Carefully read the operating instructions before using the appliance.
Features, technical information and images may vary depending on model
This Refrigerator/Freezer can be switched on using the thermostat inside the refrigerator compartment.
The temperature for both compartments, Refrigerator and Freezer, is also regulated from the same
thermostat.
FREEZING FRESH FOOD
Place the fresh food to be frozen on the freezer compartment grid. Avoid direct contact with already
frozen food. To freeze the quantity of food shown on the serial tag, move the freezer grid to the upper
position and rotate the mid position thermostat knob towards the lower values (e.g.: from 3-5/MED to
1/MIN).
After 24 hours the food will be frozen. Move the thermostat knob back to the original position.
PRODUCT SHEET
D
GB
F
NL
E
A. Refrigerator compartment
1. Crisper drawers
2. Crisper shelf
3. Shelves / Racks
4. Thermostat unit with light
5. Door trays
6. Bottle rack
9. Removable bottle holder
8. Rating plate (at the side of
crisper)
Least cold zone
Intermediate temperature zone
Coldest zone
B. Freezer compartment
9. Freezer compartment grid
10. Freezing area
11. Area for the conservation of
frozen/deep-frozen food
12. Ice cube tray
13. Freezer compartment inner door
P
I
GR
GB
Advertisement
Related Manuals for Smeg FR270AP
Summary of Contents for Smeg FR270AP
- Page 1 PRODUCT SHEET Carefully read the operating instructions before using the appliance. Features, technical information and images may vary depending on model This Refrigerator/Freezer can be switched on using the thermostat inside the refrigerator compartment. The temperature for both compartments, Refrigerator and Freezer, is also regulated from the same thermostat.
-
Page 2: Table Of Contents
INSTRUCTIONS FOR USE BEFORE USING THE APPLIANCE SAFEGUARDING THE ENVIRONMENT PRECAUTIONS AND GENERAL RECOMMENDATIONS FIRST USE CLEANING AND MAINTENANCE IF THE APPLIANCE IS NOT GOING TO BE USED IN CASE OF POWER FAILURES OPERATION OF THE REFRIGERATOR AND FREEZER COMPARTMENT REFRIGERATOR COMPARTMENT FREEZER COMPARTMENT DEFROSTING THE FREEZER COMPARTMENT... -
Page 3: Before Using The Appliance
BEFORE USING THE APPLIANCE • Your new appliance is designed exclusively for domestic use. To ensure best use of your appliance, carefully read the operating instructions which contain a description of the product and useful advice. Keep these instructions for future reference. SAFEGUARDING THE ENVIRONMENT 1. - Page 4 PRECAUTIONS AND GENERAL RECOMMENDATIONS INSTALLATION • The appliance must be handled and installed by two or more persons. • Be careful not to damage the floors (e.g. parquet) when moving the appliance. • During installation, make sure the appliance does not damage the power cable. •...
-
Page 5: First Use
FIRST USE Connect the appliance to the mains power supply. The ideal temperatures for preserving food have already been set at the factory (3-5/MED). Note: After switching the appliance on, it will be necessary to wait for 2 to 3 hours before a temperature suitable for a standard appliance load is reached. -
Page 6: Refrigerator Compartment
REFRIGERATOR COMPARTMENT Refrigerator compartment defrosting is completely automatic. Droplets of water on the rear wall inside the refrigerator compartment indicate that the automatic defrost phase is in progress. The defrost water is automatically run into a drain hole and collected in a container, where it evaporates. -
Page 7: Troubleshooting Guide
STORING FOOD Wrap food so that no water, moisture or condensate can enter; this will prevent odours or aromas going from one part to another in the refrigerator, ensuring better preservation of frozen foods. Never place hot food in the freezer. Cooling hot foods before freezing saves energy and prolongs the life of the appliance.
