Controls and Indicators

1 2 3 4 5 6 7
16
14 15
17
01. Volume Control
02. Function Switch
03. CD Compartment
04. (TAPE) Pause Button
05. (TAPE) Stop/Eject Button
06. (TAPE) Fast Forward Button
07. (TAPE) Rewind Button
08. Tuning Control
09. (TAPE) Play Button
4
Accessory
8
9
10

Operation with AC power

11
12
13
0
6
10. (TAPE) Record Button
11. (CD) Play/Pause Button
12. (CD) Track Up/Cue Button
13. Cassette Compartment
Notes:
14. (CD) Stop Button
G If the unit will not be used for a long period of time, remove the AC
15. (CD) Track Down/Review
Button
G Connection of the AC power cord to the unit disconnects the batteries.
16. (CD) Play Indicator
G Never use a power cord other than the one supplied. It may cause
17. (CD) Pause Indicator
Notes:
G The AC power cord is located in the
battery compartment.
G Only the accessory in the drawing
is included.
AC power cord x 1
(QACCU0001SJ00)
To AC INPUT
power cord from the AC outlet.
an electric shock or fire.
AC 120 V, 60 Hz
To an AC outlet
