When you use the computer in the public area, you can secure your computer on the immovable object (such as a desk) by connecting a Kensington-...

  • Page 112: Setting Up Password

    Remember the passwords once they are set. If, unfortunately, you forgot the passwords, please contact your local dealer for assistance. You are recommended to set up the password; it can protect your computer from being used by unauthorized users. MSI reminds you... 7 - 3...

  • Page 113: Using The Anti-Virus Protection

    For further instructions on using PC-cillin 2002, please refer to Advanced Features in Chapter 3. To know more about the computer virus and PC-cillin application, please refer to the document or online help of the software. MSI reminds you... 7 - 4...

  • Page 114: Tips For Traveling

    7.2 Tips for Traveling With your Notebook PC, you can use the computer with more versatility, and in more situations than ever before. Empowered by its light weight design and optimized battery life, you can bring it to presentation and meetings whenever and wherever you want.

  • Page 115: Taking Care Of Your Computer

    L610I Series Notebook PC 7.3 Taking Care of Your Computer The guidelines provided in this section are the basics to take good care of your computer. Placing and Operating Your Computer The guidelines provided in this section are the basics to take good care of your computer.

  • Page 116: Battery Safety Tips

    Cleaning Your Computer TURN OFF the computer when you have to clean it. Clean your computer by using a soft, dry cloth ONLY; do not use the alkaline detergent to wipe the exterior of the computer. Do not clean the LCD panel by using the alcohol or detergent. Only use the soft, lint-free cloth to wipe the LCD panel gently.

  • Page 117: Conserving Battery Power

    L610I Series Notebook PC Conserving Battery Power Efficient battery power is critical to maintain a normal operation of the system. If the battery power is not managed well, your saved data and customized settings may be lost. Follow these tips to help optimize battery life and avoid a sudden power loss. Suspend system operation if the system will be idle for a while or shorten the Suspend Timer’s time period.

This manual is also suitable for:

Mega book l610i

Table of Contents
