Summary of Contents for Crestron CNXENET
-
Page 3: Table Of Contents
CRESTRON Contents CNX Ethernet Expansion Card: CNXENET Description..........................1 Functional Description ....................1 Physical Description....................1 Leading Specifications....................... 2 Installation into the CNMSX ..................... 2 Problem Solving ........................5 Troubleshooting ......................5 Further Inquiries......................5 Return and Warranty Policies....................6 Merchandise Returns / Repair Service ................ -
Page 5: Cnx Ethernet Expansion Card: Cnxenet
Ethernet/LAN, internet and intranet connections. Physical Description The CNXENET, shown below, is an expansion card that occupies the DPA slot and connects directly to the control system’s processor. There are two connectors located on the CNXENET. An 8-wire RJ45 connector for LAN is available externally from the control system once installed. -
Page 6: Leading Specifications
Weight 0.08 lb (0.04 kg) * These three items make up 50219x.upz which is located in the crestron\firmware folder after the install. As of the date of manufacture, the CNXENET has been tested and found to comply with specifications for CE marking. - Page 7 CRESTRON CNXENET Installation (1 of 4) into CNMSX 1. Place the control system right-side-up on a flat surface and remove four screws from the top of the unit. 2. Remove 12 screws from both sides of the control system. There are six screws per side.
- Page 8 DO NOT force pins into connector. 9. Align mounting brackets on CNXENET printed circuit board with mounting holes in chassis so that RJ45 connector aligns with cut out. 10. Secure CNXENET to the control system with two screws 11.
-
Page 9: Problem Solving
Leading Specifications section. Further Inquiries If after reviewing this Operations & Installation Guide for the CNXENET, you cannot locate specific information or have questions, please take advantage of Crestron's award winning customer service team by calling: •... -
Page 10: Return And Warranty Policies
CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended, or if it has been subjected to misuse, accidental damage, modification, or improper installation procedures.
