FILE MANAGEMENT
FILE MANAGEMENT
The file management capabilities of the camera make it
easy to keep track of images. You can protect files against
deletion, and even use its DPOF feature to specify images
for printing.
Folders
Your camera automatically creates a directory of image
storage folders in its built-in Flash memory or on the
memory card.
Memory Folders and Files
An image you record is automatically stored in a folder,
whose name is a serial number. You can have up to 900
folders in memory at the same time. Folder names are
generated as shown below.
Example: Name of the 100th folder.
100CASIO
Serial number (3 digits)
Each folder can hold files numbered up to 9,999.
Trying to store the 10,000th file in a folder causes the next
serially numbered folder to be created. Folder names are
generated as shown below.
Example: Name of the 26th file
C I M G 0 0 2 6 . J P G
Serial number (4 digits)
• The actual number of files you will be able to store on a
memory card depends on the image quality settings,
capacity of the card, etc.
• For details about the directory structure, see "Memory
Directory Structure" on page 137.
95
Extension
Advertisement
Table of Contents
Related Manuals for Casio EX-M20U - 3
Summary of Contents for Casio EX-M20U - 3
-
Page 1: File Management
FILE MANAGEMENT FILE MANAGEMENT The file management capabilities of the camera make it Each folder can hold files numbered up to 9,999. easy to keep track of images. You can protect files against Trying to store the 10,000th file in a folder causes the next deletion, and even use its DPOF feature to specify images serially numbered folder to be created. -
Page 2: Protecting Files
FILE MANAGEMENT Use [ ] and [ ] to Protecting Files select “On”, and then Once you protect a file it cannot be deleted (page 93). You press [SET]. can protect files individually or you can protect all files in •... -
Page 3: To Protect All Files In Memory
FILE MANAGEMENT To protect all files in memory DPOF The letters “DPOF” stand for “Digital Print In the PLAY mode, press [MENU]. Order Format”, which is a format for recording on a memory card or other medium Select the “PLAY” tab, select “Protect”, and which digital camera images should be then press [ ]. -
Page 4: To Configure Print Settings For A Single Image
FILE MANAGEMENT To configure print settings for a single Use [ ] and [ ] to specify the number of copies. image • You can specify up to 99 for the number of copies. Specify 00 if you do not want to have the image In the PLAY mode, press [MENU]. -
Page 5: To Configure Print Settings For All Images
FILE MANAGEMENT To configure print settings for all images To turn on date stamping for the prints, press [DISP] so is displayed. 12 12 In the PLAY mode, press [MENU]. • To turn off date stamping for the prints, press [DISP] is not displayed. -
Page 6: Print Image Matching
FILE MANAGEMENT PRINT Image Matching II Exif Print Images include PRINT Image Matching Exif Print is an data (mode setting and other camera internationally supported, setup information). A printer that open standard file format supports PRINT Image Matching that makes it possible to reads this data and adjusts the printed capture and display vibrant image accordingly, so your images... -
Page 7: Using Usb Direct-Print
FILE MANAGEMENT Use the DPOF procedure on page 101 to Using USB DIRECT-PRINT specify the images in file memory that you want to print. Your camera supports USB DIRECT-PRINT, which was Use the USB cable that comes with the developed by Seiko Epson Corporation. - Page 8 FILE MANAGEMENT Press the USB cradle IMPORTANT! [USB] button. • See the documentation that comes with your printer for information about print quality and paper settings. • This displays the print • Contact your printer manufacturer for information menu on the camera’s about models that support USB DIRECT-PRINT, monitor screen.
-
Page 9: Using The Favorite Folder
FILE MANAGEMENT Use [ ] and [ ] to Using the FAVORITE Folder select “Save”, and You can copy scenery shots, photos of your family, or other then press [SET]. special images from a file storage folder (page 137) to the •... -
Page 10: To Display A File In The Favorite Folder
FILE MANAGEMENT NOTES To display a file in the FAVORITE folder • Copying an image file with the above procedure creates a 320 x 240-pixel QVGA-size image in the In the PLAY mode, press [MENU]. FAVORITE folder. • A file copied into the FAVORITE folder is Select the “PLAY”... -
Page 11: To Delete A File From The Favorite Folder
FILE MANAGEMENT NOTE To delete a file from the FAVORITE • Holding down [ ] or [ ] scrolls images at high folder speed. In the PLAY mode, press [MENU]. IMPORTANT! Select the “PLAY” tab, select “Favorites”, and • Note that a FAVORITE folder is created in the then press [ ]. -
Page 12: To Delete All Files From The Favorite Folder
FILE MANAGEMENT IMPORTANT! To delete all files from the FAVORITE • You cannot use the delete operations on page 93 to folder delete images from the FAVORITE folder. Performing the memory format operation (page 119), In the PLAY mode, press [MENU]. however, does delete FAVORITE folder files. -
Page 13: Other Settings
OTHER SETTINGS OTHER SETTINGS Turning the Key Tone On and Off (EX-S20U) Configuring Sound Settings (EX-M20U) Use the following procedure to turn the tone that sounds With the EX-M20U, you can configure separate sounds for when you press a key on and off. startup, shutter release, and key operations. -
Page 14: To Set The Volume Level
OTHER SETTINGS Use [ ] and [ ] to change the setting, and To set the volume level then press [SET]. In the REC mode or the PLAY mode, press To do this: Select this setting: [MENU]. Select a built-in sound Sound 1 through Sound 5 Select the “Set Up”... -
Page 15: Specifying An Image For The Startup Screen
OTHER SETTINGS IMPORTANT! Specifying an Image for the Startup Screen • You can select any one of the following types of You can specify an image you recorded with the camera as image as the startup image. the startup screen image, which causes it to appear on the —... -
Page 16: Configuring Power Down Image Settings
OTHER SETTINGS Change the name of the file to one of the Configuring Power Down Image Settings following. With the Power Down Image feature, you can configure the Snapshot Image: ENDING.JPG camera so a specific image stored in camera image memory appears whenever you turn off power. - Page 17 OTHER SETTINGS I To cancel Power Down Image settings IMPORTANT! • Only a snapshot (JPEG) can be used as the power down image. Use the USB cable to connect the camera to • Note that the Power Down Image feature works only your computer (page 127).
-
Page 18: Specifying The File Name Serial Number Generation Method
OTHER SETTINGS Specifying the File Name Serial Number To do this for a newly saved file: Select this setting: Generation Method Store the last file number used and increment it, regardless of whether Use the following procedure to specify the method for files are deleted or whether the Continue generating the serial number used for file names (page 95). -
Page 19: Using The Alarm
OTHER SETTINGS Press [DISP]. Using the Alarm • You could press [SET] in place of [DISP] if you want You can configure up to three alarms that cause the to configure the alarm without an image. camera to beep and display a specified image at the time you specify. -
Page 20: Stopping The Alarm
OTHER SETTINGS Stopping the Alarm Setting the Clock When an alarm time is reached while the camera is turned Use the procedures in this section to select a Home Time off, the alarm will sound for about one minute (or until you Zone, and to change its date and time settings. -
Page 21: To Set The Current Time And Date
OTHER SETTINGS Use [ ] and [ ] to select “City”, and then To set the current time and date press [ ]. In the REC mode or the PLAY mode, press Use [ ], [ ], [ ], and [ ] to select the [MENU]. -
Page 22: Changing The Date Format
OTHER SETTINGS Changing the Date Format Using World Time You can select from among three different formats for You can use the World Time screen to view a time zone display of the date. that is different from the home time zone when you go on a trip, etc. -
Page 23: To Configure World Time Settings
OTHER SETTINGS To configure World Time settings Use [ ] and [ ] to select the city you want, and then press In the REC mode or the PLAY mode, press [SET]. [MENU]. • This displays the current Select the “Set Up” tab, select “World Time”, time in the city you and then press [ ]. -
Page 24: To Configure Summer Time (Dst) Settings
OTHER SETTINGS To configure summer time (DST) After the setting is the way you want, press [SET]. settings • This displays the current time in accordance with your setting. In the REC mode or the PLAY mode, press [MENU]. Press [SET] again to exit the setting screen. Select the “Set Up”... -
Page 25: Changing The Display Language
OTHER SETTINGS Changing the Display Language Formatting Built-in Memory You can use the following procedure to select one of ten Formatting built-in memory deletes any data stored in it. languages as the display language. IMPORTANT! • Note that data deleted by a format operation cannot In the REC mode or the PLAY mode, press be recovered. - Page 26 OTHER SETTINGS Select the “Set Up” tab, select “Format”, and then press [ ]. Use [ ] and [ ] to select “Format”, and then press [SET]. • To exit the format operation without formatting, select “Cancel”.
-
Page 27: Using A Memory Card
USING A MEMORY CARD USING A MEMORY CARD You can expand the storage IMPORTANT! capabilities of your camera by using • Use only an SD memory card or a MultiMediaCard a commercially available memory with this camera. Proper operation is not guaranteed card (SD memory card or when any other type of card is used. -
Page 28: To Insert A Memory Card Into The Camera
USING A MEMORY CARD To remove a memory card from the Using a Memory Card camera IMPORTANT! • Make sure you turn off the camera before inserting or Press the memory card removing a memory card. into the camera and then •... -
Page 29: Formatting A Memory Card
Formatting a memory card on a computer and then CASIO authorized service center. using it in the camera can slow down data • Never remove a card from the camera while the processing by the camera. -
Page 30: Memory Card Precautions
USING A MEMORY CARD Load the memory card into the camera. Memory Card Precautions • If a memory card starts to behave abnormally, you can Turn on the camera. Next, enter the REC restore normal operation by reformatting it. However, we mode or PLAY mode and press [MENU]. -
Page 31: Copying Files
USING A MEMORY CARD To copy all the files in built-in memory to Copying Files a memory card Use the procedures below to copy files between built-in memory and a memory card. Load the memory card into the camera. IMPORTANT! Turn on the camera. -
Page 32: To Copy A File From A Memory Card To Built-In Memory
USING A MEMORY CARD To copy a file from a memory card to NOTE • Files are copied to the folder in built-in memory built-in memory whose name has the largest number. With this procedure you can copy one file at a time. Perform steps 1 through 3 of the procedure under “To copy all the files in built-in memory to a memory card”.
