ASROCK M3A-GLAN Brochure

M3A-GLAN
AMD 480X CrossFire
Product Brief
- Supports for AM3 / socket AM2+ / AM2
processors
- Supports Dual Channel DDR2 1066
- PCIE Gigabit LAN
- Supports ASRock Instant Boot, Instant Flash,
OC Tuner, Smart BIOS, Intelligent Energy Saver
The specification is subject to change without notice. The brand and product names are trademarks of their
respective companies. Any configuration other than original product specification is not guaranteed.
TM
+ SB600 Chipsets
w ww.as rock.com
Detail Specification
Platform
- ATX Form Factor: 12.0-in x 7.8-in, 30.5 cm x 19.8 cm
- Support for Socket AM2+ / AM2 processors: AMD
CPU
Phenom TM FX / Phenom / Athlon 64 FX / Athlon 64 X2
Dual-Core / Athlon X2 Dual-Core / Athlon 64 / Sempron
processor
- Support for AM3 processors: AMD Phenom
and Athlon II X4 / X3 / X2 processors
- AMD LIVE! TM
- Supports AMD's Cool 'n' Quiet Technology
- FSB 1000 MHz (2.0 GT/s)
- Supports Untied Overclocking Technology
- Supports Hyper-Transport Technology
Chipset - Northbridge: AMD 480X CrossFire
- Southbridge: AMD SB600
- Dual Channel DDR2 memory technology
Memory
- 4 x DDR2 DIMM slots
- Supports DDR2 1066/800/667/533 non-ECC,
un-buffered memory
- Max. capacity of system memory: 16GB
- 1 x PCI Express x16 slot
Expansion Slot
- 2 x PCI Express x1 slots
- 3 x PCI slots
Audio - 5.1 CH Windows
(ALC662 Audio Codec)
LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/s
- Realtek RTL8111DL
- Supports Wake-On-LAN
ASRock HD 6CH I/O
Rear Panel I/O
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x Serial Port: COM1
- 1 x Parallel Port (ECP/EPP Support)
- 6 x Ready-to-Use USB 2.0 Ports
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and
SPEED LED)
- HD Audio Jack: Line in / Front Speaker / Microphone
Connector - 4 x SATAII 3.0 Gb/s connectors, support RAID (RAID 0,
RAID 1 and RAID 10), NCQ, AHCI and "Hot Plug"
functions
- 1 x ATA133 IDE connector (supports 2 x IDE devices)
- 1 x Floppy connector
- 1 x IR header
- CPU/Chassis/Power FAN connector
- 24 pin ATX power connector
- 4 pin 12V power connector
- CD in header
- Front panel audio connector
- 2 x USB 2.0 headers (support 4 USB 2.0 ports)
BIOS Feature - 4Mb AMI BIOS
- AMI Legal BIOS
- Supports "Plug and Play"
- ACPI 1.1 Compliance Wake Up Events
- Supports jumperfree
- SMBIOS 2.3.1 Support
- CPU Voltage Multi-adjustment
- Supports Smart BIOS
Support CD
- Drivers, Utilities, AntiVirus Software (Trial Version)
- ASRock OC Tuner
Unique Feature
- Intelligent Energy Saver
- Instant Boot
- ASRock Instant Flash
- Hybrid Booster:
- CPU Frequency Stepless Control
- ASRock U-COP
- Boot Failure Guard (B.F.G.)
- ASRock AM2 Boost: ASRock Patented Technology
to boost memory performance up to 12.5%
- CPU Temperature Sensing
Hardware Monitor
- Chassis Temperature Sensing
- CPU/Chassis/Power Fan Tachometer
- CPU Quiet Fan
- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore
OS - Microsoft ® Windows
Vista TM / Vista
Certifications - FCC, CE, WHQL
- Quick Installation Guide, Support CD, I/O Shield
Accessories
- ATA 133 cable
- 1 x SATA data cable (optional)
- 1 x SATA 1 to 1 power cable (optional)
TM
II X4 / X3
Ready
TM Chipset
®
Vista™ Premium Level HD Audio
® XP / XP Media Center / XP 64-bit /
TM 64-bit compliant
