Reviewing Statistics
Understanding System
Statistics
Understanding Current
Call Information
Various statistics about LAN and WAN parameters are stored and available for
review.
To view statistics, do the following.
1 From the 56K LAN Modem's home page, select Statistics.
2 Select the type of statistics you would like to review.
You can view the following types of statistics.
System
Current Call
Last Call
Service Provider
Refer to the appropriate section for a list and description of the information
provided.
The system statistics are described in Table 9.
Table 9 Description of System Statistics
System Statistics
Product ID
Serial Number
Ethernet Address
System software version number
Boot software version number
The LAN Modem has been up for Displays the length of time the 56K LAN Modem has been
Date (Month/Day/Year)
Time (Hour:Minute:Second)
Built-in modem
* This date and time is based on the computer used to initially set up the LAN Modem.
The current call information is described in Table 10.
Table 10 Current Call Information Description
Current Call Information
Connect Message
Call direction
Service provider name
IP address in use
Primary DNS address
Description
Displays the product ID of the 56K LAN Modem.
Displays the serial number of the 56K LAN Modem.
Displays the Ethernet address of the 56K LAN Modem.
Displays the firmware version of the 56K LAN Modem.
For internal use only.
running. This timer is cleared when the unit is power cycled
or reset.
Lists the current date of the LAN Modem
Lists the current time of the LAN Modem
Displays the DSP version of the LAN Modem
Description
Indicates the modem CONNECT message received for the
current call.
Indicates whether the current call is incoming or outgoing.
Indicates the destination to which the current call is
connected.
Indicates the IP address assigned by the service provider.
Indicates the primary DNS address of the service provider to
which the current call is connected.
Reviewing Statistics
91
*
*
