  • Page 1 +44 (0) 1933 35 2000 +44 (0) 1933 31 2000 fax © 2006 Belkin Corporation. All rights reserved. All trade names are registered trademarks of respective manufacturers listed. The mark Wi-Fi is a registered mark of the Wi-Fi Alliance. P75175...
  • Page 2 N1 Wireless Desktop Card User Manual F5D8001...

  • Page 4: Table Of Contents

    Windows System Tray ........14...

  • Page 6: Introduction

    • Store, retrieve, and copy files from one computer to another • Simultaneously play games online, check Internet email, and chat Advantages of a Wireless Network Here are some of the advantages of setting up a Belkin wireless network: • Mobility – you no longer need a dedicated “computer room”—you can work on a networked laptop or desktop...

  • Page 7: Placement Of Your Wireless Networking Hardware For Optimal Performance

    • In multistory homes, place the wireless router (or access point) on a floor that is as close to the center of the home as possible. This may mean placing the wireless router (or access point) on an upper floor.
  • Page 8 Large aquariums • Metallic-based, UV-tinted windows If your wireless signal seems weak in some spots, make sure that objects such as these are not blocking the signal’s path between your computers and wireless router (or access point). Cordless Phone Placement...
  • Page 9 AOL software, or by re-logging into the secure website. A second alternative is to change your computer’s power management settings so it does not go to sleep; however, this may not be appropriate for portable computers. To change your power management setting in Windows, see the “Power Options”...

  • Page 10: Overview

    The Card complies with the IEEE draft-802.11n specification to communicate with other draft-802.11n-compliant wireless devices at speeds of up to 300Mbps*. The Card is also compatible with 802.11g devices at 54Mbps as well as 802.11b products at 11Mbps. The Card operates on the same 2.4GHz frequency band as 802.11b/g...

  • Page 11: Applications And Advantages

    Applications and Advantages Connection rates of up to 300Mbps* • Provides immediate high-speed wireless connectivity at home, work, and hotspot locations without compromising the use of existing 802.11b/g products Compatibility with 802.11b/g products • The Card is backward-compatible with existing Wi-Fi (IEEE 802.11b/g) products...

  • Page 12: System Requirements

    Overview (a) Power/Activity LED Lights up when the Card is powered on; flashes when wireless activity is detected (b) Card Connector Part of the Card that fits into your computer’s PCI slot (c) External Antenna Connector Lets you connect to the cable from the external antenna System Requirements •...

  • Page 13: Installing And Setting Up The Card

    (This may take 15–20 seconds.) Click “Install Software” or “Next” to start the installation. Note: If the Belkin Wireless Card Installer screen does not appear within 20 seconds, access your CD-ROM by double-clicking on the “My Computer” icon; then double-click on the CD-ROM drive into which the installation CD has been placed.
  • Page 14 “Next”. The first in a series of progress-monitoring screens will let you know where you are in the setup process. You might see a screen similar to this one. This DOES NOT mean there is a problem.

  • Page 15: Step 2 Insert

    Remove the screws behind your computer case that secure the computer cover and remove the cover. Touch any metal part of the case to discharge static electricity, to avoid damage to your product or the computer. Locate an empty PCI expansion slot (usually white in color).

  • Page 16: Step 3 Finish

    Replace the computer’s cover. Plug in the external antenna cable to the connector on the back of the Card. Now that the Card is installed, you can reconnect the power cord and turn the computer back on. Step 3...
  • Page 17 Installing and Setting up the Card Installing and Setting up the Card The Wizard will now install your software. You might see a screen similar to this one. This DOES NOT mean there is a problem. Our software has been fully tested and is compatible with this operating system.

  • Page 18: Step 4 Configure

    Networking Utility icon on the desktop screen. The Belkin Wireless Networking Utility screen will appear. Select a network to connect to from the “Available Networks” list and click “Connect”. Note: In order to see your available networks, you must be near a working wireless router or access point.

  • Page 19: Using The Belkin Wireless Networking Utility

    Windows System Tray To access the WNU, simply place your mouse pointer and right-click over the WNU icon on the Windows task tray. If the icon is not present, click on “Start > Programs > Belkin > Belkin Wireless Utility”.

  • Page 20: Network Status

    This window displays the available networks at the current location as well as their SSID, Signal Strength, Security Type, Channel, and Network Type. Lost Wireless Connection If the current wireless connection is lost, a window will pop up and the WNU will attempt to reconnect.

  • Page 21: Network Status And Solution Tips

    Network Status and Solution Tips To further understand the current Network Status, click “Open Wireless Utility”. The default screen will be the “Current Status” tab and the “Network Status” section determines which connections are good and/or faulty. The WNU also features a “Solution Tips” section that provides...

  • Page 22: Setting Wireless Network Profiles

    Using the Belkin Wireless Networking Utility Setting Wireless Network Profiles The “My Connections” tab on the WNU allows you to add, edit, and delete connection profiles. It also displays signal strength, security, and network type. Securing your Wi-Fi Network ®...
  • Page 23 Using the Belkin Wireless Networking Utility Using the Belkin Wireless Networking Utility Note: When you select a network using encryption, you will first see the simple security screen. Click the “Advanced” button to see other security options (below).
  • Page 24 Depending on the security level (64- or 128-bit), the user will be asked to input a 10- or 26- character hex key. A hex key is a combination of letters, a–f, and numbers, 0–9.
  • Page 25 For instance: AF 0F 4B C3 D4 = 64-bit WEP key C3 03 0F AF 0F 4B B2 C3 D4 4B C3 D4 E7 = 128-bit WEP key Write down the hex WEP key from your wireless router (or access point) and enter it manually into the hex WEP key table in your Card’s...
  • Page 26 Using the Belkin Wireless Networking Utility WPA is a new Wi-Fi standard that improves upon the security features of WEP. To use WPA security, the drivers and software of your wireless equipment must be upgraded to support it. These updates will be found on your wireless vendor’s website.

  • Page 27: Configuring Your Card To Use Security

    Configuring your Card to use Security At this point, you should already have your wireless router (or access point) set to use WPA or WEP. In order for you to gain wireless connection, you will need to set your N1 Wireless Desktop Card to use the same security settings.

  • Page 28: Wep Setup

    A hex (hexadecimal) key is a combination of numbers and letters from A–F and 0–9. For 64-bit WEP, you need to enter 10 hex keys. For instance: AF 0F 4B C3 D4 = 64-bit WEP key...
  • Page 29 A–F and 0–9. For 128-bit WEP, you need to enter 26 hex keys. For instance: C3 03 0F AF 0F 4B B2 C3 D4 4B C3 D4 E7 = 128-bit WEP key...
  • Page 30 Please record the key prior to applying changes in the wireless router (or access point). If you don’t remember the hex key, your client will be locked out of the wireless router (or access point).
  • Page 31 Using the Belkin Wireless Networking Utility WPA-PSK (no server) Choose this setting if your network does not use a radius server. WPA-PSK (no server) is typically used in home and small office networking. From the “Network Authentication” drop-down menu, select “WPA-PSK (no server)”.
  • Page 32 Using the Belkin Wireless Networking Utility Click “Save” to finish. You must now set all clients (network cards) to match these settings. Wireless Networking Utility Options The “Options” tab on the WNU provides the user the ability to customize his or her WNU settings.
  • Page 33 Using the Belkin Wireless Networking Utility Using the Belkin Wireless Networking Utility Wireless Networking Utility Help The WNU “Help” tab provides users with access to online and telephone support, a one-click check for software updates, and advanced diagnostic tools.
  • Page 34 Advanced Diagnostic Tools The “Advanced Diagnostic Tools” section is the central control panel for all the settings of the hardware and software components of the wireless network. It provides an array of tests and connectivity services to ensure optimal network performance.

  • Page 35: Troubleshooting

    Troubleshooting Troubleshooting I can’t connect to the Internet wirelessly. If you are unable to connect to the Internet from a wireless computer, please check the following items: Look at the lights on your wireless router. If you’re using a Belkin Wireless Router, the lights should be as follows: •...
  • Page 36 If the correct network name is not listed, check the SSID settings to see if they match. The SSID is case-sensitive and the spelling on each computer must be exactly the same in order for the Card to connect to the wireless router (or access point).
  • Page 37 Next, double-click on the icon named “setup.exe”. Power LED does not come ON; Card is not working. If the LED indicators are not ON, the problem may be that the Card is not connected or installed properly. Verify that the Card is plugged firmly into the CardBus slot of your computer.
  • Page 38 Troubleshooting Link LED is solid but I cannot connect to the Internet. If you have a signal but can’t get online or obtain an IP address, the problem may be that there is a mismatch between the encryption key settings in your computer and wireless router (or access point).
  • Page 39 Card’s connection. In the “Properties” dialog, select the “Configure” button on the “General” tab (Windows 98 users will have to select the Wireless Card in the list box and then click “Properties”), then choose the “Advanced” tab and select the rate property.
  • Page 40 The most common wireless networking standard, 802.11b, transmits information at 11Mbps; 802.11a and 802.11g work at 54Mbps; and draft 802.11n works at 108Mbps. See the chart on the next page for more detailed information.
  • Page 41 *Distance and connection speeds will vary depending on your networking environment. **This Card is compatible with products based on the same version of the draft 802.11n specifications and may require a software upgrade for best results.
  • Page 42 Troubleshooting Technical Support You can find technical support information at www.belkin.com/networking. If you want to contact technical support by phone, please call: US: 877-736-5771 Europe: 00 800 223 55 460 Australia: 1800 235 546 New Zealand: 0800 235 546 Singapore: 800 616 1790...

  • Page 43: Information

    Information Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 44 (except for shipping charges for the product). What is not covered by this warranty? All above warranties are null and void if the Belkin product is not provided to Belkin Corporation for inspection upon Belkin’s request at the sole expense of the purchaser, or if Belkin Corporation determines that the Belkin product has been improperly installed, altered in any way, or tampered with.
  • Page 45 Corporation, Belkin may designate, in its sole discretion, an equipment repair facility to inspect and estimate the cost to repair such equipment. The cost, if any, of shipping the equipment to and from such repair facility and of such estimate shall be borne solely by the purchaser. Damaged equipment must remain available for inspection until the claim is finalized.
  • Page 46 Information...
