Capturing still images

In addition to video, VideoStudio also allows you to capture still images. The
image format can be BMP or JPEG, and the size depends on its source video.
To choose your image format, click File: Preferences. In the Preferences dialog
box click the Capture Tab and set the format.

To capture still images:

1. Connect your camcorder or VCR to your capture
card. Switch it on and set it to Play (or VTR /
VCR) mode. Check your device manual for
specific instructions.
2. Open a new project.
3. In the Capture Step, click Play in Navigator.
4. When you get to the part of the video you want
to record, click Capture Image on the Capture
Settings Tab in the Options Panel.
VideoStudio Manual and other Help Resources
We hope that the information that
has been provided you has got you
up and running with PYRO A/V Link
and Video Studio. This "Getting
Started with VideoStudio" is a very
abridged version of the VideoStudio
manual. VideoStudio has many
features and capabilities; some
have yet to be covered. To learn
more step by step procedures, you
can read the full on-line manual that
is in Acrobat reader format.
Help and Instructions (F1)
At any time you can press the F1
key on your keyboard and Video Studio help will pop up. You can read tips
and techniques or read step by step procedures.
Full Manual
The Full manual is located on the PYRO A/V Link CD:
1.) Insert CD and when the Auto-run menu pops up, Click on Video Studio icon.
2.) On the Video Studio Auto-run screen, Click Browse CD.
3.) An file explorer window will open, double click on the "Document" folder and then
double click on the Manual folder.
4.) If you do not have Adobe Acrobat installed, click on the Acrobat folder and install the
Acrobat Reader.
PYRO A/V LINK 37
