Sennheiser MKE 300 Product Sheet

MKE 300
Microphones |
General Description
The MKE 300 has been specially designed for use on film and video
cameras/camcorders. It is fitted onto the camera's flashmount and by
virtue of its super-cardioid/lobar pick-up pattern picks up the sound
coming from the direction the camera is pointing at. Colour: anthracite.
Features
High directivity
Sprung-mounted capsule ensures effective suppression of handling noise
Integral power supply using an LR 44 battery (button cell)
On/off switch with battery status indication
Flashmount adaptor
Quality sound with picture
Delivery includes: 1 MKE 300 with integral foam windshield and
connection cable, 1 protection case
Back-Electret Condenser Microphone
Technical Data
Pick-up pattern ............................................... super-cardioid/lobar
Frequency response ..................................150 – 17,000 Hz ± 3 dB
Sensitivity (free field, no load, 1 kHz)........... 16 mV/Pa ± 2.5 dB
Nominal impedance ................................................................. 200 Ω
Min. terminating impedance ..................................................2.7 kΩ
Equivalent noise level
A-weighted (DIN IEC 651)........................................................ 18 dB
CCIR-weighted (CCIR 468-3).................................................... 28 dB
Max. SPL (1 kHz)...............................................116 dB (THD = 1 %)
Power supply ................................................................. 1.5 V battery
Battery life .................................................................................. 200 h
Connector ..........................................................3.5 mm Ø mono jack
Cable.................................................................................. helical cable
Dimensions ...........................................................230 x 65 x 50 mm
Weight ............................................................................. approx. 60 g
Profile
Super-cardioid/lobar directional microphone, frequency re -
s ponse 150 – 17,000 Hz ± 3 dB, sensitivity (free field, no load)
16 mV/Pa ± 2.5 dB at 1 kHz, nominal impedance 200 Ω, min.
terminating impedance 2.7 kΩ, max. SPL 116 dB at 1 kHz
(THD = 1 %), power supply 1.5 V battery, battery life 200 h,
3.5 mm Ø mono jack plug, helical cable, dimensions 230 x 65
x 50 mm, weight approx. 60 g.
Cat. No. 003171
