SPLIT TYPE ROOM AIR CONDITIONER

OPERATION MANUAL

Please read this operation manual before using the air conditioner.
0010517097
HSU-05LEA03
HSU-07LEA03
HSU-09LEA03
HSU-09LEA03G
HSU-09LEA03U
HSU-12LEA03
HSU-12HEA03
HSU-12LEA03G
HSU-12LEA03U
HSU-18LEA03
HSU-18HEA03
HSU-18LEA03G
HSU-18LEA03U
HSU-22LEA03
HSU-22HEA03
HSU-22LEA03G
HSU-22LEA03U
HSU-24LEA03

Advertisement

Table of Contents
loading

Related Manuals for Haier HSU-05LEA03

Summary of Contents for Haier HSU-05LEA03

  • Page 1: Operation Manual

    SPLIT TYPE ROOM AIR CONDITIONER OPERATION MANUAL HSU-05LEA03 HSU-07LEA03 HSU-09LEA03 HSU-09LEA03G HSU-09LEA03U HSU-12LEA03 HSU-12HEA03 HSU-12LEA03G HSU-12LEA03U HSU-18LEA03 HSU-18HEA03 HSU-18LEA03G HSU-18LEA03U HSU-22LEA03 HSU-22HEA03 HSU-22LEA03G HSU-22LEA03U HSU-24LEA03 Please read this operation manual before using the air conditioner. 0010517097...

  • Page 2: Safety Instructions And Warnings

    Safety Instructions and Warnings Before disposing an old air conditioner that Before starting the air conditioner, read the goes out of use, please make sure it's inop- information given in the User's Guide caref- erative and safe. Unplug the air conditioner ully.

  • Page 3: Specifications

    3. If the fuse of indoor unit on PC board is broken,please change it with the type of T. 3.15A/ 250V. 4. The wiring method should be in line with the local wiring standard.
  • Page 4 PROHIBITION PROHIBITION CAUTION Take fresh air occasionally especially Do not operate the switch with Do not use for the purpose of storage of food, art work, precise equipment, when gas appliance is running at the wet hand. breeding, or cultivation.

  • Page 5: Safety Instruction

    Do not attempt to install the air conditioner by yourself because improper works may cause electric shock, fire, water leakage. lnstallation in a inadequate place may cause accidents. Do not install in the following place. CAUTION Do not install in the...

  • Page 6: Parts And Functions

    Don't adjust it manually) Vertical blade (adjust left and right air flow) Actual inlet grille may vary from the one shown in the manual according to the product purchased For 22k unit, the power plug is on the outdoor unit...

  • Page 7: Clock Set

    Clock set When unit is started for the first time and after replacing batteries in remote controller, clock should be adjusted as follows: Press CLOCK button, "AM" or "PM" flashes.
  • Page 8 Each press will increase or decrease 1min. If the button is kept depressed, time will change quickly. After time setting is confirmed, press SET, "AM "and "PM" stop flashing, while clock starts working. NOTE: Cooling only unit do not have displays and functions related with heating.

  • Page 9: Operation

    When sudden power failure happens during unit operation in power failure resume mode, the air conditioner is not desired for use in a long period, please shut off the power supply in case that the unit automatically resume operation when power is re-supplied,...

  • Page 10: Auto Operation

    (4)Unit stop Press ON/OFF button, the unit stops. Hints Remote controller can memorize settings in each operation mode. To run it next time just select the operation mode and it will start with the previous setting. No reelecting is needed.(TIMER ON/OFF...

  • Page 11: Cool Operation

    Hints On cooling only unit, heating mode is not available. Remote controller can memorize each operation status. When starting it next time, just press ON/OFF button and unit will run in previous status. No reelecting is needed.(TIMER ON/OFF SLEEP SWING needs reelecting)

  • Page 12: Dry Operation

    Hints On cooling only unit, heating mode is not available. Remote controller can memorize each operation status. When starting it next time, just press ON/OFF button and unit will run in previous status. No reelecting is needed.(TIMER ON/OFF SLEEP SWING needs reelecting)

  • Page 13: Heat Operation

    Remote controller: AUTO IN HEAT mode, warm air will blow out after a short period of the time due to cold-draft prevention function.When FAN is set to AUTO, the air conditioner automatically adjusts the fan speed according to room temperature.

  • Page 14: Fan Operation

    Press ON/OFF button, the unit stops. Hints In FAN operation mode, the unit will not operate in COOL or HEAT mode but only in FAN mode. A UTO is not available in FAN mode And temp .setting is disabled. In FAN mode,SLEEP operation is not available.

  • Page 15: Air Flow Direction Adjustment

    When humidity is high,condensate water might occur at air outlet if all vertical louvers are adjusted to left or right. It is advisable not to keep horizontal flap at downward position for a long time in COOL or DRY mode ,otherwise, condensate water might occur.

  • Page 16: Power Failure Resume Function

    C higher than temp. setting. After another 1 hours, temp. rises by 1 C further. The unit will run for further 6 hours then stops. 6.Note to the power failure resume: Temp. is higher than temp. setting so that room press the sleep button ten times in five seconds temperature won't be too Iow for your sleep.

  • Page 17: Health Operation

    The anion generator in the air conditioner can generate a lot of anion effectively balance the quantity of position and anion in the air and also to kill bacteria and speed up the dust sediment in the room and finally clean...

  • Page 18: Timer On/Off Operation

    Timer On/Off Operation Set Clock correctly before starting Timer operation You can let unit start or stop automatically at following times: Before you wake up in the morning, or get back from outside or after you fall asleep at night.
  • Page 19 Follow the same procedures in "Time setting for TIMER ON". (6) Time confirming for TIMER OFF After time setting, press SET button to confirm, "OFF" stops flashing Time displayed: Unit stops at X hour X min. To cancel TIMER mode...

  • Page 20: Emergency Operation

    Removal of the restriction of emergency or test operation: Press the emergency operation switch once more, or manipulate through the remote controller; the "Pi" sound, the emergency or test operation is terminated. When the remote controller is manipulated, it gets the system back to the normal operation mode.

  • Page 21: Maintenance

    Use the timer effectively during operation During cooling operation prevent the penetration of direct sunlight with curtain or blind Use the louvers effectively If the unit is not to be used for a long time, turn off the power supply main switch.

  • Page 22: Air Filter Cleaning

    Maintenance For Smart Use of The Air Conditioner WARNING Before maintenance,be sure to turn off the system and the circuit breaker. Remote Controller Indoor Body Wipe the air conditioner by using a soft and dry cloth.For serious stains,use a neutral Do not use water wipe the controller with a detergent diluted with water.Wring the water...

  • Page 23: Replacement Of Air Purifying Filter

    The bacteria-killing medium air purifying filter will be used for a long time,no need for replacement. But in the period of using them ,you should remove the dust frequently by using vacuum cleaner or flaping them lightly,otherwise ,its performance will be affected.

  • Page 24: Troubleshooting

    Should there be a big noise from air flow in unit operation, air filter may be too dirty. This is because the system circulates smells from the interior air such as the smell of Smells are generated.
  • Page 25 HSU-05LEA03 HSU-07LEA03 HSU-09LEA03 HSU-09LEA03G HSU-09LEA03U HSU-12LEA03 HSU-12HEA03 HSU-12LEA03G HSU-12LEA03U HSU-18LEA03 HSU-18HEA03 HSU-18LEA03G HSU-18LEA03U HSU-22LEA03 HSU-22HEA03 HSU-22LEA03G HSU-22LEA03U HSU-24LEA03 NO: 0010517097...
  • Page 29 HSU-12HEA03 HSU-05LEA03 HSU-22LEA03 HSU-12LEA03 HSU-07LEA03 HSU-22HEA03 HSU-12LEA03G HSU-09LEA03 HSU-22LEA03G HSU-12LEA03U HSU-09LEA03G HSU-22LEA03U HSU-18LEA03 HSU-24LEA03 HSU-09LEA03U HSU-18HEA03 HSU-18LEA03G HSU-18LEA03U...
  • Page 30 TEMP ON/OFF MODE TIMER CLOCK SWING SLEEP HEALTH LOCK RESET...
  • Page 31 ON/OFF TEMP MODE TIMER CLOCK SWING HEALTH SLEEP LOCK RESET...
  • Page 32 ON/OFF TEMP MODE TIMER CLOCK SWING SLEEP LOCK RESET...
  • Page 34 ON/OFF TEMP AUTO COOL HEAT MODE TIMER SWING CLOCK AUTO SLEEP HEALTH LOCK RESET...
  • Page 35 AUTO COOL HEAT ON/OFF TEMP MODE TIMER SWING CLOCK HEALTH SLEEP AUTO LOCK RESET...
  • Page 36 AUTO COOL HEAT ON/OFF TEMP MODE TIMER SWING CLOCK SLEEP HEALTH AUTO LOCK RESET...
  • Page 37 AUTO COOL HEAT ON/OFF TEMP MODE TIMER SWING CLOCK SLEEP HEALTH AUTO LOCK RESET...
  • Page 38 ON/OFF TEMP MODE TIMER SWING CLOCK HEALTH SLEEP LOCK RESET...
  • Page 39 ON/OFF TEMP MODE TIMER SWING CLOCK HEALTH SLEEP LOCK RESET...
  • Page 41 ON/OFF TEMP MODE TIMER SWING CLOCK SLEEP HEALTH LOCK RESET...
  • Page 42 ON/OFF TEMP MODE TIMER SWING CLOCK HEALTH SLEEP LOCK RESET...
  • Page 43 ON/OFF TEMP MODE TIMER SWING CLOCK HEALTH SLEEP LOCK RESET...
