Summary of Contents for Goldmund TELOS 800
- Page 2 Please allocate some time to peruse this manual and you shall discover invaluable insights to elevate your auditory enjoyment of the TELOS 800 to unprecedented heights. Since 1978, Goldmund has been dedicated to developing audio equipment of the highest quality and accuracy to immerse you in the most realistic audio experience possible.
- Page 3 All handling must be performed according to the following instructions to avoid impairing the amplifier’s performance. IMPORTANT PLEASE DO NOT CONNECT ANY CABLES OR MOVE ANY PARTS BEFORE READING THE FOLLOWING INSTRUCTIONS User Manual – TELOS 800 - Stereo Power Amplifier - 3 -...
- Page 4 User Manual – TELOS 800 - Stereo Power Amplifier - 4 -...
- Page 5 Please unpack the components with care. CAUTION Should you need to return the TELOS 800 to the factory or your local representative for warranty repair, please be aware that it must be repacked using the original packaging. This packaging has been designed to specifically safeguard your TELOS 800 during transit. Utilizing alternative packaging is likely to result in damage and invalidate warranty coverage.
- Page 6 The TELOS 800 amplifier, as all high quality amplifiers, generates a substantial amount of heat when operating at high levels and necessitates adequate natural ventilation. Proper cooling of the heat sinks is mandatory. Placing temperature-sensitive equipment atop the amplifier is strongly discouraged.
- Page 7 If used with an analogue signal, connect the interconnect between the preamp and each power amp and set the TELOS 800 in analogue mode. You may either use the RCA female socket or the XLR. The XLR socket, especially useful in professional installations, is wired as follows: 1.
-
Page 8: Important Note
Connect the speaker cables to the Left & Right red and black binding post terminals at the rear of the amplifier, or to the Left & Right 4B type connectors using Goldmund high-definition speaker cables. The 2 separate binding post 5-way output and Goldmund 4B type output connectors are connected internally in parallel. - Page 9 If the digital input is not used, the orange LED is off, showing there is no lock and the amplifier • Push both buttons simultaneously in remains muted until a lock is found. The LED will turn on as soon as the TELOS 800 receives order to turn off the amplifier. a digital input.
- Page 10 Left button: to navigate into the menu to select the input, and screen brightness adjustment. • Right button: to select the digital S/PDIF input, analogue input (RCA & XLR) and mute/unmute the amplifier. User Manual – TELOS 800 - Stereo Power Amplifier - 10 -...
-
Page 11: Warm-Up Sonic Effect
On the input selection menu, one press on the right button moves the Input selection to the right as follow: WARM-UP SONIC EFFECT When the amplifier has not been used recently it will take 10 to 15 minutes for the amplifier to reach optimum operating temperature. User Manual – TELOS 800 - Stereo Power Amplifier - 11 -... - Page 12 WARNING Always turn the power off before cleaning your amplifier. There are no user serviceable parts inside the TELOS 800. Unauthorized servicing or alteration invalidates the manufacturer’s warranty. User Manual – TELOS 800 - Stereo Power Amplifier - 12 -...
-
Page 13: Power Supply
4 x output binding posts (2x red & 2x black ; Left & Right speaker Output) • 2 x output Goldmund speaker 4B type connector (Left & Right speaker Output) • 2 x Analogue RCA input (unbalanced connector, Left & Right) •... - Page 14 44 W x 32 H x 45.2 D (cm) – 17.3 W x 13 H x 17.8 D (inch) • Visit our website at www.goldmund.com • 57 kg User Manual – TELOS 800 - Stereo Power Amplifier - 14 -...
