OWNER'S MANUAL
FREEZER
Before beginning installation, read these instructions
carefully. This will simplify installation and ensure that the
product is installed correctly and safely. Leave these
instructions near the product after installation for future
reference.
ENGLISH
MFL71737172
Rev.00_031324
Copyright © 2024 LG Electronics Inc. All Rights Reserved.
Scan the QR code to see the manual.
www.lg.com
Advertisement
Table of Contents
Related Manuals for LG GC-B514ELFM
Summary of Contents for LG GC-B514ELFM
- Page 1 Before beginning installation, read these instructions carefully. This will simplify installation and ensure that the product is installed correctly and safely. Leave these instructions near the product after installation for future reference. ENGLISH www.lg.com MFL71737172 Rev.00_031324 Copyright © 2024 LG Electronics Inc. All Rights Reserved.
-
Page 2: Table Of Contents
Moving the Appliance for Relocation ............14 OPERATION Before Use ......................15 Product Features....................17 Control Panel ....................18 Door Handle .....................19 Icemaker ......................19 Shelf ........................21 Freezer Drawer....................21 Air Filter ......................22 SMART FUNCTIONS LG ThinQ Application ..................23 Smart Diagnosis ....................24 MAINTENANCE Cleaning ......................26 TROUBLESHOOTING Before Calling for Service................27... -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. Safety Messages This symbol is displayed to indicate matters and operations that can cause risk. - Page 4 SAFETY INSTRUCTIONS responsible for their safety. Children should be supervised to ensure that they do not play with the appliance. • This appliance is intended to be used in household and similar applications such as: - staff kitchen areas in shops, offices and other working environments;...
- Page 5 • Do not clean the appliance with brushes, cloths or sponges with rough surfaces or which are made of metallic material. • Only qualified service personnel from LG Electronics service centre should disassemble, repair, or modify the appliance. Contact an LG Electronics customer information centre if you move and install the appliance in a different location.
- Page 6 • Ensure that the outlet socket is properly grounded, and that the earth pin on the power cord is not damaged or removed from the power plug. For more details on grounding, inquire at an LG Electronics customer information centre.
- Page 7 • Do not bend the power cable excessively or place a heavy object on it. • Immediately unplug the power plug and contact an LG Electronics customer information centre if you detect a strange sound, odour, or smoke coming from the appliance.
- Page 8 SAFETY INSTRUCTIONS • Do not place hands or metallic objects inside the area emitting the cold air, cover or heat releasing grille on the back. • Do not apply excessive force or impact to the back cover of the appliance. •...
-
Page 9: Caution
SAFETY INSTRUCTIONS CAUTION CAUTION • To reduce the risk of minor injury to persons, malfunction, or damage to the product or property when using this product, follow basic precautions, including the following: Installation • After unpacking, check the appliance for any damage that may have occurred during transit. - Page 10 They may shatter if exposed to sudden temperature changes. • Do not insert the shelves upside down. The shelves may fall. • To remove frost from the appliance, contact an LG Electronics customer information centre. • Dispose of the ice inside the ice bin in the freezer compartment...
-
Page 11: Installation Before Installation
INSTALLATION INSTALLATION Before Installation changes. This may result in decrease or increase of the appliance width. Dimensions and Clearances Too small of a distance from adjacent items may Ambient Temperature result in the degradation of freezing capability and increased electricity costs. Allow over 50 mm of •... - Page 12 Minimum 50 hand side to suit your kitchen design. NOTE • Reversing the doors must be performed by the qualified personnel of LG Electronics. If not, the 110° doors will not be covered by the warranty. 1643 NOTE Connecting the Freezer and •...
-
Page 13: Levelling The Appliance
INSTALLATION Levelling the Appliance Open the doors and check to make sure that they close easily. Before Beginning When the appliance doors appear to be uneven, Door Alignment follow the instructions below to align the doors. If the door of the appliance is not level, adjust the NOTE difference in the height of appliance door. -
Page 14: Turning On The Power
INSTALLATION Use the spanner to fasten the keeper nut by Fix the power plug. turning it to the right. • Models with a power plug hook: Pull the power plug out, insert and fix it into the power plug hook at the rear or on top of the appliance. -
Page 15: Operation
The alarm sounds if the door is left open or not completely closed. Storing Foods Effectively NOTE • Contact the LG Electronics customer information • Food may freeze or spoil if stored at the wrong centre if the alarm sound continues even after temperature. Set the appliance to the correct closing all doors. - Page 16 OPERATION • Store raw meat and fish in suitable containers in CAUTION the appliance, so that it is not in contact with or drip onto other food. • To remove the drawers, first remove the food • Avoid refreezing any food which has been from drawers and then pull out the drawers completely thawed.
-
Page 17: Product Features
OPERATION Product Features The appearance or components of the appliance may differ from model to model. Interior *1 This feature is only available on some models. Door Handle Pull the handle to open the door. Icemaker Stores ice produced by the manually icemaker. •... -
Page 18: Control Panel
OPERATION Control Panel The actual control panel may differ from model to model. Control Panel and Functions *1 This feature is only available on some models. Freezer Press this button repeatedly to select a desired temperature between -15 °C and -23 °C. •... -
Page 19: Door Handle
Wi-Fi The Wi-Fi button, when used with the LG ThinQ app, allows the refrigerator to connect to a home Wi- Fi network. Refer to Smart Functions for information on the initial setup of the application. - Page 20 OPERATION Hold the handle of ice tray and pull it out. Lift and remover the ice storage bin slightly. Fill the ice tray with potable water up to the WARNING water line. • Fill with potable water only. CAUTION • Be careful not to twist the ice tray with force as it can be broken.
-
Page 21: Shelf
OPERATION Fill the ice tray with water up to the marked water Tilt the shelf and remove it by pulling it out. line. WARNING • Fill with potable water only. Refit the shelf by sliding it inward until the shelf snaps into the frame. -
Page 22: Air Filter
OPERATION Air Filter Dry it using a hair dryer or by exposing it to sunlight. The filter is reusable. Reusing the Air Filter You can remove the odors absorbed by the Air Filter and reuse it. Pull out the drawer in the on the bottom compartment. -
Page 23: Smart Functions
Search for and install the LG ThinQ application from the Google Play Store or Apple App Store on a smartphone. Run the LG ThinQ application and sign in with your existing account or create an LG account to sign in. -
Page 24: Smart Diagnosis
Internet service provider or refer to your Open Source Software Notice wireless router manual. Information • LG ThinQ is not responsible for any network connection problems or any faults, To obtain the source code that is contained in this malfunctions, or errors caused by network product, under GPL, LGPL, MPL, and other open connection. - Page 25 *1 This control panel is only available on some models. Follow the instructions below to use the audible diagnosis method. • Launch the LG ThinQ application and select the Smart Diagnosis feature in the menu. Follow the instructions for audible diagnosis provided in the LG ThinQ application.
-
Page 26: Maintenance Cleaning
MAINTENANCE MAINTENANCE Cleaning Cleaning the Interior • When removing a shelf or drawer from inside General Cleaning Tips the appliance, remove all stored foods from the shelf or drawer to prevent injury or damage to • Performing manual defrosting, maintenance or the appliance. -
Page 27: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING Before Calling for Service Cooling Symptoms Possible Cause & Solution There is no Is there a power interruption? refrigeration or • Check the power of other appliances. freezing. Appliance is unplugged. • Plug the power plug in the outlet properly. A fuse in your home may be blown or the circuit breaker tripped. - Page 28 Lamp failure appliance does not • Close the door and re-open. If the lamp does not turn on, please contact turn on. the LG Electronics customer information centre. Do not attempt removal of the lamp. Noises Symptoms Possible Cause & Solution...
- Page 29 TROUBLESHOOTING Symptoms Possible Cause & Solution The appliance is noisy Does the rear of the appliance touch the wall? and generates • Adjust the installation position to allow enough clearance around the abnormal sounds. appliance. Are objects scattered behind the appliance? •...
- Page 30 • Find the Wi-Fi network connected to your smartphone and remove it, then not connected to the register your appliance on LG ThinQ. Wi-Fi network. Mobile data for your smartphone is turned on. • Turn off the Mobile data of your smartphone and register the appliance using the Wi-Fi network.
- Page 31 Memo...
