PRODUCT DESCRIPTION
A. Refrigerator Compartment
1. Crisper drawer
2. Shelves / Shelf area
3. Thermostat control knob/light
4. Door trays
5. Bottle rack
6. Removable bottle restraint
7. Rating plate (at the side of crisper drawer)
8. Ice cube tray
9. Low Temperature compartment door
B. Low temperature compartment if
present
Coldest zone
Least cold zone
Note: The number of shelves and type of
accessories may vary, depending on the model.
All shelves, door trays and racks are removable.
Important: Refrigerator accessories must not
be washed in a dishwasher.
CONTROLS
A. Thermostat knob
B. Light switch
D. Thermostat control reference
E. Light bulb (max 15 W)
Important:
12
Close the appliance door!
Advertisement
Table of Contents
Related Manuals for Smeg FR132AP
Summary of Contents for Smeg FR132AP
-
Page 1: Product Description
PRODUCT DESCRIPTION A. Refrigerator Compartment 1. Crisper drawer 2. Shelves / Shelf area 3. Thermostat control knob/light 4. Door trays 5. Bottle rack 6. Removable bottle restraint 7. Rating plate (at the side of crisper drawer) 8. Ice cube tray 9. -
Page 2: Before Using The Appliance
BEFORE USING THE APPLIANCE • This appliance is intended to be used in household and similar applications such as - staff kitchen areas in shops, offices and other working environments; - farm houses and by clients in hotels, motels and other residential type environments; - bed and breakfast type environments;... -
Page 3: Precautions And General Recommendations
PRECAUTIONS AND GENERAL RECOMMENDATIONS INSTALLATION • The appliance must be handled and installed by two or more persons. • Be careful not to damage the floors (e.g. parquet) when moving the appliance. • During installation, make sure the appliance does not damage the power cable. •... -
Page 4: How To Operate The Refrigerator Compartment
HOW TO OPERATE THE REFRIGERATOR COMPARTMENT This appliance is an automatic refrigerator or a refrigerator with a star low temperature compartment. Defrosting of the refrigerator compartment is completely automatic. The refrigerator can operate at ambient temperatures between +16°C and +32°C. Switching on the refrigerator for the first time Insert the plug into the mains socket. -
Page 5: How To Operate The Low Temperature Compartment
HOW TO OPERATE THE LOW TEMPERATURE COMPARTMENT The low temperature compartment, if present, is a star compartment. For recommended storage times for frozen foods, see the packaging of individual food products. When purchasing frozen food products: • Make sure the packaging is not damaged, since the product quality may have deteriorated. -
Page 6: How To Defrost And Clean The Low Temperature Compartment
HOW TO DEFROST AND CLEAN THE LOW TEMPERATURE COMPARTMENT For optimum performance, we recommend the low temperature compartment is defrosted at least twice a year, or when the ice on the walls reaches a thickness of about 3mm. If possible, defrost the freezer when it is nearly empty. 1. -
Page 7: Cleaning And Maintenance
CLEANING AND MAINTENANCE • Clean the air vents and condenser at the rear of the appliance regularly with a vacuum cleaner or brush • Clean the outside using a soft cloth For long vacations 1. Empty the refrigerator and low temperature compartments. -
Page 8: Troubleshooting Guide
TROUBLESHOOTING GUIDE 1.The appliance is not working. • Is there a power failure? • Is the plug properly inserted in the socket? • Is the main power switch on? • Has the fuse blown? • Is the thermostat set to •? 2. -
Page 9: After Sales Service
AFTER-SALES SERVICE Before contacting the After Sales Service: 1. See if you can solve the problem yourself with the help of the Troubleshooting guide. 2. Switch the appliance off and then on again to see if the problem has been solved. If it has not, switch off the appliance again and repeat the operation after one hour. -
Page 10: Electrical Connection For Great Britain And Ireland Only
ELECTRICAL CONNECTION FOR GREAT BRITAIN AND IRELAND ONLY Warning - this appliance must be earthed Fuse replacement If the mains lead of this appliance is fitted with a BS 1363A 13amp fused plug, to change a fuse in this type of plug use an A.S.T.A. - Page 11 UNDER COUNTERS Super SETMO SYSTEM...
- Page 12 min 40 mm 3 mm N° 1 N° 10 - Ø 3,5 x 14 N° 5 N° 2...
- Page 15 8 x 3,5 x 14 (12)
- Page 18 N 2 Ø 3,5 x 14...
- Page 19 N 2 Ø 3,5 x 14...
- Page 21 X = 3 mm...
- Page 22 150*...
- Page 23 135* 185* 100 + b 150 + b...
- Page 24 > 136 > 186* 185*...
- Page 25 Max 30 mm...
- Page 30 RUS BG 5019 102 00113 Printed in Italy 04/04...
