Page 2: Dlp2010 Light Control Evm Overview
DLP2010 Light Control EVM Overview This user’s guide presents an overview of the DLP2010 Light Control evaluation module (EVM) and a general description of the main features and functions. It explains the first steps to get started, and provides a detailed description of the push buttons function, the on board LEDs, and the main connectors. -
Page 3: Safety Instructions
2 LED which may be harmful to the eye. WARNING Observe handling precautions. Electrostatic sensitive devices. Applicable Documents The following documents are applicable to the DLP2010 Light Control EVM and are available on TI.com (www.ti.com). • DLP2010 (0.2 WVGA) DMD data sheet (DLPS046B) •... -
Page 4: What Is In The Dlp2010 Light Control Evm
What is in the DLP2010 Light Control EVM? www.ti.com What is in the DLP2010 Light Control EVM? The DLP2010 Light Control module consists of three subsystems: • Light engine: Includes the optics, red, green, and blue LEDs, and the 854 × 480 (WVGA) DMD. -
Page 5: Light Engine
This quick-start assumes default conditions as shipped. 1. Power up the DLP2010 Light Control EVM by applying an external DC power supply (19 V DC, 3.42 A) to the J10 connector. The P5V_VIN (D5) and P3P3V_SB (D6) LED will turn on to indicate that 5-V and 3.3-V standby power is applied. - Page 6 NOTE: The system is designed to operate also with an external 12-V DC power supply. 2. Move the SW_ONOFF switch to the ON position to turn the DLP2010 Light Control EVM on. When the DLP2010 Light Control EVM is turned on, the PROJ_ON LED D3 will turn on.
-
Page 7: Circuit Description
Change LED current total 7 steps PB_RIGHT1 Change of volume when HDMI input is selected Connectors on DLP2010 Light Control Display board Table 5. Installed Connectors on the DLP2010 Light Control Display Board INSTALLED SWITCHES/PUSH BUTTONS DESCRIPTION Connector for the DMD flex cable... -
Page 8: Evm Setup
DLP2010 Light Cotnrol GUI, HDMI, audio and the connector for the DLP2010 Light Control Display board. The main board also contains the switch to turn on the projector in case the DLP2010 Light Control Display board and the engine is connected. - Page 9 The main and display board connect together via J5 and J9. Note that the main board connector J5 on the DLP2010 Light Control Display board is on the bottom, while the LED and Flex cable connectors are on the top as shown in Figure 6 DLPU069B –...
- Page 10 Figure 6. DLP2010 Light Control Connections The optical engine contains the DLP2010 DMD and the flash device for the DLPC3470 which will be connected via the flex cable. The LED adapter board is connecting the three LEDs with the LED connector on the DLP2010 Light Control Display board.
- Page 11 Figure 8. DLP2010 Light Control complete EVM Ensure that everything is setup correctly before continuing. Verify that the flex cable is connected correctly to the DMD and the DLP2010 Light Control Display board. DLPU069B – July 2018 – Revised February 2019 DLP2010 Light Control EVM User’s Guide...
- Page 12 Changed J10 connector description from "5-V" to "19-V" in Table 3 ..................• Added note for board modification on Rev A Revision History DLPU069B – July 2018 – Revised February 2019 Submit Documentation Feedback Copyright © 2018–2019, Texas Instruments Incorporated...
