- Page 1 MENU 10163.3ETsHbDpQS (BOF 5541S) 10163.3ETsHbDpQW (BOF 5541W) (EN) INSTRUCTION MANUAL IO-CBI-0693 / 8072401 (10.2022 / v5)
- Page 2 DEAR CUSTOMER, The oven is exceptionally easy to use and extremely efficient. After reading the instruction manual, operating the oven will be easy. Before being packaged and leaving the manufacturer, the oven was thoroughly checked with regard to safety and functionality. Before using the appliance, please read the instruction manual carefully.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Safety instructions ......................4 Description of the appliance ..................... 8 Installation ......................... 10 Operation ........................... 12 Baking in the oven – practical hints ................21 Test Dishes ........................23 Cleaning maintenance.......................25 Technical data ........................30... -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS Warning: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or... - Page 5 SAFETY INSTRUCTIONS Warning: Ensure that the appliance is switched off before replacing the lamp to avoid the possibillity of electric shock. You should not use steam cleaning devices to clean the appliance. ● Ensure that small items of household equipment, including connection leads, do not touch the hot oven as the insulation material of this equipment is usually not resistant to high temperatures. ● Do not leave the oven unattended when frying. Oils and fats may catch fire due to overheating or boiling over. ● Do not put pans weighing over 15 kg on the opened door of the oven. ● Do not use harsh cleaning agents or sharp metal objects to clean the door as they can scratch the surface, which could then result in the glass cracking.
- Page 6 HOW TO SAVE ENERGY Using energy in a respon- sible way not only saves money but also helps the environment. So let’s save energy! And this is how you can do it: ● Do not uncover the pan too often (a watched pot never boils!).
- Page 7 DISPOSAL OF THE APPLIANCE UNPACKING During transportation, protec- Old appliances should not sim- tive packaging was used to ply be disposed of with normal protect the appliance against household waste, but should any damage. After unpack- be delivered to a collection and ing, please dispose of all recycling centre for electric and elements of packaging in a...
-
Page 8: Description Of The Appliance
DESCRIPTION OF THE APPLIANCE Electronic programmer Temperatureregulator Cooker operation signal light L signal light R MENU Oven function Temperature adjust- selector knob ment knob... - Page 9 SPECIFICATIONS OF THE APPLIANCE Cooker fittings: Grill grate Baking tray* (drying rack) Roasting tray* Side racks* *optional...
-
Page 10: Installation
INSTALLATION Installing the oven ● The kitchen area should be dry and aired and equipped with efficient ventillation. When installing the oven, easy access to all control elements should be ensured. ● This is a Y–type design built–in oven, which means that its back wall and one side wall can be placed next to a high piece of furniture or a wall. - Page 11 INSTALLATION Electrical connection ● The oven is manufactured to work with a one-phase alternating current (230V 1N~50 Hz) and is equipped with a 3 x 1,5 mm connection lead of 1.5 mm length with a plug including a protection contact. ● A connection socket for electricity supply should be equipped with a protection pin and may not be located above the...
-
Page 12: Operation
OPERATION Before using the oven for the first time Important! In ovens equipped with the electronic Remove packaging, clean the interior of programmer Ts, the time “0.00” will the oven and the hob. start flashing in the display field upon Take out and wash the oven fittings with connection to the power supply. The programmer should be set with warm water and a little washing–up liq- the current time. - Page 13 OPERATION Electronic timer* Kitchen Timer You can active the Kitchen Timer at any time, regardless of the status of other functions. The Kitchen Timer can be set from 1 minute up to 23 hours and 59 minutes. To set the Kitchen Timer: l Touch , then the display will show MENU...
- Page 14 OPERATION Cancel settings l Set the oven function selector knob and the temperature selector knob in off posi- Timer and delayed timed function settings tion., may be cancelled at any time. l Touch and hold < / > or to mute the MENU alarm. The will be off and the Cancel automatic function settings: l simultaneously touch the <...
- Page 15 OPERATION Electronic timer* Kitchen Timer You can active the Kitchen Timer at any time, regardless of the status of other functions. The Kitchen Timer can be set from 1 minute up to 23 hours and 59 minutes. To set the Kitchen Timer: l Touch , then the display will show MENU...
- Page 16 OPERATION l Set the oven function selector knob and l Use the < / > sensors to select your pre- the temperature selector knob in off posi- ferred brightness: tion., Use > to select the setting 1 to 9 l Touch and hold or simultaneously Use < to select the setting 9 to 1 MENU touch and hold <...
- Page 17 OPERATION Oven is off Oven functions and operation. Independent oven lighting Set the knob in this position to light up Oven with automatic air circu- the oven interior. lation (including a fan and ring heater) Rapid Preheating The oven can be warmed up using the bottom Top heater, roaster and fan on.
- Page 18 OPERATION Bottom heater on Convection with ring heating ele- When the knob is set to this position ment and bottom heater on the oven is heated using only the With this setting the convection fan bottom heater. Baking of cakes from and bottom heater are on, which in- the bottom until done (moist cakes creases the temperature at the bottom...
- Page 19 OPERATION Use of the grill The grilling process operates through infrared rays emitted onto the dish by the incandes- cent grill heater. In order to switch on the grill you need to: ● Set the oven knob to the position marked grill ● Heat the oven for approx. 5 minutes (with the oven door shut). ● Insert a tray with a dish onto the appropri- ate cooking level;...
-
Page 20: Baking In The Oven - Practical Hints
BAKING IN THE OVEN – PRACTICAL HINTS Baking ● we recommend using the baking trays which were provided with your cooker; ● it is also possible to bake in cake tins and trays bought elsewhere which should be put on the drying rack; for baking it is better to use black trays which conduct heat better and shorten the baking time;... - Page 21 BAKING IN THE OVEN – PRACTICAL HINTS Oven with automatic air circulation (including a fan and ring heater) Type of Type Temperature Level Time dish of heating (min.) Sponge cake 160 - 200 2 - 3 30 - 50 Muffins 160 - 170 25 - 40 Muffins...
-
Page 22: Test Dishes
TEST DISHES. According to standard EN 60350-1. Baking Type of dish Accessory Level Type Temperature Baking of heating time (min.) Baking tray 160 - 170 25 - 40 Baking tray 155 - 170 25 - 40 Baking tray 155 - 170 25 - 40 Small cakes 2 + 4... - Page 23 TEST DISHES. According to standard EN 60350-1. Grilling Type of dish Accessory Level Type Temperature Time of heating (min.) Wire rack 250 (220*) 1,5 - 2,5 White bread toast Wire rack 250 (220*) 2 - 3 Wire rack + 4 - wire rack roasting tray 1st side 10 - 15 Beef burgers...
-
Page 24: Cleaning Maintenance
CLEANING AND MAINTENANCE Replacing the halogen bulb in the oven By ensuring proper cleaning and mainte- nance of your cooker you can have a sig- Before replacing the halogen bulb, make nificant influence on the continuing fault-free sure the appliance is disconnected from operation of your appliance. the electric mains to avoid a possible Before you start cleaning, the cooker must electric shock. - Page 25 CLEANING AND MAINTENANCE l Ovens in cookers marked with the letter l Ovens in cookers marked with the letters D* are equipped with easily removable Dp* have stainless steel sliding telescopic wire shelf supports. To remove them for runners attached to the wire shelf sup- washing, pull the front catch, then tilt the ports.
- Page 26 CLEANING AND MAINTENANCE Removing the inner panel Door removal 1. Using a flat screwdriver unhook the up- per door slat, prying it gently on the sides In order to obtain easier access to the oven (fig. B). chamber for cleaning, it is possible to remove 2. Pull the upper door slat loose. (fig. B, C) the door.
- Page 27 CLEANING AND MAINTENANCE 3. Pull the inner glass panel from its seat (in the lower section of the door). Re- move the inner panel (fig. D,D1). Note! Risk of damage to glass panel mounting. Do not lift the glass panel up but pull it out. 4.
- Page 28 OPERATION IN CASE OF EMERGENCY In the event of an emergency, you should: ● switch off all working units of the oven ● disconnect the mains plug ● call the service centre ● some minor faults can be fixed by referring to the instructions given in the table below. Before calling the customer support centre or the service centre check the following points that are presented in the table. PROBLEM REASON ACTION...
-
Page 29: Technical Data
TECHNICAL DATA Voltage rating 230V~50 Hz Power rating max. 3,1 kW Cooker dimensions H/W/D 59,5 / 59,5 / 57,5 cm Basic Information: The product meets the requirements of European standards EN 60335- 1; EN60335-2-6. The data on the energy labels of electric ovens is given according to standard EN 60350-1 / IEC 60350-1. These values are defined with a standard workload a with the functions active: bottom and top heaters (conventional heating) and fan assisted heating (forced air heating), if these functions are available.
