Page 1 StorTrends/ ManageTrends® (Version 2.7) User’s Guide for the StorTrends 1300 Storage Appliance MAN-1300 03/14/08...
Page 2: Revision History
American Megatrends, Inc. All trademarks and trade names used in this document refer to either the entities claiming the marks and names or their products. American Megatrends, Inc. disclaims any proprietary interest in trademarks and trade names other than its own.
Page 3: Table Of Contents
Rack Mounting Considerations ....................9 Installing the System into a Rack ....................9 Identifying the Sections of the Rack Rails ................9 Installing the Inner Rails ......................10 Installing the Outer Rails ......................10 ...
Page 4 Step One: Power your system on ....................18 Step Two: Get the IP address ....................18 Step Three: Connecting to the StorTrends® Storage Appliance from another system ..... 18 Step Four: Logging on to the StorTrends® Storage Appliance ..........19 ...
Page 5 Connecting Data Cables ......................59 Connecting Power Cables ...................... 59 Connecting the Control Panel ....................59 Figure 5-1. Front Control Panel Header Pins (JF1) ............... 60 I/O Ports ............................. 60 Figure 5-2. Rear Panel I/O Ports .................... 60 ...
Page 6 Control Panel : System Settings..................... 89 Control Panel : System : Information Icon : System Information Page ........90 Control Panel : System : Information Icon : System H/W Health Information Page ....90 StorTrends® 1300 User’s Guide (StorTrends iTX version 2.7)
Page 7 Control Panel : Network Settings : TCP/IP Settings Page ........... 102 Control Panel : Network Settings : TCP/IP Settings Page : DHCP or Static IP Address ..103 Control Panel : Network Settings : TCP/IP Settings Page : Create Teaming ...... 106 ...
Page 8 Step 4 : Assign a SAN Target ....................149 Step 5 : Enable the Port of the Target on the Storage Appliance ........149 Step 6 : Enable iSNS on the Storage Appliance (optional) ..........149 ...
Page 9 Managing your Snap Assisted Pairs from the Replication Management page ....184 High Availability ........................186 Managing your High Availability Pair from the High Availability Management page .... 188 Replication Management ...................... 190 Replication Management : Create New Replication Wizard ..........190 ...
Page 10 Attach a Keyboard and Monitor .................... 229 Fully Boot into ManageTrends ..................... 229 Insert the StorTrends iTX Installation CD (with the build you want to upgrade to) ....230 Upgrade Procedure (using the Command Line Interface) ........... 230 ...
Page 11 CLI Command for Joining Synchronous Replications Pairs ..........255 Failover Operation ........................ 256 Synchronous Replication Failover – Before Failover in Original Secondary ....... 256 Synchronous Replication Failover – After Failover in Original Secondary ......256 CLI Command for Failover Operations of Synchronous Replication Pairs ......257 ...
Page 12 Figure 5:The Delta Snapshot Replication Technology behind Asynchronous Replication in StorTrends iTX ........................307 Figure 6: Deduplication and WAN Transfer Acceleration Management in StorTrends iTX . 308 Additional WAN Assists in Asynchronous Replication with StorTrends® ........ 309 ...
Page 13 Data ............................317 Delta Snaps .......................... 318 DHCP ........................... 318 Disaster Recovery Plan/Solution ..................318 Domain ..........................318 Domain Controller ........................ 318 Domain Name........................319 Ethernet ..........................319 Ethernet 802.2 ........................319 ...
Page 14 VSS ............................336 Volume ..........................337 WAN ............................. 337 WDS ............................. 337 WINS ............................ 337 WWN ............................ 337 XFS ............................337 Index ............................339 StorTrends® 1300 User’s Guide (StorTrends iTX version 2.7)
Page 15: Limited Warranty
Limited Warranty The buyer agrees that if this product proves to be defective, American Megatrends is only obligated to repair or replace this product at American Megatrends’ discretion according to the terms and conditions of the warranty registration card that accompanies this product.
Page 16: Disclaimer
(even if American Megatrends has been advised of the possibility of such damages).
Page 17: Product Compliance Information
The StorTrends 1300 chassis is compliant with the following safety standards/requirements: Electromagnetic Emissions FCC Class A, EN 55022 Class A, EN 61000-3-2/-3-3, CISPR 22 Class A Electromagnetic EN 55024/CISPR 24, (EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11)
Page 18 StorTrends® 1300 User’s Guide (StorTrends iTX version 2.7)
Page 19: Chapter 1 Introduction
(IP-SAN) and Network Attached Storage (NAS) on a single storage platform. The StorTrends 1300i supports iSCSI, enabling block applications like Microsoft® Exchange and Oracle® to be deployed or stored on the same server as traditional file services and storage. The StorTrends 1300i is designed with performance in mind, and includes features for enterprise-level storage management such as hardware RAID, advanced snapshots, volume replication and failover.
Page 20: Hardware Specifications
• Four (4) 3.5” Hot-swappable SAS / SATA Drive Bays • 250 GB, 500 GB or 1.0 TB capacity hard drives are supported, for 1.0 TB, 2.0 TB or 4.0 TB physical storage capacity per appliance Hardware RAID Support •...
Page 21: Cooling Specifications
Operating Temperature: 50 to 95˚F (10˚ to 35˚ C) • Operating Relative Humidity: 8% to 90% (non-cond.) Physical Characteristics • Dimensions: 1.7” (43 mm) H x 17.2” (437 mm) W x 25.6” (650 mm) D • Weight: 45 lbs. (20.4 kg) StorTrends® iTX Software Specifications: Volume Replication •...
Page 22: Isns Configuration
LUN dynamic volume expansion • Dynamic NAS volume expansion • Unified RAID Management • RAID levels 0, 1, 5, 6, 10, 10+ N, 50, 60 • Auto RAID rebuild Remote Management • SNMP, SMIS 1.1, VDS StorTrends® 1300 User’s Guide (StorTrends iTX version 2.7)
Page 23: Ups Support
UPS Support • Universal UPS Support; Supports Windows® OS/iTX/Linux as UPS slaves and many UPS makes and models Applications Supported • Oracle®, SQL, Microsoft® Exchange, VMware® and so on. Chapter One : Introduction...
Page 24 StorTrends® 1300 User’s Guide (StorTrends iTX version 2.7)
Page 25: Chapter 2 Chassis Set Up
You should inspect the box the StorTrends® 1300 Storage Appliance was shipped in and note if it was damaged in any way. If the server itself shows damage, you should file a damage claim with the carrier who delivered it.
Page 26: Preparing For Setup
Choosing a Setup Location • Leave enough clearance in front of the rack to enable you to open the front door completely (~25 inches). • Leave approximately 30 inches of clearance in the back of the rack to allow for sufficient airflow and ease in servicing.
Page 27: Rack Mounting Considerations
Two pairs of short brackets to be used on the front side of the outer rails are also included. Chapter Two : Chassis Set Up...
Page 28: Installing The Inner Rails
Begin by measuring the distance from the front rail to the rear rail of the rack. Attach a short bracket to the front side of the right outer rail and a long bracket to the rear side of the right outer rail. Adjust both the short and long brackets to the proper distance so that the rail can fit snugly into the rack.
Page 29: Locking Tabs
Locking Tabs Both chassis rails have a locking tab, which serves two functions. The first is to lock the server into place when installed and pushed fully into the rack, which is its normal position. Secondly, these tabs also lock the server in place when fully extended from the rack.
Page 30: Installing The Server Into The Rack
You should now have rails attached to both the chassis and the rack unit. The next step is to install the server into the rack. Do this by lining up the rear of the chassis rails with the front of the rack rails. Slide the chassis rails into the rack rails, keeping the pressure even on both sides (you may have to depress the locking tabs when inserting).
Page 31: Installing The Server Into A Telco Rack
Larger chassis should be positioned to balance the weight between the front and the back. If a bezel is included on your server, remove it. Attach the two front brackets to each side of the chassis, then the two rear brackets positioned with just enough space to accommodate the width of the Telco rack.
Page 32: Checking The Serverboard Setup
Checking the Serverboard Setup After you install the StorTrends 1300 in the rack, you will need to open the top cover to make sure the server board is properly installed and all the connections have been made. Step Description Step 1: Accessing the...
Page 33: Accessing The Inside Of The System
Accessing the Inside of the System Chapter Two : Chassis Set Up...
Page 34: Checking The Drive Bay Setup
Checking the Drive Bay Setup Next, you should check to make sure that the peripheral drives, the SATA drives and SATA backplane have been properly installed and all connections have been made. Step Description Step 1: Accessing the All drives are accessible from the front of the server. For servicing drive bays the DVDROM drive, you will need to remove the top chassis cover.
Page 35: Completing The Hardware Installation
Completing the Hardware Installation Next, you should check to make sure that all SAS drives have been properly inserted and have not come loose in transit. Step Description 1. Checking the drive All drives can be accessed from the front of the server. Verify that bays the hard disk drive trays are inserted all the way into their bay.
Page 36: Connect To The Stortrends® Appliance
Once the StorTrends® Storage Appliance is fully operational, you will see the following screen. Write down the IP Address listed in the “Ip Address” field. If you have both NICs connected to your network, there will be two IP Addresses.
Page 37: Step Four: Logging On To The Stortrends® Storage Appliance
Both the user name and password are case sensitive. StorTrends® iTX has a built in feature that logs you out in the event that it detects no activity for 20 minutes and will display a message that states, “Your session has expired.”...
Page 38: Using The Quick And Easy Setup Wizard
Email Alerts Settings. Once the Email Alerts Settings has been completed, you will be prompted to run the Wizard. The Quick and Easy Setup Wizard will get your Storage Appliance up and running in less than five minutes.
Page 39 Critical/Fatal Check this box to trigger an email notification to be sent whenever a critical or fatal event is recorded. A Critical or Fatal event can be an event such as a hard disk drive failure. Apply button To save changes, left click the Apply button.
Page 40: Step One: Quick Start Setup Wizard
Use the following instructions as a basis. Note: The Quick and Easy Setup Wizard will select all the physical hard disk drives present in the StorTrends® iTX Storage Appliance to create the RAID array. SAN and NAS volume names are automatically generated. A default NAS Share is also automatically created.
Page 41: Step Two: Raid Level
RAID 1 • RAID 5 This step will create a Logical disk and a storage pool from all the physical hard disk drives available in the system/controller with the RAID type you specify. Note: Once you select Next, you cannot come back to this step.
Page 42: Step Three: San Or Nas Or Both
Step Three: SAN or NAS or Both Once an array has been created in the box, you can select how you want to use your Storage Appliance. You are provided with the following options: • Only SAN • Only NAS •...
Page 43: Step Four: Allocating Space
Note: You can use the slider bar to adjust the size of each Volume type. If you have selected Only NAS or Only SAN, then you will only be able to adjust the slider for that type of Volume. Chapter Two : Chassis Set Up...
Page 44: Step Five: Summary View
Note: You can change the default names for volumes and containers at this point. Also note that uppercase characters are not allowed in target names. Additionally, if you are planning to use the snap-assisted replication feature, uppercase characters should be avoided in both the container and volume names.
Page 45 Do not close the window or click anywhere else until the operation completes. Chapter Two : Chassis Set Up...
Page 46: Step Six: All Done No Errors
Step Six: All Done No Errors STOP! YOU SHOULD NOW BE UP AND RUNNING. ALL THE OTHER SECTIONS CAN BE SKIPPED. StorTrends® 1300 User’s Guide (StorTrends iTX version 2.7)
Page 47: Using The Advanced Setup Wizard
The Advanced Setup Wizard allows you to have more control of the storage being configured. Step One: Advanced Wizard If the storage has not been configured on your Storage Appliance, you will be prompted to run the Wizard. Click the Advanced option and then click Next. Chapter Two : Chassis Set Up...
Page 48: Step Two: Create A New Storage Pool
Select Create new storage pool and then click Next. Note: The screen capture above is from a 3U unit. By default, the 1U units do not display this screen because the 1U units do not use hardware RAID. The 1U units only support RAID 0, RAID 1, RAID 5 and RAID 1n.
Page 49: Step Three: Select Pool
Step Three: Select Pool Select the Disks Select the Disks that you want to use in your Storage Pool. Chapter Two : Chassis Set Up...
Page 50: Set The Raid Levels
Note: The screen capture above is from a 3U unit. The 1U units only support RAID 0, RAID 1, RAID 5 and RAID 1n. However, if you install a hardware RAID controller, more RAID levels are displayed. Keep in mind that your hardware RAID controller may not be fully supported.
Page 51: Step Four: Configure San Volume
Step Four: Configure SAN Volume STOP! This section allows you to configure a SAN Volume and a SAN Target on to the Storage Appliance. If you have configured this storage appliance as a NAS Only unit, SKIP THIS STEP and go to Step Five: Configure NAS Volume.
Page 52: Enter Volume Name
Name must be alphanumeric, not have any spaces and be between one and 63 characters in length. Enter Volume Size In the Enter Volume Size field, enter the size that you want to use for your SAN Volume. The field is measured in Gigabytes GB. StorTrends® 1300 User’s Guide (StorTrends iTX version 2.7)
Page 53: Select Thin Or Exact Provisioning
For example, if the storage device has an actual physical size of 500 GB, the user can assign a size of up to 256 TB per box. Based on the consumption of the storage device’s physical capacity, more physical drive capacity can be added later as desired.
Page 54: Select San As The Dialect Type
Select SAN as the Dialect Type. Create Target and Target Name Place a check next to the Create New Target field. Enter a name for your Target. The Target Name must be alphanumeric, not have any spaces and be between one and 63 characters in length.
Page 55: Step Five: Configure Nas Volume
Step Five: Configure NAS Volume STOP! This section allows you to configure a NAS Volume and a NAS Share on to the Storage Appliance. If you only want to configure this storage appliance as a SAN Only unit, SKIP THIS STEP by clicking the Finish button and go to Step Six: Summary View and Status.
Page 56: Enter Volume Name
For example, if the storage device has an actual physical size of 500 GB, the user can assign a size of up to 256 TB per box. Based on the consumption of the storage device’s physical capacity, more physical drive capacity can be added later as desired.
Page 57: Select Nas As The Dialect Type
Create Share and Share Name Place a check next to Create New Share if you wish to create a NAS Share at this time, otherwise click the Add button and continue on to the next step. If you want to create a NAS Share now, in the Share Name field, enter a unique name for your NAS Share.
Page 58: Step Six: Summary View And Status
A summary will appear. Your Storage Appliance will be automatically configured based on the values that you have entered. Do not close the window or click anywhere else until the operation completes. StorTrends® 1300 User’s Guide (StorTrends iTX version 2.7)
Page 59: Step Seven: All Done No Errors
Step Seven: All Done No Errors STOP! YOU SHOULD NOW BE UP AND RUNNING. Chapter Two : Chassis Set Up...
Page 60 StorTrends® 1300 User’s Guide (StorTrends iTX version 2.7)
Page 61: Chapter 3 System Interface
System Interface Overview There are several LEDs on the control panel as well as others on the SATA drive carriers to keep you constantly informed of the overall status of the system as well as the activity and health of specific components.
Page 62: Control Panel Leds
Deactivating the UID LED must be performed in the same way it was activated. (If the UID LED was activated via IPMI, you can only turn the LED off via IPMI and not with the UID button.) StorTrends® 1300 User’s Guide (StorTrends iTX version 2.7)
Page 63: Sata Drive Carrier Leds
The SES2 compliant backplane activates the red LED to indicate a drive failure. If one of the SAS drives fail, you will be notified by the StorTrends iTX software. Replace the failed SAS drive(s).
Page 64 StorTrends® 1300 User’s Guide (StorTrends iTX version 2.7)
Page 65: Safety Information And Technical Specifications
• Be aware of the locations of the power on/off switch on the chassis as well as the room's emergency power-off switch, disconnection switch or electrical outlet. If an electrical accident occurs, you can then quickly remove power from the system.
Page 66: Installing The Onboard Battery
• Place the chassis top cover and any system components that have been removed away from the system or on a table so that they won't accidentally be stepped on. • While working on the system, do not wear loose clothing such as neckties and unbuttoned shirt sleeves, which can come into contact with electrical circuits or be pulled into a cooling fan.
Page 67: Esd Safety Guidelines
For proper cooling, make sure to install all chassis covers before turning on the system. If this rule is not strictly followed, warranty may become void. Do not open the casing of a power supply. Power supplies can only be accessed and serviced by a qualified technician of the manufacturer.
Page 68: Before Accessing The Chassis
3. Unplug all power cords from the system or the wall outlets. 4. Disconnect all the cables and label the cables for easy identification. 5. Use a grounded wrist strap designed to prevent static discharge when handling components. Removing the Chassis Cover After completing the above steps, you can remove the covers and install components/peripheral devices into the chassis as described in this user’s guide.
Page 69: Reinstalling The Chassis Covers
To reinstall the chassis covers, please follow the steps listed below: 1. Make sure that all components and devices are securely fastened on the chassis and there are no loose parts/screws inside the chassis.
Page 70 StorTrends® 1300 User’s Guide (StorTrends iTX version 2.7)
Page 71: Chapter 5 Advanced Serverboard Setup
Static electrical discharge can damage electronic components. To prevent damage to printed circuit boards, it is important to handle them very carefully. Also note that the size and weight of the server board can cause it to bend if handled improperly, which may result in damage. To prevent the server board from bending, keep one hand under the center of the board to support it when handling.
Page 72: Processor And Heatsink Installation (If Not Installed)
When purchasing a LGA 775 CPU or when receiving a server board with a CPU pre- installed, make sure that the CPU plastic cap is in place and none of the CPU pins are bent; otherwise, contact the retailer immediately.
Page 73 Action Read and understand all Warning, Caution, and Notes listed on the previous page. Disengage the Load Lever by pressing it down and then out from under the retention tab. Rotate the Load Lever to its fully open position. Rotate the Load Plate to its fully open position.
Page 74 Step Action Grasp the processor using only your thumb and index fingers at the edges of the processor. The Socket has been designed to allow room for your fingers to fit into. Carefully place the processor straight down into the socket body using a purely vertical motion.
Page 75: Installing The Heatsink
Step Action Place the heatsink on top of the CPU so that the four mounting holes are aligned with those on the (preinstalled) heatsink retention mechanism. Screw in two diagonal screws (for example, the #1 and the #2 screws) until just snug.
Page 76: Removing The Heatsink
Once the heatsink is loose, remove it from the CPU. Clean the surface of the CPU and the heatsink to get rid of the old thermal grease. Reapply the proper amount of thermal grease on the surface before you re-install the heatsink StorTrends®...
Page 77: Connecting Cables
All JF1 wires have been bundled into single keyed ribbon cable to simplify their connection. The red wire in the ribbon cable plugs into pin 1 of JF1. Connect the other end of the cable to the Control Panel printed circuit board, located just behind the system status LEDs in the chassis. See the Connector Definitions section for details and pin descriptions of JF1.
Page 78: Figure 5-1. Front Control Panel Header Pins (Jf1)
Figure 5-1. Front Control Panel Header Pins (JF1) I/O Ports The I/O ports are color coded in conformance with the PC 99 specification. Figure 5-2. Rear Panel I/O Ports StorTrends® 1300 User’s Guide (StorTrends iTX version 2.7)
Page 79: Installing Memory
DIMM slots. Populating two slots at a time (DIMM1A + DIMM1B, DIMM2A + DIMM2B, etc.) with memory modules of the same size and of the same type will result in dual-channel, interleaved memory which is faster than the single-channel, non- interleaved memory.
Page 80: Figure 5-3. Installing Dimm Into Slot
To Install: Insert module vertically and press down until it snaps into place. Pay attention to the bottom notch. To Remove: Use your thumbs to gently push each release tab outward to free the DIMM from the slot. Adding PCI Cards PCI Expansion Slots Two riser cards are used to support add-on cards to the system.
Page 81: Pci Card Installation
PCI card installation Before installing a PCI add-on card, make sure you install it into the correct riser card. Begin by releasing the locking tab that corresponds to the slot you wish to populate. Insert the expansion card into the correct riser card, pushing down with your thumbs evenly on both sides of the card.
Page 82: Serverboard Details
JPL2 JBT1 JPG1 ES1000 ICH7R USB2/3 SATA0 South Bridge SATA1 SATA2 SATA3 Intel 3010 North Bridge JLED LGA 775 FAN1 FAN5 FAN4 FAN3 Note: Jumpers not noted are for test purposes only. StorTrends® 1300 User’s Guide (StorTrends iTX version 2.7)
Page 83: Server Board Quick Reference
PWR-LED Power Ready LED Indicator *LE1: When this blue LED is on, either the control panel UID button or the back panel UID button has been pressed by the user to indicate the location of the unit. Chapter Five : Advanced Serverboard Setup...
Page 84: Connector Definitions
Pin Definition (JF1) Pin # Definition Control Ground Power LED The Power LED connection is located on pins 15 and 16 of JF1. Refer to the table on the right for pin definitions. Power LED Pin Definitions (JF1) Pin # Definition Control StorTrends®...
Page 85: Hdd Led
HDD LED The HDD (IDE Hard Disk Drive) LED connection is located on pins 13 and 14 of JF1. Attach the IDE hard drive LED cable to display disk activity. Refer to the table on the right for pin definitions.
Page 86: Power Fail Led
Power Fail LED The Power Fail LED connection is located on pins 5 and 6 of JF1. Refer to the table on the right for pin definitions. Power Fail LED Pin Definitions (JF1) Pin # Definition Ground Reset Button The Reset Button connection is located on pins 3 and 4 of JF1. Attach it to the hardware reset switch on the computer case.
Page 87: Universal Serial Bus Headers
Ground Ground Serial Ports The COM1 serial port is located on the IO backplane. COM2 is a header on the server board. Note: Pin 10 is included on the header but not on the port. NC indicates no connection. Serial Port...
Page 88: Chassis Intrusion
The speaker connector located at J9 allows you to choose between using the internal or an external speaker. For the internal speaker, jump pins 3 and 4. To use an external speaker, place the speaker cable header on all four pins.
Page 89: Wake-On-Ring
Wake-On-Ring The Wake-On-Ring header is designated JWOR. This function allows your computer to receive and "wakeup" by an incoming call to the modem when in suspend state. You must have a WOR card and cable to use this feature. Wake-On-Ring...
Page 90: Lan1/2 (Ethernet Ports)
To clear CMOS, 1. First power down the system and unplug the power cord(s) 2. With the power disconnected, short the CMOS pads with a metal object such as a small screwdriver 3. Remove the screwdriver (or shorting device) 4. Reconnect the power cord(s) and power on the system.
Page 91: Vga Enable/Disable
VGA Enable/Disable JPG1 allows you to enable or disable the VGA port. The default position is on pins 1 and 2 to enable VGA. LAN Enable/Disable Change the setting of jumper JPL1 or JPL2 to enable or disable the onboard Ethernet (RJ45) ports LAN1 and LAN2, respectively.
Page 92: Floppy, Ide And Sata Drive Connections
A red mark on a wire typically designates the location of pin 1. • A single floppy disk drive ribbon cable has 34 wires and two connectors to provide for two floppy disk drives. The connector with twisted wires always connects to drive A, and the connector that does not have twisted wires always connects to drive B.
Page 93: Chapter 6 Advanced Chassis Setup
If some steps are unnecessary, skip ahead to the next step. Tools Required The only tool you will need to install components and perform maintenance is a Philips screwdriver. Static-Sensitive Devices Electrostatic discharge (ESD) can damage electronic components. To prevent damage to any printed circuit boards (PCBs), it is important to handle them very carefully.
Page 94: Control Panel
Ethernet Ports Control Panel The control panel (located on the front of the chassis) must be connected to the JF1 connector on the server board to provide you with system status indications. These wires have been bundled together as a ribbon cable to simplify the connection. Connect the cable from JF1 on the server board to the appropriate header on the Control Panel PCB (printed circuit board).
Page 95: System Fan Failure
Replace any failed fan at your earliest convenience with the same type and model (the system can continue to run with a failed fan). Remove the top chassis cover while the system is still running to determine which of the fans has failed.
Page 96: Sata Drive Installation
To add a new drive, install a drive into the carrier with the printed circuit board side facing down so that the mounting holes align with those in the carrier. Secure the drive to the carrier with six screws, as shown in Figure 6-4.
Page 97: Figure 6-5. Removing A Sata Drive From The Server
With the chassis cover removed, unplug the power and data cables from the drive you want to remove. Then locate the locking tab at the rear of the drive. It will be on the left side of the drive when viewed from the front of the chassis. Pull the tab away from the drive and push the drive unit out the front of the chassis.
Page 98: Power Supply
First unplug the power cord from the failed power supply module. To remove the failed power module, push the release tab (on the back of the power supply) to the side and then pull the module straight out. The power supply wiring was designed to detach automatically when the module is pulled from the chassis.
Page 99: Removing/Replacing The Power Supply
Removing/Replacing the Power Supply Removing the power supply First turn the power switch on the control panel off, then unplug the power cord from the system. Replace with the same model (p/n PWS-561-1H20). To remove the failed power module, first remove the screws that secure the power supply to the chassis.
Page 100 StorTrends® 1300 User’s Guide (StorTrends iTX version 2.7)
Page 101: Chapter 7 Managing The Storage Appliance
Connecting to the Storage Appliance from another system Type the IP Address of the Storage Appliance into your Internet Browser. (Microsoft Internet Explorer 6.0 Service Pack 1 and Mozilla Firefox 1.5.04 or later are supported) Chapter Seven : Managing the Storage Appliance...
Page 102: Logging On To The Storage Appliance
Logging on to the Storage Appliance You will be prompted to provide a username and password before you can gain access to it. Enter your username and password. Default user name: itxadmin Default password: password Note: When you login using the default itxadmin password, you have full administrative powers.
Page 103: Managetrends Hardware Health Information
ManageTrends Hardware Health Information On the top bar there is a health icon. Click on the Hardware Heath icon to view the Hardware Health Information screen. This page displays all information relevant to the hardware health of your ManageTrends box. Here you can view the current status of the system’s fans, temperatures and server board voltages.
Page 104: Managetrends Management Tree
ManageTrends® provides you with capacity growth trends. This allows you to plan for additional storage purchases ahead of time. At the heart of StorTrends® stack is a very powerful SRM module that takes care of Trending, Analysis and Reporting.
Page 105 XML aware application. For example, Microsoft® Office® Excel® program. Save as Text button This button allows you to export the event log as a plain text file so that you can view it in a standard word processor application.
Page 106: Control Panel
Control Panel StorTrends® 1300 User’s Guide (StorTrends iTX version 2.7)
Page 107: Control Panel : System Settings
Status of the Storage Appliance and of many of its individual components. Date and Time The Date and Time Settings page displays the Time Zone, Server Date, Server Time, NTP Configuration, and NTP server information. This page also has a Synchronize With Local System button.
Page 108: Control Panel : System : Information Icon : System Information Page
Control Panel : System : Information Icon : System H/W Health Information Page The System Hardware Health Information page displays the System Temperature, fan speed and Drive Status for the Storage Appliance. You can mouse over the icon of an individual part to view its health status.
Page 109: Control Panel : System : Information Icon : Date/Time Settings Page
Type your network’s NTP server’s FQDN or IP address into this field. Synchronize with Use this button to set the Storage Appliance’s time to be the same as that of the system Local System button being used to access the Storage Appliance.
Page 110: Control Panel : System : Information Icon : Update Stortrends Itx Software Page
Control Panel : System : Information Icon : Update StorTrends iTX software Page The Update StorTrends software page allows you to upgrade the StorTrends software. This page displays input boxes for the FTP Address, Path, Username and Password. Field/Item Description FTP Address Type your FTP server name or IP address into this field.
Page 111: Control Panel : System : Information Icon : System Control Page
Control Panel : System : Information Icon : System Control Page This page allows you to shutdown or reboot your Storage Appliance. Select the appropriate button. You also have the option to allow the Storage Appliance to shutdown automatically on critically high temperatures.
Page 112: Control Panel : System : Information Icon : Ups Configuration Page
This field displays the remaining minutes of power. Mode This field allows you to select the mode for the system that you are connecting to the UPS. For example, the Master system is the system that is connected directly to the UPS via serial cable or USB cable.
Page 113: Control Panel : Themes
Control Panel : Themes Allows you to use different color configurations for the GUI. Control Panel : Themes : Red Control Panel : Themes : Olive Green Chapter Seven : Managing the Storage Appliance...
Page 114: Control Panel : Themes : Blue
Control Panel : Themes : Blue Note: You must clear the cache on your Internet browser in order to see the new theme. StorTrends® 1300 User’s Guide (StorTrends iTX version 2.7)
Page 115: Control Panel : Network Settings
Community Name. Default community name is public. Firewall The Firewall Settings: Allowed/Blocked Sites page allows you to Add, Delete and Modify allowed or blocked sites. This page allows you to input the Start IP, Start Port, Protocol, Subnet Mask and End Port. File Protocols The File Protocols page allows you to pick from Windows, Unix, Apple or HTTP/FTP protocols.
Page 116: Control Panel : Network Settings : Network Statistics Page
MTU by comparing MTUs and selecting the smaller of the two. Interface Link Status This field allows you to see the link status of the network adapters. The link can be either UP or DOWN. StorTrends® 1300 User’s Guide (StorTrends iTX version 2.7)
Page 117: Control Panel : Network Settings : Network Statistics Page : Receiving Details
Bad Packets Received This field reports the number of bad packets received. In other words, a bad frame that was marked as an error by PHY. Control Panel : Network Settings : Network Statistics Page : Transmission Details...
Page 118: Control Panel : Network Settings : Network Statistics Page : Receiving Errors
(Receiver ring buff overflows errors) CRC Errors CRC stands for Cyclic Redundancy Check. A CRC can be used in the same way as a checksum to detect accidental alteration of data during transmission or storage. CRCs are...
Page 119: Control Panel : Network Settings : Network Statistics Page : Transmission Errors
Failure to do so may indicate that the link has failed or that the PHY has an incorrect link configuration. This register only increments if transmits are enabled. This register is not valid in internal SerDes1 mode (TBI mode for the 82544GC/EI) and is only valid when the Ethernet controller is operating at full duplex.
Page 120: Control Panel : Network Settings : Tcp/Ip Settings Page
Control Panel : Network Settings : TCP/IP Settings Page Use this page to view or update the TCP/IP settings for the network interfaces on the Storage Appliance. Simply select the network interface from the dropdown menu that you want to configure or view.
Page 121: Control Panel : Network Settings : Tcp/Ip Settings Page : Dhcp Or Static Ip Address
Control Panel : Network Settings : TCP/IP Settings Page : DHCP or Static IP Address DHCP or Static Description Obtain IP and DNS By default the TCP/IP setting is set to obtain an IP Address and DNS server address from Server Addresses a DHCP server. Automatically...
Page 122 This dropdown menu allows you to select the NIC to configure (if applicable). Interface dropdown menu Obtain IP and DNS By default the TCP/IP setting is set to obtain an IP Address and DNS server address from Server Addresses a DHCP server. Automatically...
Page 123 Press the <ENTER> key to continue. This field must have an entry and cannot be left blank. If you do not have a primary DNS installed on your network, enter 0.0.0.0 for the value of this field.
Page 124: Control Panel : Network Settings : Tcp/Ip Settings Page : Create Teaming
Balance TLB (Transmit Load Balance) Note: Whether you choose NIC-1 or NIC-2 as the primary NIC, the IP address of the network team will be that previously assigned to NIC-1. Control Panel : Network Settings : TCP/IP Settings Page : Create Teaming : Balance Round Robin This option transmits packets in sequential order from the first available slave-NIC in the team through the last.
Page 125: Control Panel : Network Settings : Snmp Protocol Settings Page
Community Name Enter the community name that your network uses. A community name is a secret identity based on plain-text that is used to authenticate queries to agents of managed network devices. A read-only community name allows systems to gather statistics from your SNMP device. The most commonly used community name is public.
Page 126: Control Panel : Network Settings : Firewall Settings Page
IP addresses to block or allow. You can also specify which ports and protocol to block or allow. By default the Blocked Sites page is displayed. If it is not, left click the Blocked Sites link to enter a range of IP addresses that you want to block.
Page 127 Left click the Trusted Sites link to enter a range of IP addresses that you want to always allow. Field/Item Description Start IP Address This field allows you to enter the start address of the subnet you want to either block or always allow.
Page 128: Control Panel : Network Settings : Firewall Settings Page : Modifying
Control Panel : Network Settings : Firewall Settings Page : Modifying You can edit any of the IP address ranges by selecting the IP address range from the main Firewall window. You can enter your adjustments and left clicking on the Modify button for the changes to take effect.
Page 129: Control Panel : Network Settings : File Protocols Settings Page : Set Windows File Protocol Page
Microsoft® CIFS is a proposed standard protocol that allows programs to make requests for files and services on remote systems running Microsoft Windows operating systems on the Internet. Note: If you navigate away from the Set Windows File Protocol page or it did not appear first, click the Windows link. Field/Item Description WINS Address Type the WINS server’s IP address into this field.
Page 130: Disable Windows File Server Protocol (Cifs)
Disable Windows File Server Protocol (CIFS) If you want to change the settings, you must disable CIFS first. To disable the Windows File Server Protocol (CIFS), left click the Disable button. Enable Windows File Server Protocol (CIFS) Complete all the fields and then, to enable the Windows File Server Protocol (CIFS), left click the Enable button.
Page 131: Control Panel : Network Settings : File Protocols Settings Page : Set Network File System (Nfs) Protocol Page
Control Panel : Network Settings : File Protocols Settings Page : Set Network File System (NFS) Protocol Page To access the Set Network File System (NFS) Protocol page, click the NFS link. Field/Item Description Enable Set Network File Left click this box to enable NFS.
Page 132: Control Panel : Network Settings : File Protocols Settings Page : Set Apple File Protocol Page
Control Panel : Network Settings : File Protocols Settings Page : Set Apple File Protocol Page To access the Set Apple File Protocol page, click the Apple link. Field/Item Description Enable Apple File Left click this box to enable AFP.
Page 133: Control Panel : Network Settings : File Protocols Settings Page : Set Http/Ftp File Protocol Page
Control Panel : Network Settings : File Protocols Settings Page : Set HTTP/FTP File Protocol Page To access the Set HTTP/FTP File Protocol page, click the HTTP/FTP link. Field/Item Description Enable HTTP Sharing Left click this box to enable HTTP sharing.
Page 134: Control Panel : Users And Groups Settings
Secondary Server Name/IP, Organizational Unit, Admin Name and Admin Password. The NIS Settings page allows you to Enable NIS and to Add or Remove to or from the IP Address List. This page displays the Domain Name, IP Address List.
Page 135: Control Panel : Users And Groups Settings : Users List Page
This button allows you to remove a user. Properties button This button allows you to view and edit the properties of a user. For example, you can change the password and/or change the Full Name of the user. You will not be able to change the User Name (Login Name).
Page 136: Create New User
Full permissions to local access. If you do not have a specific group or do not want to add this user to a group, simply skip that step. Type in a password for the user and then confirm it by typing it in again in the Confirm Password field.
Page 137: Removing A User
Removing a User To delete a user, highlight their name and click the Remove button. After you confirm that you really want to remove the user, the list will refresh and a message will appear stating that the “User successfully deleted.”...
Page 138: Control Panel : Users And Groups Settings : Groups List Page
Control Panel : Users and Groups Settings : Groups List Page The Groups List page displays the Total Number of Groups, the Group Name, Group ID and the Type. This page allows you to Create New groups and Remove groups. This page also allows you to change Group Properties.
Page 139: Create New Group
To create a new group, simply click the Create New button. The Create New Group page opens. It is very intuitive and easy to use. Simply, type in a Group Name (one word). Select the user(s) you want to be a part of the Group.
Page 140: Removing A Group
Removing a Group To delete a Group, highlight the Group Name and click the Remove button. After you confirm that you really want to remove the Group, the list will refresh and a message will appear stating that the “Group successfully deleted.”...
Page 141: Control Panel : Users And Groups Settings : Ads Settings Page
Control Panel : Users and Groups Settings : ADS Settings Page The ADS Settings page allows you to Enable ADS. This page has fields for the Workgroup/Domain Name, Pre-Windows 2000 Domain Name, Primary Server Name/IP, Secondary Server Name/IP, Organizational Unit, Admin Name and Admin Password.
Page 142 Server Name/IP Type the Host Name or IP Address of the Active Directory® Services server into this field. Select if the Host Name or IP Address is that of an Active Directory®, Microsoft® Windows® NT 4.0 Domain or Workgroup. Note: That the secondary Server Name/IP is optional.
Page 143: Control Panel : Users And Groups Settings : Nis Settings Page
Below become editable when this option is selected. IP Address Type the IP address for the NIS server in the system and left click the Add to the List button. IP Address List The IP address for each NIS server in the system that you have entered is listed in this field.
Page 144: Control Panel : Iscsi
Icon Description ISNS The ISNS Setting page allows you to enable/disable the ISNS service and set an alias name. This page also allows you to configure support for Multiple ISNS servers. Portals The iSCSI- Portal Settings page allows you to Enable iSCSI Service and the Portal(s).
Page 145: Control Panel : Iscsi Settings : Isns Setting Page
This field displays the Alias name. This is configurable. ISNS Server IP field This field allows you to enter the IP address of an ISNS server that you want to add to the ISNS server IP list, thereby registering the StorTrends iTX server appliance with that server.
Page 146: Control Panel : Iscsi Portal Settings Page
This is a list of the system’s ports with their accompanying Port, Target IP Address, section Portal Tag and Status information. You can click on a port to enable or disable it. You can also modify the Portal Tag value (you must disable the portal before changing its tag).
Page 147: Control Panel : Iscsi Portal Settings Page : Advanced Page
This field allows you to set the immediate data value option. The default value for this field is Yes. Initial R2T field This field allows you to set the initial R2T value option. The default value for this field is Apply button Use this button to save changes and make the changes active.
Page 148: Control Panel : Iscsi : Statistics Page
The Target Statistics page displays the Device Statistics and the Error Statistics. Field/Item Description Device Statistics This list contains sent and received statistical information for SCSI payload, iSCSI PDUs, and iSCSI PDU bytes. Error Statistics This list contains count statistical information for failed login attempts, failed sessions, failed header digest sessions, and failed format error sessions.
Page 149: Control Panel : Iscsi : Iscsi Session Management Page
The iSCSI Session Management page displays the Session List. Field/Item Description Session List This list allows you to view active sessions. It also allows you to terminate any of the listed sessions. Terminate button Use this button to terminate a selected session.
Page 150: Control Panel : Iscsi : Bi-Directional Authentication Page
The Bi-directional Authentication page displays the Initiators List gathered from those iSNS servers that this box has registered with or you can enter the name of an iSCSI initiator or username and password, manually if you are not using iSNS.
Page 151: Control Panel : Alerts Settings
SNMP Traps The SNMP Alert Settings page allows you to Enable SNMP Alert Notifications. This page also allows you to input the Community Name, Target IP. This page allows you to select the alert types which are to trigger SNMP notifications.
Page 152: Control Panel : Alerts : Snmp Alert Settings Page
Critical/Fatal box Check this box to trigger an SNMP alert notification to be sent whenever a critical or fatal event is recorded. A Critical or Fatal event can be an event such as a hard disk drive failure. Apply button To save changes, left click the Apply button.
Page 153: Control Panel : Alerts: Email Alert Settings Page
Critical/Fatal Check this box to trigger an email notification to be sent whenever a critical or fatal event is recorded. A Critical or Fatal event can be an event such as a hard disk drive failure. Apply button To save changes, left click the Apply button.
Page 154: Control Panel : License Settings
Control Panel : License Settings Icon Description Update License The License Information page allows you to view/update the license for the Storage Appliance. StorTrends® 1300 User’s Guide (StorTrends iTX version 2.7)
Page 155: Control Panel : License Settings : License Information Page
After your changes have been processed by an AMI Support Representative, you’ll receive a new license key in the form of a text document. After you save the new key to a location on your hard drive, use the Browse button to navigate to the location of that file, and then simply select the Update License button to complete the process.
Page 156: Raid Management
RAID Management Allows you to configure RAID arrays using Software RAID or supported H/W RAID controllers. Physical Disks Management The Physical Disks Management page displays all physical disks attached to the RAID controller. Note: Click the Rescan button to refresh the information on this screen.
Page 157: Global Spare
This field displays whether or not the physical disk is being used as a Global Spare. In Use This field displays if the physical disk is available or is being used as part of a Volume. Status This field displays the status of the physical disk. The physical disk status can be in any of...
Page 158: Disk Properties
Slot Index This field displays the slot index number of the physical disk. Disk Type This field displays the type of physical disk is being used, such as SCSI, IDE, SATA and so on. Spare Type This field displays the type of spare that the physical disk is being used as (global, distributed or dedicated).
Page 159: Logical Disk Management
RAID Level This field displays the type of RAID array of the Logical Disk. Status This field displays the status of the physical disk. The physical disk status can be in any of the following states: Initializing The Logical Disk is being initialized.
Page 160: Logical Disk Properties
RAID Level This field displays the type of RAID array of the Logical Disk. Logical Device Status This field displays the status of the physical disk. The physical disk status can be in any of the following states: Initializing The Logical Disk is being initialized.
Page 161 Physical Disks This field displays all the physical disks involved in this Logical Disk. The physical Port Involved location of the physical disk on the Controller and on which Controller it is attached to is displayed. Blink Disk button Clicking on this button will cause the physical disks involved in this LD to blink.
Page 162: Deleting A Logical Disk
Select this option to transform the Logical Disk from one raid level to another. Name This field displays the name of the Logical Device name. Status This field displays the status of the logical disk. The disk can be in any of the following states: Initializing The Logical Disk is being initialized.
Page 163 Field Description RAID Level This field displays the type of RAID array of the Logical Disk. If you are transforming the Logical Disk, you can modify the RAID Level. Organized as This field displays how the Logical Disk is organized.
Page 164: Storage
The iSCSI protocol increases the capabilities and performance of storage data transmissions. Because of the wide use of IP networks, iSCSI can be used to transmit data over LANs, WANs, or the Internet and can enable location-independent data storage and retrieval.
Page 165: Iscsi Name
Select the type of Cache you want to use for the RAID array in the Cache Option drop down menu. Use the drop down menu in this step to select the cache level (such as Read, Read/Write, Write Back, or No Cache).
Page 166: Step 2 : Create A Storage Pool
Logical Disks. Click on the Create Storage Pool link. In the Enter Storage Pool Name field, select a LD from the list, and then enter a name for your Storage Pool. The Storage Pool Name must be alphanumeric, not have any spaces and be between one and 63 characters in length.
Page 167: Step 4 : Assign A San Target
SAN Target. Click on the iSCSI icon located under the Control Panel node. Select the Portals icon. Select the IP Address of the port that you want to Enable, enter a new portal tag if desired, click on the Enable Portal checkbox, and left click the Apply button.
Page 168: Step 7 : Log Onto The Target From The Server
Description From the application server, open the Microsoft Initiator application. Left click the Available Targets or Targets tab and left click the Refresh button. The Target appears in the Select a Target field. StorTrends® 1300 User’s Guide (StorTrends iTX version 2.7)
Page 169 Step Description Select the Target that you want to log on to. Notice that the Status of the Target is Inactive. Left click the Log On button. Note: If the Target does not appear in the list, try the following: •...
Page 170 If you are using a different initiator (list of supported initiators is available from AMI), then the procedure will differ according to that particular software/hardware’s specifications. The procedure to log on will also differ if you are using selective access to the LUN, for example, CHAP or persistent targets option.
Page 171: Step 8 : Verify The Target Using Disk Management On The Server
Open Disk Management from the Computer Management utility in your Microsoft Windows operating system hosting your initiator software. The Target is listed as one of the local disks and can be initialized and formatted as if it were a local hard disk drive.
Page 172: Step 9 : Create Nas Volume
For example, if the storage device has an actual physical size of 500 GB, the user can assign a virtual size of up to 256 TB. Based on the consumption of the storage device’s physical capacity, more physical drive capacity can then be added later.
Page 173: Step 10 : Create A Nas Share
63 characters in length. Type a description of the NAS Share in the Description field. This step is optional. In the Folder Path field, type in the path you want to share. You can also Browse to the desired Volume or Folder.
Page 174: Step 11 : Schedule Snapshots
This is typically accomplished by splitting a mirrored set of disks or creating a copy of a disk block when it is written, preserving the original. At restore time, the original is made available immediately, resulting in almost instantaneous restores.
Page 175: Storage : Storage Pool Management
Physical Capacity This field displays the physical size of the Storage Pool in GB. Add Logical Disk Click on this button if you wish to expand your container by adding one or more existing Logical Disks to it. Logical Disks Name This field displays the name of the Storage Pool.
Page 176: Storage : San Volume Management
Storage : SAN Volume Management This page appears if you click on any existing Pool and then on an existing SAN Volume. This page displays SAN Volume information and Target information. It also allows you to Delete or Expand Volumes, schedule snapshots and disable/enable advanced caching.
Page 177: Storage : Snapshot Recovery
The Snapshot Timescape window will appear. Here you can cycle through the available Snapshot. Click the Review link to display the Target Information of the Snapshot so that you can configure your initiator and review its contents. Once you click the Review link, the Snapshot Target Information will display in the lower left corner of the window.
Page 178: Storage : San Snapshot Management
Storage : SAN Snapshot Management This page appears if you click on any existing Pool and then on an existing SAN Volume and Snapshot Node. This page displays a list of all the snapshots of the selected Volume. Field/Button Description Snapshot Name This field displays the name of the Snapshot.
Page 179: Storage : Continuous Data Protection (Cdp)
Time Addressable Storage (TAS) as well as Event Addressable Storage (EAS). So all volumes / volume groups that have been enabled for Journaling will be available for CDP. Besides, the CDP UI provides a way to consistently review and recover volumes of a Consistency group.
Page 180: Storage : Continuous Data Protection (Cdp) : Cdp Control Window
CDP. Note that the above list of CGs / Volumes pertains only to the currently selected container. If you want to perform a CDP on a different CG / Volume, you need to go back and select the corresponding container.
Page 181: Storage : Continuous Data Protection (Cdp) : Cdp Flashback Window - Log View
The ‘Time Slider Panel’ shows graphically, the events and snapshots that are journaled. The slider (1) can be dragged to any point on the line with a resolution of 1 second. The red dots represent snapshots and the blue dots represent events that were logged. The orange region prior to the first snapshot indicates a zone where journal data is not available.
Page 182: Storage : Continuous Data Protection (Cdp) : Time Step Control Panel
The Main control panel displays the snapshot (1), event (2) and time (3) controls. The Time control increments the time by a default value of 1 sec. This time step can be changed from the ‘Time Step Control Panel’. The number of IO’s to be performed can also be specified in this panel.
Page 183: Storage : Continuous Data Protection (Cdp) : Snapshot Based Sliding
Storage : Continuous Data Protection (CDP) : Snapshot based sliding This screen shows an example of using the Snapshot Control. Pressing the left and right button moves the slider from one snapshot to another. Storage : Continuous Data Protection (CDP) : Time based sliding This screen show sliding using time control.
Page 184: Storage : Continuous Data Protection (Cdp) : Event Based Sliding
Another view for this window is the ‘Event View’ which is revealed by clicking on ‘Event View’ on the left corner of the Flashback window. The CDP utility makes a note of three different types of events taking place in the system: (a) Snapshots (b) Application events and (c) Windows events.
Page 185: Storage : Continuous Data Protection (Cdp) : Event Description
Storage : Continuous Data Protection (CDP) : Event Description This view enables the user to choose an event to review and rollback. We can switch between the Log and Event Views by clicking on the appropriate button on the left-hand corner of the window.
Page 186: Storage : Continuous Data Protection (Cdp) : Completion Of Review
Storage : Continuous Data Protection (CDP) : Completion of Review When a review is successfully completed, a writeable image of the volume at the given time instant is provided for review. If a CG is being reviewed, a single target with all consistent volumes as LUN is created.
Page 187: Storage : Continuous Data Protection (Cdp) : Retrospect Window
Each flying window represents a consistent snap group taken across all the volumes of the CG. For a SAN CG, this is achieved using the VSS Scheduler and for a NAS CG, the NAS scheduler does the job. The scroll buttons can be used to access any snapshot.
Page 188: Storage : Continuous Data Protection (Cdp) : Reviewing Snapshots
Connect your application server (Microsoft® Exchange, SQL and so on) to this image and perform a consistency check to make sure that this is the image you wish to rollback. Once you are satisfied, logout of the target and perform a rollback operation. If you are not satisfied, logout and choose another review snapshot and review again.
Page 189: Storage : Nas Volume Management
Note: You can also set default storage allocations for all new users by placing a check in the box next to “Set default quota for new users” and entering the size of the storage quota in MBs. Chapter Seven : Managing the Storage Appliance 171...
Page 190: Storage : Nas Share Management
This section allows you to modify the share access for the different types of clients. Folder/Volume Simply place a check next to the clients that you want this folder to be shared for. Click on Apply Storage : NAS Share Management : Security Settings This page allows you to control the permissions for individual users accessing the share.
Page 191: Storage : Shares
Everyone group for the selected share. Storage : Target Management To view a list of all targets for this iTX device, click on the Targets header in the navigation tree, under Storage. This page displays a list of targets that are available on this Storage Appliance, along with their connection and status information.
Page 192: Replication
The term, replication, is used in this document to describe the process of maintaining a redundant storage area network (SAN) volume. Replication Feature Table This is a table that lists the options and limitations of each of the available Replication Types. Replication Type...
Page 193: Synchronous Local San Volume Replication
Synchronous Local SAN Volume Replication This illustration shows replication taking place on the same box. Chapter Seven : Managing the Storage Appliance 175...
Page 194: Synchronous San Volume Replication Using A Remote Box
Synchronous SAN Volume Replication using a Remote Box This illustration shows volume replication using two separate boxes. StorTrends® 1300 User’s Guide (StorTrends iTX version 2.7)
Page 195: Creating A New Synchronous Replication Pair
Navigate to the Replication link in the tree menu. The Create Replication Wizard opens. Select the IP Address of the Primary box. The Primary box is the system where the Volume that you want to replicate is located. Chapter Seven : Managing the Storage Appliance 177...
Page 196 If you have selected the Remote Replication option, you must enter the access information for the remote box. You can type the IP Address into the Enter Remote Server Address field or select it from the drop down menu next to the ‘or select remote server’ option.
Page 197: Managing Your Synchronous Replication Pair From The Replication Management Page
Remote Host (such as the case when using DHCP), you can update the new IP Address by typing it into this field. In the case of a local replication pair (involving two volumes in the same local box, this column will show “local”.
Page 198 Button Description Join Joining allows you to join a split replication pair. Meaning that if you split a replication pair, this allows you to reestablish the connection between the local and remote Storage Appliances. Split Splitting allows you to temporarily disconnect a replication pair. Splitting basically means that you are breaking the connection between the remote and local Storage Appliances.
Page 199: Creating A New Snap Assisted Replication Pair
This section describes how to create a new Snap Assisted Replication (SAR) Pair using the Create Replication Wizard. Note: You must have Snapshots scheduled for the Volumes that are involved in the SAR pair before Snap Assisted Replication can function properly. Step Action Navigate to the Replication link in the tree menu.
Page 200 Select the Secondary Volume location from the drop down menu associated with the Volume that you have selected. If no Volume is configured on the Secondary box, you will have the option to have the wizard create a new Volume automatically. The wizard requires a couple of extra steps to create a new Volume.
Page 201 Skip this step if you are not configuring a SAN Volume replication onto a new Volume. This step is the same for configuring both a SAN Volume and NAS Volume, except that no Target Name is required for NAS Volumes and is therefore not displayed as an option.
Page 202: Managing Your Snap Assisted Pairs From The Replication Management Page
Local Volume, Remote Volume, Remote Host, Role, Link Status and Pairs Table Synchronization Percent. Consistency Group This is the name of the group containing the 1 or more volumes that are part of replication name pairs that replicate at the same time. Local/Remote Pool This field displays the pair’s Local and Remote Storage Pools respectively.
Page 203 Button Description Join Joining allows you to join a split replication pair. Meaning that if you split a replication pair, this allows you to reestablish the connection between the local and remote Storage Appliances. Split Splitting allows you to temporarily disconnect a replication pair. Splitting basically means that you are breaking the connection between the remote and local Storage Appliances.
Page 204: High Availability
In the event of Node failure, the Failover action is automatic and seamless. When the Failed node comes up, it is detected by the stack and is synchronized quickly to bring back redundancy to the setup. Synchronization is very efficient and ensures that only out-of-sync data is resynced.
Page 205 Navigate to the Replication link in the tree menu. The Create Replication Wizard opens. Select the IP Address of the Primary box. The Primary box is the where the Volume that you want to replicate is located. Select High Availability using iSCSI Mirror option under the Secondary Server option. Remember that for...
Page 206: Managing Your High Availability Pair From The High Availability Management Page
High Availability the remote server must be a separate box and must have the exact same specifications of the primary box. You must type the IP Address into the Enter Remote Server Address field or select it from the drop down menu next to the ‘or select remote server’ option.
Page 207 Button Description Join Joining allows you to join a split replication pair. Meaning that if you split a replication pair, this allows you to reestablish the connection between the local and remote Storage Appliances. Split Splitting allows you to temporarily disconnect a replication pair. Splitting basically means that you are breaking the connection between the remote and local Storage Appliances.
Page 208: Replication Management
Remote Host (such as the case when using DHCP), you can update the new IP Address by typing it into this field. In the case of a local replication pair (involving two volumes in the same local box, this column will show “local”.
Page 209: Replication Management : Create New Replication
Appliance ships with two NICs, so there should only be two IP Addresses in this field unless you have installed another NIC. Next, select a SAN Volume that you want to replicate from the table. The table displays a list of Volumes on the primary Storage Appliance.
Page 210: Storage Resource Management (Srm)
This makes it very easy to extend SRM to cover a bigger and wider range of attributes without having to redesign it from scratch. The key kernel component is the data collection agent that interfaces with other modules to collect instantaneous data about all monitored resources.
Page 211: Storage Provisioning And Capacity Management
StorTrends iTX, with its Thin-provisioning architecture, takes this headache out. Once the initial hurdle is crossed, the next big and persistent problem a storage administrator faces is to take an inventory of what is present today and predicting how much of growth is anticipated over the next few months, year or even beyond.
Page 212: Performance Trending
In-depth analysis of the instantaneous read and writes performance values. It gives the user information about the contributions of different I/O sizes towards the total I/O activity going on at the moment. The I/O sizes chosen are 512 byte, 4K, 8K and 64K reads or writes.
Page 213: Cpu Utilization And Memory Utilization
StorTrends, with Tiered Storage and three-level space mapping, ensures that snapshots are maintained in the most capacity-optimized manner. The next is to ensure that the so- called Recovery Images are indeed consistent and good.
Page 214: Information Lifecycle Management (Ilm) And Container Space Management (Csm)
According to research conducted by the TheInfoPro Group (TIP), the interest in ILM over the last 18 months has heated up. The TIP heat index for ILM, which was four (in order of priority) in Spring 2005, has moved to one by Spring of 2006.
Page 215: Basic Concepts
A group of logical drives belonging to the same container but have the same costs. The cost is calculated based on the RAID level, type of drives and so on. A container may contain multiple tiers, and a tier may contain multiple LDs. The following diagram gives a pictorial description about the relationship between a Logical Drive, a Container and a Tier.
Page 216 Information Retention Regulations) to retain emails for an extended period will result in messages and data to be scattered all over the space with various degrees of importance. The relevance of emails and corresponding references to them sharply tapers off with the passage of time.
Page 217: Information Retention Regulations
Texas Public Information Act How StorTrends Tiered Storage and ILM Works At the core of StorTrends iTX stack is a data collection and trending module that collects and categorizes both instantaneous and historical access patterns that can span years. Storage blocks are also cataloged with respect to their RAID levels, class of disk drives (SAS, SATA and so on) and rotational speed (15K RPM, 10K RPM, 7200 RPM and so on).
Page 218 Having chosen the right block to move out and the appropriate time to do so, the StorTrends iTX stack utilizes a very efficient algorithm to perform the migration. The Data Mover technology (that works by advertisement of blocks) ensures that data blocks are migrated without corruption in the fastest possible time.
Page 219: Stortrends Tiered Storage And Csm (Scaling Within Tiers)
This will result in multiple Logical Drives (LDs) in the same tier and data has to be striped across them. There can also be restrictions given by the RAID card in the number of disk that can be added to one LD (maximum expansion support per LD). Some RAID cards may have restrictions on creating arrays across enclosures.
Page 220: How Stortrends Tiered Storage And Csm Works
When should the data When the I/O load on the system is low. The reason for this is to not affect the bandwidth be re-striped? of the applications running above it. The method of predicting the I/O load on the system at given point in time is done by the workflow analysis.
Page 221: Space Utilization
SAN volume so the bottom line lies on the x-axis). The user can use the sliding window in the top chart to get a more detailed view in the bottom chart of how the space was consumed over a period of time. The size of the sliding window is also adjustable by the user.
Page 222: Volume Performance
The green colored line in the chart indicates the read performance and the blue colored line in the chart indicated the write performance. This chart has a sliding window that can be dragged and adjusted for viewing detailed information for a particular period of time.
Page 223: Io Performance
The IO Performance chart displays the IO performance of the volume selected. In the chart above, the volume is undergoing more 64 K read and writes compared to other segments. For instantaneous performance readings, the values are polled in five-second interval.
Page 224: Logical Drive Performance
The lines in the graph have a diminishing color gradient that is indicative of the past history of that LD. By looking at the chart it is possible to detect drive failures in advance, since unusually high latency and outstanding I/Os indicate a potentially failing drive.
Page 225: System Performance
System Performance System performance is tracked in the form of instantaneous CPU and Memory Utilization. These values are also polled on a 5-second interval. Above is the graph showing the CPU Utilization as a percentage. Chapter Seven : Managing the Storage Appliance 207...
Page 226 System performance is tracked in the form of instantaneous CPU and Memory Utilization. These values are also polled on a 5-second interval. Above is the graph showing the Memory Utilization as a percentage. StorTrends® 1300 User’s Guide (StorTrends iTX version 2.7)
Page 227: Information Lifecycle Management
Information Lifecycle Management The chart above show the access patterns of the data and how they are spread across the tiers. The chart above shows the Random Access patterns of data. The ideal situation would be for the most frequently accessed data (red) be present in the high cost tier (yellow background) and least accessed data (blue) present in the low cost tier (white background).
Page 228: Container Space Management
Container Space Management The above charts show how a container was before expansion and below, how it is after expansion and re-striping. The x-axis represents the Logical Drives and the y-axis represents the Storage space used in each logical drive.
Page 229: Appendix Araid
I/O is expedited because several hard disk drives can be accessed simultaneously. RAID systems improve data storage reliability and fault tolerance compared to single hard disk drive systems. Data loss due to a hard disk drive failure can be prevented by regenerating missing data from the remaining data and parity information stored on other hard disk drives in the volume.
Page 230: Raid Overview
Software supports stripe sizes of 8 KB to 512 KB. For example, in a four hard disk drive system using only disk striping (as in RAID level 0), segment one is written to hard disk drive one, segment two is written to hard disk drive two, and so on.
Page 231: Disk Mirroring
Both hard disk drives contain the same data at all times. Either hard disk drive can act as the operational hard disk drive.
Page 232: Selecting A Raid Level
Your StorTrends 1300 storage appliance should have a RAID controller that supports RAID 0, RAID 1, RAID 5, RAID 10 and RAID 50. Depending on your StorTrends 1300 storage appliance configuration, your RAID controller MAY also support RAID 6 and RAID 60.
Page 233: Raid 0
RAID level. RAID 0 breaks up data into smaller blocks and then writes a block to each hard disk drive in the volume. The size of each block is determined by the stripe size parameter, set during the creation of the RAID set.
Page 234: Raid 1N
This array type provides superior data redundancy because there are three or more copies of the data. It is also useful for creating exact copies of an array for backup purposes. However, this array type is expensive, in both performance and the amount of disk space required to create an array type.
Page 235: Raid 5
If a hard disk drive fails, the StorTrends® iTX Software uses the parity stored on each of the other hard disk drives to recreate all missing information. Use also for office automation and online customer service that requires fault tolerance.
Page 236 StorTrends® 1300 User’s Guide (StorTrends iTX version 2.7)
Page 237: Appendix Bchap And Mutual Chap
Access the LUN/target from a client running MS Initiator. To do this, type the IP address of the Storage Appliance in the Portals tab or use the iSNS server. To log onto the target, click on Advanced, and enter the username and password when prompted (fields are called Username and Target Secret). Click on Apply.
Page 238: Mutual Chap Authentication
Configure at least one local user (minimum of 12 characters in password) and a Volume with iSCSI support. Create a LUN and assign to a target. Enable that. Register your iSCSI Initiator with the iSNS server. To do so, enter the IP address of the server into the iSNS Servers tab of the MS Initiator applet.
Page 239: Appendix C Installation Procedure
THIS APPENDIX DESCRIBES HOW TO INSTALL THE STORTRENDS ITX SOFTWARE ON THE STORTRENDS 1300 STORAGE APPLIANCE ONLY. IT IS RECOMMENDED THAT YOU INSTALL AT LEAST TWO HARD DISK DRIVES. YOU MUST PHYSICALLY ATTACH AN EXTERNAL USB CD-ROM DRIVE ENTER THE...
Page 240: Installation Procedure
BE ERASED. THIS INCLUDES ALL USER RIGHTS, TARGET INFORMATION, NAS SHARES AND SO ON. Use the steps outlined in this manual to re-install the StorTrends® iTX 2.7 software into your storage appliance. This process is fast and should take less than 30 minutes.
Page 241: Remove Any Pci Nic Add-On Cards
Remove Any PCI NIC Add-on Cards STOP! IF YOU HAVE INSTALLED AN EXTRA NIC, YOU MUST REMOVE IT BEFORE PROCEEDING WITH THE INSTALLATION. Attach a Keyboard and Monitor Attach a keyboard and monitor to your StorTrends® Storage Appliance. Power on your StorTrends®...
Page 242: Installation Procedure
Once you have attached a keyboard and monitor, power on your StorTrends 1300 storage appliance. You should see the Welcome to AMI StorTrends ITX screen. If not, you have to reset the power on your StorTrends 1300 storage appliance and start over.
Page 243 16 hard disk drives. If there is only one hard disk drive installed, you will be prompted with a message stating, “Warning!!! Detected a single OS disk for the StorTrends iTX installation. Any OS disk failure will result in the system becoming unusable.
Page 244 The StorTrends iTX installation takes approximately 30 minutes. You will see various screens throughout the installation. At times there will be a long period where you will see a blank screen. However, do not try to do anything. Leave the system alone until the StorTrends iTX Installation CD ejects and you see the screen where it tells you that the installation is complete.
Page 245: Appendix D Upgrade Procedure
Appendix D Upgrade Procedure STOP! Currently, Upgrading from all versions of StorTrends other than StorTrends 2.7.XXXX is not supported. StorTrends iTX X.X Upgrade Current StorTrends ITX Version is X.X.XXXX. No need to upgrade. Enter OK to exit. < OK >...
Page 246: Ftp Upgrade Procedure
Logout of all your iSCSI connections and disconnect all NAS shares. The upgrade process reboots your system. Copy the upgrade file(s) that you have received into an FTP folder. If you do not have an FTP server handy, please refer to the section, Using StorTrends as an FTP Server. If the upgrade file is compressed, you must uncompress it first.
Page 247: Upgrade Procedure Using The Command Line Interface
Fully Boot into ManageTrends WARNING! This step is critical. Do NOT insert the CD until you are fully booted into the StorTrends software. Doing so may cause you to accidentally re-install instead of upgrade. Power on your Storage Appliance. Make sure that your Storage Appliance is fully booted into the StorTrends®...
Page 248: Insert The Stortrends Itx Installation Cd (With The Build You Want To Upgrade To)
Insert the StorTrends iTX Installation CD (with the build you want to upgrade to) Insert the StorTrends iTX Installation CD into the CD-ROM drive when you see the AMI StorTrends Console Interface. AMI StorTrends Console Interface System Info : Host Name...
Page 249 Kernel X.X.X-X.XXXXXX on an XXXX XXXXXXXXXXXXXXX login: _ Log in as root. Type root as your user name and press the <ENTER> key. Next, type in your password and press the <ENTER> key. The default password is password. If you changed your admin password, use the admin password.
Page 250 AMI XXX (StorTrends) Kernel X.X.X-X.XXXXXX on an XXXX XXXXXXXXXXXXXXX login: root Password: [root@ITXXXXXXXXXXXXX ~]# _ At the prompt type the following command followed by the <ENTER> key: mkdir /mnt/source AMI XXX (StorTrends) Kernel X.X.X-X.XXXXXX on an XXXX XXXXXXXXXXXXXXX login: root...
Page 251 Step Description Type the following command followed by the <ENTER> key: mount /dev/scd0 /mnt/source AMI XXX (StorTrends) Kernel X.X.X-X.XXXXXX on an XXXX XXXXXXXXXXXXXXX login: root Password: [root@ITXXXXXXXXXXXXX ~]# mkdir /mnt/source [root@ITXXXXXXXXXXXXX ~]# mount /dev/scd0 /mnt/source mount: block device /dev/scd0 is write-protected, mounting read-only...
Page 252 [root@ITXXXXXXXXXXXXX ~]# sh /mnt/source/upgrade/upgrade.sh Note: In this example, the path on the CD is UPGRADE. The file name is UPGRADE.SH, which is located in the UPGRADE directory. The StorTrends Upgrade console interface will appear. Press the <ENTER> key to proceed.
Page 253 Step Description A warning message will appear stating that you should back up before proceeding. Press the <ENTER> key to proceed or escape out to backup first. StorTrends iTX X.X Upgrade As a precautionary measure, please backup the data before upgrade.
Page 254 Step Description Once it is finished, press the <ENTER> key. The CD will eject automatically. If it does not, eject the CD. StorTrends iTX X.X Upgrade Upgrade Complete Upgrade to X.X is successful. Reboot the machine. < OK> At the prompt type the following commands followed by the <ENTER> key:...
Page 255: Using Stortrends As An Ftp Server
Check whether you have space to create a 5GB NAS volume. If you already have a NAS volume, you can use that instead. If you do not have enough space or do not have a pre- existing NAS volume, you need to use an external FTP server.
Page 256 StorTrends® 1300 User’s Guide (StorTrends iTX version 2.7)
Page 257: Appendix E Replication Overview
The Solution: Remote Replication High Availability with Synchronous Replication Various factors have to be considered while architecting a DR solution. Service Level Agreements (SLA) along with tolerable Recovery Point Objective (RPO) and Recovery Time Objective (RTO) are the key factors influencing the planning.
Page 258: Remote Replication Essentially Comes In Two Flavors
Remote Replication essentially comes in two flavors. Synchronous Replication Here the recovery site moves lockstep with the production site and offers best RPO. But it is very costly to implement. Distance is a challenge for Synchronous Replication. Beyond tens of miles, the delays and latencies incurred renders the solution impractical.
Page 259: Synchronous Replication
StorTrends offers the ultimate in flexibility and performance when it comes to disaster recovery and business continuance. Remote Synchronous Replication is implemented on the target stack. This imposes no burden on the application servers and is transparent to the SAN initiators. Setting up a complete mirror-recovery site requires just a few clicks of the mouse and in seconds the entire production server storage configuration is duplicated on the recovery site storage server.
Page 260: Stortrends Asynchronous Replication
StorTrends servers offer a very innovative and feature-rich periodic replication suite called Snap-Assisted-Replication (SAR). This form of replication is used where Service Level Agreement (SLA) permits the administrator to have a relaxation in Recovery Point Objective (RPO) and Business economics does not permit synchronous replication.
Page 261: Delta Snaps
The snapshots in the secondary are essential to provide recovery points. In the event of a failover, the active volume in the secondary cannot be used as it may have some snapshot data that is NOT fully consistent. On a failover to secondary system, the StorTrends iTX will automatically rollback to the latest available snapshot in the secondary.
Page 262: Snap Assisted Replication Of Nas Volumes
This temporary share configuration will be merged with the original configuration during a Failover. The User database is handled in a different way. If ADS / NIS users are used in the primary system, then administrator is requested to configure the secondary system also with the same ADS / NIS configurations.
Page 263: An Overview Of Journal Assisted Replication (Jar)
An Overview of Journal Assisted Replication (JAR) JAR uses Journaling method by staging the data in a rolling log and is thereby is more tolerant to link speed disparities or communication outages. Every I/O has to be replicated out in the same sequence it arrives at the Production site in order to ensure application consistency.
Page 264: Journal And Journal Files
Once JAR is enabled and is in action, it faithfully replicates every incoming I/O to the recovery site allowing a continuous spectrum of recovery points. However, if there is a big disparity between the incoming and outgoing rates, then the Journal size increases and eventually a situation may arrive when the journal will overflow and the replication cannot proceed.
Page 265: Synchronous Replication & High Availability
Step Action The first step involves logging in to the primary node’s ManageTrends and going to the replication tab. It is assumed here that the primary volume and targets have already been created; also the primary portal must have been activated. Select “Remote Replication” as the replication type Specify the secondary nodes IP address, user name and the password in this screen and click next.
Page 266 (or) a new volume can be created as shown below. In order to proceed to the next step based on the options selected, click next.
Page 267 Step Action If a new volume creation option has been selected, the new container and new volume have to be configured. Creation of Remote Container Creation of Remote Volume and Target Appendix E : Replication Overview 249...
Page 268: Cli Command For Creating A Synchronous Replication Pair
Finally the summary screen is shown. Upon clicking the finish button the replication pairs are created one by one. Please allow a few seconds for the replication pairs to be created and the screen to refresh itself with the replication pairs.
Page 269: Synchronous Replication And High Availability Pair Details
Synchronous Replication and High Availability Pair Details Synchronous Replication Details High Availability Pair Details Appendix E : Replication Overview 251...
Page 270: Synchronous Replication And High Availability Pair Deletion
Synchronous Replication and High Availability pair deletion The deletion of replication pair is done by clicking on the delete button in the primary node. This button is disabled by default in the secondary node. In case the replication pair has become disconnected and there is a need to delete the replication, CLI delete command must be used with the force flag enabled.
Page 271: Cli Command For Deleting A Synchronous Replication Pair
ManageTrends on CLI command. The following screenshot shows the result of a split operation. The connection mode “Manual” refers to a split replication pair. It can also be seen that the capacity out-of-sync is non-zero now, as compared to the previous screenshot.
Page 272: Cli Command For Displaying Split Replication And Status
CLI Command for Displaying Split Replication and Status A sample CLI command for displaying status and split operation of Synchronous replication pair is shown below: [root@ITX0030488657ee ~]# cli get -l StoragePool1_SANVolume1 syncreplica Replication pair details: ************************* Primary Container : StoragePool1...
Page 273: Join Operation And Resync Progress
Join Operation and Resync Progress Join operation is clicking on the join button in the primary node of a split replication pair. Once this is done the replication resumes and the out-of-sync percentage starts going down till it becomes fully in-sync and out-of-sync percentage becomes zero.
Page 274: Failover Operation
Failover Operation Failover operation is done by clicking on the failover button in the original secondary node. Once the failover completes the replication role in the original secondary becomes primary. Synchronous Replication Failover – Before Failover in Original Secondary Synchronous Replication Failover – After Failover in Original Secondary...
Page 275: Cli Command For Failover Operations Of Synchronous Replication Pairs
Success. Failback Operation Failback operation is done by clicking on the failback button in the original primary node. Once the failback completes the replication role in the original primary node becomes primary from secondary. Synchronous Replication Failback – Before Failback in Original Primary...
Page 276: Synchronous Replication Failback - After Failback In Original Primary
Synchronous Replication Failback – After Failback in Original Primary CLI Command for Failback Operations of Synchronous Replication Pairs A sample CLI command for failback operation of Synchronous replication pair is shown below: [root@ITX0030488657ee ~]# cli perform -t failback -l Storage1_SecReplSANVolume1 syncreplica Success.
Page 277: Snap-Assisted Replication
Snap-Assisted Replication Navigating with ManageTrends Appendix E : Replication Overview 259...
Page 278: Snap Assisted Replication Using The Replication Wizard
The first step involves logging in to the ManageTrends of the primary node and going to the replication tab in the tree view. It is assumed here that the primary volume and targets have already been created, and the primary portal has been activated. Now specify the secondary node IP address, user name and the password in this screen and click next.
Page 279 Pool for the replication. Click next to proceed further. The next step involves creation of the volumes and volume targets on the secondary side. The user also has the option to specify the provision type i.e. Thin/Exact for the volumes. Click next for volume creation to begin.
Page 280 Enable encryption or compression based on user requirement. For compression, select the compression level (1- 9). This page shows the summary of the replication pairs and its parameters for the user to confirm before actual creation of the replication pair. Click finish to create the replication pair.
Page 281: Replication
Replication SAR view – Primary Box SAR view – Secondary Box Appendix E : Replication Overview 263...
Page 282: Sar - Configuring The Schedule
Action To configure the schedule for replication, click on the “Edit” button shown in the following figure. Continue to set the schedule either for a specific time and day. The default schedule is [All the time – Everyday]. After selecting the required parameters, Click on “Add Schedule” to persist it.
Page 283: Sar - Deleting The Schedule
SAR – Deleting the Schedule Step Action To remove an existing schedule, select the schedule from the schedule information box. Click on “Remove Schedule”. Appendix E : Replication Overview 265...
Page 284: Failover Operation
Failover Operation Go to the SAR page in the secondary box and click on the “Failover” button. After this, the Role in the Secondary changes to Primary. Note: Failover should be always done only in the original secondary box. Before Failover Operation in Secondary Box...
Page 285: After Failover Operation In Secondary Box
After Failover Operation in Secondary Box Appendix E : Replication Overview 267...
Page 286: Failback Join Operation
Failback Join Operation Go to the SAR page in the acting primary (original secondary) box and click on the “Failback Join” button. After this the Role in the orginal Primary box changes to secondary. Note: Failback Join operation can be done only in the acting primary (original secondary) box.
Page 287: After Failback Join Operation In Primary (Original Secondary) Box
After Failback Join Operation in Primary (Original Secondary) Box. After Failback Join Operation in Secondary (Original Primary) Box. After Failback Join operation both the boxes again becomes ready for replication. Now the replication happens from the original secondary to the original primary.
Page 288: Failback Operation
Failback Operation Go to the SAR page in the secondary (Original Primary) box and click on the “Failback” button. Note: Failback should be always done only in the original primary box. Before Failback Operation in Secondary (Original Primary) Box. After Failback Operation in Secondary (Original Primary) Box.
Page 289: After Failback Operation In Primary (Original Secondary) Box
After Failback Operation in Primary (Original Secondary) Box. Deleting the SAR pair The user can delete the SAR pair by clicking the “Delete” button. Deletion of SAR pair Appendix E : Replication Overview 271...
Page 290: Journal Management & Journal Assisted Replication
CLI: A Journal can be created using ITX 2.7 CLI interface. For example: cli create -t journal -j journal0 -l /dev/sdc journal Where –j option is the Journal name and –l option is for LD name. –l option can be repeated for as many LDs for a Journal.
Page 291 In Create Journal Page, one or more LDs have to be selected. Enter a name for Journal and proceed to creation. Once a Journal is created, a separate node will be created under ‘Storage/Journal’. Select this node to manage this Journal. Used space and Available space can be seen here.
Page 292: Creating A Journal File
Creating a Journal File Journal File is always associated with a Consistency Group. It means, Journal File is associated with one or more volumes for which Journaling will be perform on this Journal File. StorTrends® 1300 User’s Guide (StorTrends iTX version 2.7)
Page 293 For example: cli create -t journal –f journalfile0 –c StoragePool1 –v privol0 –v privol1 –z 10 -j journal0 journal Where, –f option is for Journal File name, -c option is for container name, -v option is for volume name and –j option is for Journal name. –v option can be repeated for as many volumes for a Journal File.
Page 294: Journal Assisted Replication
JAR is preferred over SAR when Recovery Point Objective (RPO) has to be very minimal. JAR also provides another benefit with compare to SAR. In JAR, remote volume can be in-sync with Primary volume. SAR always relies on volume’s snapshot in order to replicate data.
Page 295 In next page, A) select replication type as ‘Journal Assisted’. B) Select Journal File from the list C) Select all volumes associated with the Journal File. Note that JAR does not replicate NAS volume. It can replicate only a SAN volume.
Page 296 Remote Storage Pool and volume can be either already existing or can be created now freshly. Note the Journal File in remote is not required. Edit default parameters for remote volume as shown below and continue. StorTrends® 1300 User’s Guide (StorTrends iTX version 2.7)
Page 297 ‘Maximum Snapshot per volume’. Give a name for this JAR in ‘Consistency group name’ field. Review the desired configuration in the last page and select ‘Finish’ to proceed to JAR creation as shown below. Appendix E : Replication Overview 279...
Page 298 Once the affected region is replicated through DVM snapshot, it will try to fallback on Journal File. When a CG rollback happens, all IOs in journal may be invalidated. In such cases, it will rely on snapshot.
Page 299 When JAR is in ‘Snapshot mode’, it will check journal file upon completion of each snapshot based replication to see whether it can fall back to Journal based replication. Journal based replication can be done only when a snapshot event is exists (in Journal File) for a completed snapshot.
Page 300 StorTrends® 1300 User’s Guide (StorTrends iTX version 2.7)
Page 301: Appendix F Setting Up Dhcp From The Console Interface
Make sure it is plugged into the back of the chassis. Also make sure that it is a good cable. Check to make sure that your switch is properly configured (if it is a manageable switch).
Page 302: Console Interface
Console Interface The main menu is the first screen that you see when you log into the Console Interface of your StorTrends® iTX Storage Appliance. Navigate to the section you want to view or configure. Keyboard Key Function <ARROW UP>...
Page 303: Set Ip Address
NIC-1 NetworkInterface-1 NIC-2 NetworkInterface-2 < OK > < Cancel > This screen allows you to configure TCP/IP automatically via DHCP server or by specifying the addresses statically for the following: • IP address (Server) • Subnet Mask • Default Gateway •...
Page 304: Set To Dhcp
Configure NIC-x: DHCP ( X ) STATIC < Cancel > < OK > Highlight the DHCP option by navigating to it and press the <SPACE> bar to select it. TCP/IP Configuration Port NIC-x Configuration Mode STATIC IP Address 192.168.0.3 Subnet Mask 255.255.255.0...
Page 305: Appendix G Updating An Expired License
“The license is unavailable/expired for both the SAN and NAS features. You need to upgrade to a valid license for at least one of the features in order to continue managing this server.”...
Page 306: Overview
After your changes have been processed by an AMI Support Representative, you’ll receive a new license key in the form of a text document. After you save the new key to a location on your hard drive, use the Browse button to navigate to the location of that file, and then simply select the Update License button to complete the process.
Page 307 After your license has been processed by an AMI Support Representative, you will receive a License key in the form of a text document. After you save the new key to a location on your hard drive, use the Browse button to navigate to the location of that file, and then simply select the Update License button to complete the process.
Page 308 StorTrends® 1300 User’s Guide (StorTrends iTX version 2.7)
Page 309: Appendix Hups Configuration
The data in the write-back cache being not persistent, any power failure in the storage system will result in the loss of valuable data. In order to circumvent this problem the administrator must use a UPS to protect the system from abrupt power failures.
Page 310: Configuring Using Managetrends
StorTrends box can be run on UPS. If either one of the condition is met the StorTrends boxes will execute a graceful shutdown, thereby preventing any potential data loss for the applications.
Page 311: Configuring Slave Boxes
Configuring Slave Boxes The status of the UPS can also be monitored using the CLI. The following examples show how to use the CLI to find the type of UPS connected and monitor the status of it. Monitoring UPS through CLI...
Page 312: Action On Power Failure
Whenever the A/C power fails, the UPS takes over and the StorTrends boxes start running on the UPS. Depending on the type of the UPS and the load on it, it will start discharging and the amount of time and charge left in the UPS can be monitored using the ManageTrends.
Page 313: Cache Mode Change From Stortrends Logs
The ManageTrends event log is also updated with this information the A/C power was turned off. The status of the UPS, whether it is running on A/C or battery and the amount of charge and time remaining in the UPS can be monitored using the ManageTrends or the CLI, as mentioned before.
Page 314: Messages From Stortrends Log - Auto Shutdown
Messages from StorTrends Log - Auto Shutdown 2 04:16:57 ITX003048841e04 upsmon[9206]: UPS upsunit@127.0.0.1 battery is 2 04:16:57 ITX003048841e04 upsd[9202]: Client upsuser@127.0.0.1 set FSD on UPS [upsunit] 2 04:16:57 ITX003048841e04 upsmon[9206]: Executing automatic power-fail shutdown 2 04:16:57 ITX003048841e04 wall[10855]: wall: user root broadcasted 2...
Page 315: Appendix I Continuous Data Technology
Statistics show that data growth is almost doubling every year, yet the Recovery Time Objective (RTO) has remained the same, if not tighter. From the anatomy of data re-usage, it is clear that in overwhelming situations most recent data is recalled.
Page 316: Stortrends Itx Installation Cdt - A True Event Addressable Storage
Today there are various implementations of CDP. A vast majority of vendors implement it on the Host that is serving as the File or Application Server. In Host based CDP, there is a filter driver or “Data-Tap” residing in the Host Operating Systems that replicates every I/O on the Production Server to the CDP Server.
Page 317 In a typical environment where an average of 10GB production data is changed or generated per hour, a journal file of 1TB can hold four days worth of continuous chronological data. In addition, with eight levels of scheduled snapshots and up to 2000 snapshots per volume StorTrends can deliver any historic data across a very wide time spectrum.
Page 318: Contemporary Cdp Appliance Vs Stortrends Itx Installation Cdp
In contemporary CDP appliances, the write I/Os are replicated outside the appliance using some sort of data-tapping agents. This mirrored I/O is then (1) staged in a buffer in the appliance. The old data is (2) read from the recovery volume, time-stamped and (3) journalled out into a “undo”...
Page 319: Under The Hood: Stortrends Itx Installation Cdt
I/O latency. During a Review or Rollback operation, initially a rollback to a previous writable snapshot is done and then the redo Journal is played on top of it to the selected point in time. Under the hood: StorTrends iTX Installation CDT The Advanced Caching Module of iTX stack serves as the central repository of in-flight data.
Page 320: Stortrends Continuous Data Protection Architecture
StorTrends Continuous Data Protection architecture StorTrends® 1300 User’s Guide (StorTrends iTX version 2.7)
Page 321: Appendix Jwds And Deduplication In Stortrends Itx
Signals transported at nearly the speed of light are saddled with delays, resulting in latencies that can no longer be ignored, as is the case with LAN data transfers. These round-trip delays range from a couple of milliseconds for inter-city connections to around 80-100 ms from coast-to-coast, and as much as 250-300 ms for submarine transmissions across the globe.
Page 322: Figure 1: Effect Of Tcp Protocol On Transfer Bandwidth
For example, using a single T1 connection, the maximum achievable rate is 1.55 mbps; for T3 it is 45 mbps; with OC3 it increases to 155 mbps, and with Gigabit Ethernet (GigE) links this maximum reaches the impressive order of Gigabits per second.
Page 323: Figure 2: Stortrends Transfer Profile Vs. Tcp Transfer Profile
Figure 2: StorTrends Transfer Profile vs. TCP Transfer Profile Based on the data above, it is clear that for short distances, where latencies are in the sub-ms range (for example, in LAN environments), the throughput is dictated entirely by the link bandwidth.
Page 324: The Stortrends® Itx Wds Implementation And Transfer Acceleration
As noted earlier, although the performance of the TCP stack can be tweaked, it is a fairly accurate generalization that TCP is more suitable for the LAN environment than it is in long-haul networks.
Page 325: Figure 5:The Delta Snapshot Replication Technology Behind Asynchronous Replication In Stortrends Itx
Like many of its competitors, StorTrends® employs delta-snapshot technology to transfer only the data that has changed between passes in order to reduce the amount of data transported. In addition to this, StorTrends® also employs an intelligent data-dedupe algorithm to filter out some of the previously transmitted data from earlier passes.
Page 326: Figure 6: Deduplication And Wan Transfer Acceleration Management In Stortrends Itx
SQL servers generate random I/Os of 8K blocks, and Exchange servers generate random I/Os of 4K blocks, making it easy to see that even when chunk sized I/Os are replicated, they may carry multiple packets of duplicated data. To remedy this, the deduplication feature in StorTrends iTX utilizes a very I/O-efficient algorithm to detect duplicate data and eliminates them, to further reduce the amount of data transported during asynchronous replication.
Page 327: Additional Wan Assists In Asynchronous Replication With Stortrends
In addition to the optimizations described above, StorTrends® supports the compression and encryption of data before it is released on the WAN, which reduces the net size of data transferred over these more expensive links. StorTrends® supports various compression depths, including an adaptive compression mode where the depth of compression is determined by an analysis of the current and statistical load on the system.
Page 328 The innovative replication stack found in StorTrends iTX offers unprecedented performance for remote replication over wide-area networks. It utilizes an intelligent mix of standards-based transport protocols to overcome the inefficiencies and high latencies of TCP protocols in WANs and provide excellent bandwidth utilization. Additional performance gains are made through data reduction technologies such as compression and data deduplication.
Page 329: Appendix K System Specifications
Field/Item Description Processors Single 775-pin Intel® Xeon® 3000 Series, Pentium® D, Pentium Extreme Edition, Pentium 4, and Celeron D processors at a FSB speed of 1066/667/533 MHz Note: Pease refer to our web site for a complete listing of supported processors.
Page 330 StorTrends® 1300 User’s Guide (StorTrends iTX version 2.7)
Page 331: Glossary
Access Control List. An ACL is a table that tells the system’s operating system the access rights each user has to a directory or file. The directory or file has a security attribute that identifies its access control list. The list has an entry for each system user with access privileges, such as read and write.
Page 332: Archive
Archive The StorTrends® iTX software uses this word to describe the process of backing up data stored on it to a safe place. Asynchronous Replication Asynchronous replication can minimize the performance impact and bandwidth requirements of synchronous replication by forgoing the need to write to the primary and secondary simultaneously.
Page 333: Cdp
No snapshot taken at a later time T1 will be replicated, until the prior snapshot taken at time T0 on all volumes are replicated and snapshots for time T0 on all volumes are replicated in the secondary. Similarly, on a failover to secondary, all volumes in the consistency group are rolled back to the same snap group there by maintaining application consistency across all the volumes.
Page 334 • If no matching snap groups present that is safe (out of disaster), then there is no way the replication can continue with given parameters. In such scenarios, the PASSIVE volume data will be wiped out and replication will start from the beginning.
Page 335: Cow
Often, this table is just a hash (by logical address) of the location of old data versus that of new data. This table needs to be consulted when a snapshot is mounted and read, and preferably should be stored in the system’s main memory to allow for rapid reads from...
Page 336: Delta Snaps
In the event of a failover, the active volume in the secondary cannot be used as it may have some snapshot data that is not fully consistent. On a failover to secondary system, the StorTrends iTX will automatically rollback to the latest available snapshot in the secondary.
Page 337: Domain Name
(LAN). Ethernet 802.2 Packet format that defines the standard for the data link layer. It is made up of two smaller layers called the logical link control (LLC) layer and the media access control (MAC) layer.
Page 338: Ethernet Snap
> < 38-1492 > Failover Failover is a process by which a PASSIVE system (B) is made as ACTIVE in the event of a irrecoverable failure of the ACTIVE system (A). During a Failover operation, the PASSIVE system (B) will rollback to the latest available snapshot – snap group across all volumes.
Page 339: Fc San
Fibre Channel over TCP/IP. FCIP is a TCP/IP-based tunneling protocol for connecting geographically distributed Fibre Channel SANs transparently to both Fibre Channel and Firewall A set of related programs, located at a network gateway server that protects the resources of a private network from users from other networks. Frame A frame is a single data packet that is transmitted across a network.
Page 340: Group
Group A group is a number of users that are bunched together. Having a group makes it easier to assign a set of rules that are common to a set of users. Common groups can be Accounting, Sales, Marketing, and so on.
Page 341: Ilm
An administrator may want to move old data to cheaper, lower-performance media, and move frequently used new data to faster media.
Page 342: Ips
The iSCSI protocol increases the capabilities and performance of storage data transmissions. Because of the wide use of IP networks, iSCSI can be used to transmit data over LANs, WANs, or the Internet and can enable location-independent data storage and retrieval.
Page 343: Iscsi Initiator
(initiates) the transfer of information to and from an iSCSI target. iSCSI Name An iSCSI Name is used by the Initiator and Target for locating storage resource and storage resource allocation. The iSCSI Name also is used to identify which initiator has access to which target resource.
Page 344: Mail Server
2.1 version release. Mirroring the StorTrends® iTX OS is the ability to install the StorTrends® iTX software on two hard disk drives. Basically, if one of the two boot hard disk drives fails, you still maintain the ability to boot to the StorTrends® iTX operating system from the alternate hard disk drive.
Page 345: Nic
Using NIS, each host, client or server in the system has knowledge about the entire system. A user at any host can get access to files or applications on any host in the network with a single user identification and password. It is intended for use on local area networks.
Page 346: Osi
StorTrends® iTX software provides quota support on a per volume basis. This quota can be set for every individual user. If the quota is set to zero, it means the user has unlimited storage access. If the quota is set to a particular size it means the user has only that much amount of storage at his/her access in that volume.
Page 347: Raid 0
RAID level. RAID 0 breaks up data into smaller blocks and then writes a block to each hard disk drive in the volume. The size of each block is determined by the stripe size parameter, set during the creation of the RAID set.
Page 348: Raid 6
A 6-drive array provides two striped three drive RAID 5 sets. Generally, RAID 50 is useful in very large arrays, arrays with 10 or more disks. Like the RAID 1n and RAID 10n array types, RAID 50 can handle multiple disk failures.
Page 349: Raid 60
RAID 60 uses distributed parity, with two independent parity blocks per stripe in each RAID set, and disk striping. A RAID 60 virtual disk can survive the loss of two disks in each of the RAID 6 sets without losing data. It works best with data that requires high reliability, high request rates, high data transfers, and medium-to-large capacity.
Page 350: Row
As with Copy-on-Write snapshots, systems that implement Redirect-On-Write snapshots also need to maintain tables that contain a map of where old data and new data are stored. However, this mapping needs to be updated and referred to for volume reads in Redirect- on-Write, as opposed to merely for snapshot reads in Copy-on-Write.
Page 351: Sar
Snap Assisted Replication is built on top of the advanced snapshot mechanism provided by the StorTrends iTX 2.1 / 2.5 stacks. In a Snap Assisted Replication environment a primary volume snapshot will be replicated to a volume in a secondary system. Since the snapshot is a frozen image and the snapshot data is sequentially replicated to the remote volume, the remote volume will not be consistent until the entire image is replicated.
Page 352: Smb
SMB can be used over the Internet on top of its TCP/IP protocol or on top of other network protocols such as Internet Packet Exchange (IPX) and NetBEUI.
Page 353: Srm
A part of the host address is reserved to identify the particular subnet. Switch A network device that selects a path or circuit for sending a unit of data to its next destination. Glossary 335...
Page 354: Synchronous Replication
In short, when an I/O is recorded, it is written simultaneously to both the primary and the secondary to ensure parity. The writing of the I/O to the primary is in essence blocked until the secondary is updated. In this way, volumes are protected from failure at the granularity of an I/O, since the primary and secondary sites are always perfectly synchronized with each other, as the name suggests.
Page 355: Volume
It all depends on how you set up your Volumes. The controller treats one or more hard disk drives or unused space on a hard disk drive as a single array. A Volume provides the ability to concatenate storage from various hard disk drives regardless of the size of the space on those hard disk drives.
Page 356 StorTrends® 1300 User’s Guide (StorTrends iTX version 2.7)
Page 357: Index
Choosing a Setup Location, 8 AppleTalk®, 3, 313 CLI Command for Creating a Appliance, i, 7, 17, 18, 20, 22, 24, 26, 29, 33, 37, Synchronous Replication Pair, 250 40, 83, 85, 86, 87, 89, 90, 91, 93, 102, 107, 108,...
Page 358 Network Settings Control Panel, 43, 44, 59, 65, 76, 86, 88, 89, 90, Network Statistics Page, 99 91, 92, 93, 94, 95, 96, 97, 98, 99, 100, 101, 102, Control Panel 103, 106, 107, 108, 110, 111, 113, 114, 115, 116,...
Page 359 Network Settings Control Panel TCP/IP Settings Page, 106 Network Settings Control Panel File Protocols Settings Page Network Settings Set Windows File Protocol Page, TCP/IP Settings Page Create Teaming, 106 Control Panel Control Panel Network Settings, 113 Network Settings Control Panel...
Page 360 Portal Settings Page, 128 Control Panel DAS, 317 iSCSI, 129 Data, 1, 2, 70, 71, 129, 161, 192, 196, 197, 198, 200, Control Panel 211, 214, 245, 272, 297, 298, 299, 306, 315, 317, iSCSI Portal Settings Page, 129...
Page 361 Initiator, 126, 132, 146, 147, 150, 219, 220, 325 (JF1), 60 Insert the StorTrends iTX FTP, 3, 89, 92, 97, 115, 155, 228, 229, 237, 321 Installation CD (with the build FTP Upgrade Procedure, 228, 229 you want to upgrade to), 230...
Page 362 N Journal Management & Journal Assisted Replication, 272 NAS, 1, 4, 22, 24, 25, 33, 37, 38, 39, 86, 113, 116, 146, Journaling, 161, 245, 246, 272, 274, 275, 301, 147, 154, 155, 156, 169, 171, 172, 173, 174, 178,...
Page 363 Safety Information and Technical Quota, 328 Specifications, 47 SAN, 1, 22, 24, 25, 33, 34, 37, 146, 147, 148, 149, 156, R 158, 160, 161, 169, 173, 174, 178, 179, 182, 183, 184, 186, 188, 190, 191, 192, 195, 196, 203, 241,...
Page 364 Speaker Connector, 70 RAID Level, 23 Split Operation and Replication Tab Storage, i, 1, 4, 7, 17, 18, 20, 22, 24, 26, 29, 31, 32, Status, 253 33, 37, 40, 83, 85, 86, 87, 89, 90, 91, 93, 102, 107,...
Page 365 View, 166 Continuous Data Protection (CDP), Storage Storage Continuous Data Protection (CDP), Continuous Data Protection (CDP) Storage Example of a selected CDP window, Continuous Data Protection (CDP) Event Description, 167 Storage Storage Continuous Data Protection (CDP), Continuous Data Protection (CDP),...
Page 366 StorTrends Integrated UPS Target Discovery, 336 Configuration, 291 TCP, 3, 97, 102, 103, 104, 105, 107, 108, 109, 128, StorTrends iTX Installation CDT – a 146, 149, 173, 285, 286, 303, 304, 305, 306, 310, True Event Addressable Storage, 298...
Page 367 X V XFS, 337 VGA Enable/Disable, 73 Volume, 1, 3, 25, 33, 34, 36, 37, 38, 139, 147, 148, Z 149, 154, 155, 156, 158, 160, 162, 171, 172, 173, 174, 177, 178, 179, 182, 183, 184, 187, 188, 190,...
