SERVICE MANUAL
COMPACT DISC STEREO
CASSETTE RECEIVER
SYSTEM
Z-L200
• This Service Manual is the "Supplement" and replaces "Simple Manual"
Z-L200, (S/M Code No. 09-005-422-5T3).
• This Service Manual contains information about the difference between
Z-L200 (LH) and Z-L200 (HA). If requiring other information, see Service Manual
of Z-L100 (U) / 200 (LH), (S/M Code No. 09-99C-422-5R1).
• If requiring information about the CD mechanism, see Service Manual of AZG-1,
(S/M Code No. 09-001-335-3NC).
Z-L200
BASIC TAPE MECHANISM : ZZM-2 PR1NM
BASIC CD MECHANISM : AZG-1 ZA3RN1DM
CD
SPEAKER
CASSEIVER
CX-ZL200
SX-ZL200
S/M Code No. 09-006-422-5S1
HA
REMOTE
CONTROLLER
RC-ZAS02
Advertisement
Table of Contents
Related Manuals for Aiwa Z-L200
Summary of Contents for Aiwa Z-L200
- Page 1 Z-L200, (S/M Code No. 09-005-422-5T3). • This Service Manual contains information about the difference between Z-L200 (LH) and Z-L200 (HA). If requiring other information, see Service Manual of Z-L100 (U) / 200 (LH), (S/M Code No. 09-99C-422-5R1). • If requiring information about the CD mechanism, see Service Manual of AZG-1, (S/M Code No.
-
Page 2: Specifications
<FM tuner section> Tuning range 87.5 MHz to 108 MHz Usable sensitivity (IHF) 13.2 dBf Antenna terminals 75 ohms (unbalanced) <AM tuner section> Tuning range 530 kHz to 1710 kHz (10 kHz step) 531 kHz to 1602 kHz (9 kHz step) Usable sensitivity 350 V/m Antenna... -
Page 3: Electrical Main Parts List
ELECTRICAL MAIN PARTS LIST REF. NO. PART NO. KANRI 8A-NFA-615-010 C-IC,M38B57MCH-E236FP 87-A21-397-010 IC,STK490-070 87-A21-482-010 IC,RPM6938-H4 87-A21-419-040 C-IC,NJM14558MD-TE2 87-A21-443-040 C-IC,M62495AFP 87-A21-560-010 IC,LA1844L-A 87-070-127-110 IC,LC72131 D TRANSISTOR 87-026-609-080 TR,KTA1266GR 89-213-702-010 TR,2SB1370E 87-026-610-080 TR,KTC3198GR 87-A30-076-080 C-TR,2SC3052F 87-A30-075-080 C-TR,2SA1235F 87-026-245-080 TR,DTC114ES 87-A30-198-080 TR,KTC3199GR 87-A30-090-080 FET,2SK2541 87-A30-107-070 C-TR,CMBT5401... - Page 4 REF. NO. PART NO. KANRI C460 87-010-196-080 C-CAP,S 0.1-25 ZF C461 87-012-158-080 C-CAP,S 390P-50 CH C462 87-012-158-080 C-CAP,S 390P-50 CH C601 87-012-140-080 CAP,CHIP S 470P-50 J CH C602 87-012-140-080 CAP,CHIP S 470P-50 J CH C607 87-010-182-080 C-CAP,S 2200P-50 B C608 87-010-182-080 C-CAP,S 2200P-50 B C609...
-
Page 5: Transistor Illustration
REF. NO. PART NO. KANRI C118 87-010-248-040 CAP,E 220-10 SME C119 87-010-248-040 CAP,E 220-10 SME C120 87-018-123-080 CAP,TC U 220P-50V KB C123 87-A11-148-080 CAP TC U 0.1-50 ZF C124 87-A11-148-080 CAP TC U 0.1-50 ZF C125 87-010-405-040 CAP,E 10-50 M 11L SME C126 87-A11-148-080 CAP TC U 0.1-50 ZF... -
Page 6: Wiring - 1 (Main)
WIRING - 1 (MAIN) – 6 –... -
Page 7: Schematic Diagram - 1 (Main 1/2)
SCHEMATIC DIAGRAM - 1 (MAIN 1/2) – 7 –... - Page 8 SCHEMATIC DIAGRAM - 2 (MAIN 2/2) – 8 –...
-
Page 9: Wiring - 2 (Front)
WIRING - 2 (FRONT) – 9 –... -
Page 10: Schematic Diagram - 3 (Front)
SCHEMATIC DIAGRAM - 3 (FRONT) – 10 –... - Page 11 WIRING - 3 (PT) – 11 –...
- Page 12 SCHEMATIC DIAGRAM - 4 (PT) – 12 –...
- Page 13 WIRING – 4 (DECK) – 13 –...
-
Page 14: Ic Block Diagram
ADJUSTMENT <TUNER> 7. DC Balance / Mono Distortion Adjustment Settings : • Test point : TP3, TP4 (DC Balance) TP8 (Lch), TP9 (Rch) (Distortion) • Adjustment location : L801 • Input level : 60dBµV Method : Set to FM 98.0MHz and adjust L801 so that the voltage between TP3 and TP4 becomes 0V ±... -
