Sony TA-F445R Service Manual

SERVICE MANUAL
TA-F440R
AEP Model
SPECIFICATIONS
Amplifier Output
Continuous RMS power output (both channels driven
;
;
simultaneously)
Output jack
Jack type Voltage/impedance
Model for Scandinavian countries, Switzerland, Spain and Portugal
DIN, | kHz 8 ohms 60 W + 60 W
20 Hz— 20 kHz 8 ohms 50 W +50 W
Model for other countries
4 ohms
DIN, 1 kHz
8 ohms
20 Hz— 20 kHz 8 ohms
Input
PHONO (MM) Phono
TUNER, CD, AUX,
TAPE I/DAT,
TAPE 2/MD
75 W +75 W
60 W + 60 W
50 W +50 W
50 kilohms
50 kilohms
100 dB
Sensitivity
2.5 mV
Phono 150 mV
S/N
PHONO (MM) A, 5 mV
TUNER, CD, AUX, TAPE I/DAT, TAPE 2/ND
REC OUT
Model for Scandinavian
countries, Switzerland, Spain
— and Portugal: 8— 16 ohms
Model for other countries:
4—16 ohms
SPEAKERS
Accepts low and high
impedance headphones
Stereo phone
jack
HEADPHONES
Tone controls
Response Turnover frequency
+ 10 dB (100 Hz)
+ 10 dB (10 kHz)
BASS
TREBLE
Harmonic distortion Less than 0.025% at 10 W output
Intermodulation (IM) distortion (60 Hz: 7 kHz = 4:1)
Less than 0.025% at 10 W output
PHONO: RIAA equalization curve
+ 0.5 dB
TUNER, CD, AUX, TAPE 1/DAT,
TAPE 2/MD: 7 Hz— 100 kHz!$ dB
Less than 170 uw V (network A)
50 (8 ohms, 1 KHz)
5 kHz
Frequency response
Residual noise
Damping factor
— Continued on next page —
