Orion Cobalt CTW101 Manual

Bullet tweeters
Hide thumbs

Advertisement

Quick Links

Download this manual
CTW101
3.75"
BULLET tWEETERS

Advertisement

loading

Related Manuals for Orion Cobalt CTW101

Summary of Contents for Orion Cobalt CTW101

  • Page 1 CTW101 3.75” BULLET tWEETERS...
  • Page 2 Thank you for purchasing this Orion product. Orion products are specif ically engineered and designed for the mobile audio environment. This manual contains important information about installation, set-up procedures and integrating your new Orion product into your vehicle. With proper care and installation, your new product will provide you with many years of high performance listening enjoyment.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION......................2 SPECIFICATIONS......................3 SPEAKER DIAGRAM.....................4 CHOOSING A LOCATION.....................5 INSTALLATION......................6 - 7 TROUBLESHOOTING....................8 WARNING/DISCLAIMER....................9 WARRANTY........................10 WHAT’S IN THE BOX 2 x Bullet Tweeters 6 x Mounting Screws 6 x Speed Clips 1 x Window Sticker 1 x Owners Manual...

  • Page 4: Specifications

    SPECIFICATIONS Specifications CTW101 RMS Power Watts MAX Music Power Watts Nom Impedance (Ohm) Voice Coil 1” Magnet Structure 20 Oz Frequency Response 2kHz - 20kHz SPL(dB) Overall Depth 43.8mm / 1.724” Mounting Depth 38.4mm / 1.512” Overall Diameter 95.7mm / 3.768” Mounting Diameter 71.3mm / 2.807 Recommended Capacitor...

  • Page 5: Speaker Diagram

    SPEAKER DIAGRAM 95.70 71.30 85.35...

  • Page 6: Choosing A Location

    Avoid areas that do not provide a flat, sturdy mounting surface. Orion speakers are designed to fit in almost any factory location. Again, if at all possible, it is recommended that you use a factory location. This applies mostly to later model vehicles. For those...

  • Page 7: Installation

    Remember to check and recheck all connections to insure proper use. Orion recommends using at least 18-gauge wire with your new speaker system. Thinner gauge wire may easily be severed and can cause damage to your system should any bare wire come in contact with the vehicle’s chassis.
  • Page 8 INSTALLATION CONTINUED Make sure that your audio system is off while installing and connecting your new Orion speakers. Failure to do so could result in damaging the speaker beyond repair. Be sure to route the wires to the speakers with the insulated terminals ending at the speakers.

  • Page 9: Troubleshooting

    TROUBLESHOOTING In the event that your Orion speakers appear to require service, we ask that you f irst do a little troubleshooting to determine if the problem is actually the speaker or a problem located in a different part of the vehicle such as the amplif ier, wiring, fusing or possibly the source unit.

  • Page 10: Warning/Disclaimer

    IMPORTANT: Never cut any metal that is an integral part of the vehicle’s safety or structural support system. If you are unsure, it is best to have the product professionally installed by an Authorized ORION Dealer. Never sacrif ice your safety for sound.

  • Page 11: Warranty

    4. This warranty does not cover car static, electrical interference, adjustments or labor costs for the removal or reinstallation of the unit for repair. 5. The sole responsibility of Orion under this warranty shall be limited to the repair or replacement thereof, at the sole discretion of Orion.
  • Page 12 3130 WEST 15TH AVENUE HIALEAH, FLO RIDA 33012 TEL: 786.464.0247 EMAIL: SUPPO RT@ O RIO NC ARAUDIO .C O M O RIO NC ARAUDIO .C O M PRO UD SPO NSO R O F C opyright O RIO N All righs reserved. Any unauthorized reproduction or use of any O rion logos, images or design elements is strictly prohibited by law.
