Page 1: Operation Manual
SPLIT TYPE ROOM AIR CONDITIONER OPERATION MANUAL HSU-09H03/R2(DB) HSU-12H03/R2(DB) HSU-12HB03/R2(DB) HSU-18H03/R2(DB) HSU-22H03/R2(DB) HSU-09HA103/R2(DB) HSU-12HA103/R2(DB) HSU-18HA103/R2(DB) HSU-22HA103/R2(DB) Please read this operation manual before using the air conditioner. No.00105... -
Page 2: Safety Instructions And Warnings
Safety Instructions and Warnings Before disposing an old air conditioner that Before starting the air conditioner, read the goes out of use, please make sure it's inop- information given in the User's Guide caref- erative and safe. Unplug the air conditioner ully. - Page 3 3. If the fuse of indoor unit on PC board is broken,please change it with the type of T. 3.15A/ 250V. If the fuse of outdoor unit is broken,change it with the type of T.25A/250V...
-
Page 4: Safety Instruction
Do not attempt to install the air conditioner by yourself because improper works may cause electric shock, fire, water leakage. lnstallation in a inadequate place may cause accidents. Do not install in the following place. CAUTION Do not install in the... - Page 5 PROHIBITION PROHIBITION CAUTION Take fresh air occasionally especially Do not operate the switch with Do not use for the purpose of storage of food, art work, precise equipment, when gas appliance is running at the wet hand. breeding, or cultivation.
-
Page 6: Parts And Functions
Lights up during compressor adjust up and down air flow. is selected. running. (Don't adjust it manually.) Actual inlet grille may vary from the one shown in the manual according to the product purchased Outdoor unit HSU-09H03/R2(DB) HSU-09HA103/R2(DB) HSU-12H03/R2(DB) HSU-22H03/R2(DB) - Page 7 8. HEALTH display B will be displayed on LCD. 9. SLEEP display Please select A without special explanation. NOTE: (1)The following functions and related displays are not available (2) Cooling only unit do not have functions and displays related with heating.
- Page 8 If the remote controller can't run normally during operation, please remove the batteries and reload several minutes later. Hint: Remove the batteries in case unit won't be in usage for a long period. If there are any display after taking-out, just need to press reset key.
-
Page 9: Health Operation
Note When the fan motor in the indoor unit does not work, the health lamp lights up, but the anion generator does not release anion. -
Page 10: Auto Operation
1. Unit start Link with electronic power. Remote controller Press ON/OFF on the remote controller, unit starts. The liquid crystal will display the working state of last time (Except Timer, Sleep, Power/Soft and Health airflow). 2.Select operation mode Press MODE button. For each press, operation mode... -
Page 11: Cool Operation
1. Unit start Link with electronic power. Remote controller Press ON/OFF on the remote controller, unit starts. The liquid crystal will display the working state of last time (Except Timer, Sleep, Power/Soft and Health airflow). 2.Select operation mode Press MODE button. For each press, operation mode... -
Page 12: Dry Operation
1. Unit start Link with electronic power. Press ON/OFF on the remote controller, unit starts. Remote controller The liquid crystal will display the working state of last time (Except Timer, Sleep, Power/Soft and Health airflow). 2.Select operation mode Press MODE button. For each press, operation mode... -
Page 13: Fan Operation
Press ON/OFF button, the unit stops. About FAN operation In FAN operation mode, the unit will not operate in COOL or HEAT mode but only in FAN mode ,AUTO is not available in FAN mode.And temp.setting is disabled. In FAN mode,SLEEP operation is not available. -
Page 14: Heat Operation
Remote controller: AUTO Air conditioner is running under displayed fan speed IN HEAT mode, warm air will blow out after a short period of the time due to cold-draft prevention function. When FAN is set to AUTO, the air conditioner automatically adjusts the fan speed according to room temperature. - Page 15 Be careful not to catch a cold when cold air blows downward. It is harmful to your health in summer to go frequently in and out of places where temp. difference is above 7 C.
-
Page 16: Sleep Operation
Note The sleeping hours lasts 8 hours and couldn't be adjusted. When timing on function is set, the sleeping function can't be set After the sleeping function is set up, if user resets timing on function, the sleeping function will be cancelled; the machine will be in the state of timing-on. -
Page 17: Timer On/Off Operation
Hints: After replacing batteries or a power failure happens, time setting should be reset. Remote controller possesses memory function, when use TIMER mode next time,just press SET button after mode selecting if time setting is the same as previous one. -
Page 18: Remote Controller
" on the remote controller stops flashing. " " starts flashing. Time displayed: Unit starts or stops at x hour x min. 5.Time setting for TIMER OFF Just press HOUR button ,follow the same procedure in "Time setting for TIMER ON"... -
Page 19: Power Operation
To cancel POWER operation Press POWER/SOFT button twice ,POWER/SOFT disappears. SOFT Operation You can use this function when silence is needed for rest or reading. Selecting of SOFT operation Press POWER/SOFT button. Every time the button is pressed,display changes as follows:... -
Page 20: Emergency And Test Operation
In this operation, the system automatically selects the operation modes, cooling or heating, according to the room temperature. When machine is running in emergency, the set value of temperature and wind speed couldn't be altered; meanwhile, it can't operate for dehumidifying or under timing mode. -
Page 21: Maintenance
Use the timer effectively during operation During cooling operation, prevent the penetration of direct sunlight with curtain or blind. Use the louvers effectively If the unit is not to be used for a long time, turn off the power supply main switch. -
Page 22: Air Filter Cleaning
Maintenance For Smart Use of The Air Conditioner WARNING Before maintenance,be sure to turn off the system and the circuit breaker. Remote Controller Indoor Body Wipe the air conditioner by using a soft and dry cloth.For serious stains,use a neutral detergent diluted with water.Wring the water... -
Page 23: Replacement Of Air Purifying Filter
6.Close the Inlet Grille Close the Grille surely NOTE: Please replace the air Purifying Filter when color of the filter become same levle of sample attached in the indoor unit. Please replace the air Purifying Filter in 3-6 months as standard. -
Page 24: Cleaning The Body
To Keep Your Air conditioner in Good Condition after Season. Operate in cooling mode for 2-3 hours. To prevent breeding mold or bad smell, be sure to operate at the designated temperature or 30 C,cooling mode and High speed fan mode for 2-3 hours. -
Page 25: Cleaning The Standard Air Filter
Before Setting in High season Cleaning the standard air filter. Operation without filter may cause troubles.Be sure to attach both right and left filters prior to the operation. Each of them are of different shapes. Connecting the earthing cable. Caution Incomplete earthing may cause an electric shock. -
Page 26: Troubleshooting
This noise is generated by the inspection casing expanding or shrinking because of temperature changes. Should there be a big noise from air flow in unit operation, air filter may be too dirty. This is because the system circulates smells Smells are generated.
