ASROCK G31M-VS Brochure

G31M-VS
®
Intel G31+ ICH7 Chipsets
Product Brief
- Supports FSB1333/1066/800 MHz
®
- Intel Graphics Media Accelerator 3100,
DirectX 9.0, Max. shared memory 384MB
- Supports ASRock Instant Boot
- Supports Smart BIOS, ASRock OC Tuner
- Supports Intelligent Energy Saver
The specification is subject to change without notice. The brand and product names are trademarks of their
respective companies. Any configuration other than original product specification is not guaranteed.
www.as rock.com
Detail Specification
- Micro ATX Form Factor: 8.8-in x 6.7-in, 22.4 cm x 17.0 cm
Platform
CPU - LGA 775 for Intel
2 Duo / Pentium
®
Celeron , supporting Dual Core Wolfdale processors
- Supports CPU power up to 65W
- Supports FSB1333/1066/800 MHz
- Supports Hyper-Threading Technology
- Supports Untied Overclocking Technology
- Supports EM64T CPU
Chipset - Northbridge: Intel
- Southbridge: Intel
- Dual Channel DDR2 memory technology
Memory
- 2 x DDR2 DIMM slots
- Supports DDR2 800/667 non-ECC, un-buffered memory
- Max. capacity of system memory: 8GB
- 1 x PCI Express x16 slot
Expansion Slot
- 1 x PCI slot
®
- Intel Graphics Media Accelerator 3100
Graphics
- Pixel Shader 2.0, DirectX 9.0
- Max. shared memory 384MB
- 5.1 CH Windows
Audio
(Realtek ALC662 Audio Codec)
LAN
- Realtek PCIEx1 LAN 8102EL
- Speed: 10/100 Ethernet
- Supports Wake-On-LAN
Rear Panel I/O
I/O Panel
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x Serial Port: COM1
- 1 x VGA Port
- 4 x Ready-to-Use USB 2.0 Ports
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)
- HD Audio Jack: Line in / Front Speaker / Microphone
Connector
- 2 x SATAII 3.0 Gb/s connectors
(No support for RAID and "Hot Plug" functions)
- 1 x ATA100 IDE connector (supports 2 x IDE devices)
- 1 x Print port header
- CPU/Chassis FAN connector
- 24 pin ATX power connector
- 4 pin 12V power connector
- CD in header
- Front panel audio connector
- 2 x USB 2.0 headers (support 4 USB 2.0 ports)
BIOS Feature
- 4Mb AMI BIOS
- AMI Legal BIOS
- Supports "Plug and Play"
- ACPI 1.1 Compliance Wake Up Events
- Supports jumperfree
- SMBIOS 2.3.1 Support
- VCCM Voltage Multi-adjustment
- Supports Smart BIOS
Support CD
- Drivers, Utilities, AntiVirus Software (Trial Version)
- ASRock OC Tuner
Unique Feature
- Intelligent Energy Saver
- Instant Boot
- Hybrid Booster:
- CPU Frequency Stepless Control
- ASRock U-COP
- Boot Failure Guard (B.F.G.)
- CPU Temperature Sensing
Hardware Monitor
- Chassis Temperature Sensing
- CPU Fan Tachometer
- Chassis Fan Tachometer
- CPU Quiet Fan
- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore
®
OS - Microsoft Windows
TM
Vista 64-bit compliant
Certifications - FCC, CE
- Quick Installation Guide, Support CD, I/O Shield
Accessories
- ATA 100 Cable (Optional)
- 1 x SATA Data Cable (Optional)
- 1 x SATA 1 to 1 Power Cable (Optional)
® Dual Core Core TM 2 Extreme / Core TM
® Dual Core / Celeron ® Dual Core /
®
G31
®
ICH7
® Vista TM Premium Level HD Audio
® TM
2000 / XP / XP 64-bit / Vista /
