  • Page 1 FUJITSU Server PRIMEQUEST 2000 Series Hardware Installation Manual C122-H007-01EN Download from Www.Somanuals.com. All Manuals Search And Download.

  • Page 2: Preface

    Preface Preface This manual describes the functions and features of the PRIMEQUEST 2000 series. The manual is intended for system administrators. For details on the regulatory compliance statements and safety precautions, see the PRIMEQUEST 2000 Series Safety and Regulatory Information (C122-E171XA).
  • Page 3 Preface Revision History Edition Date Revised location (type) (*1) Description 2014-02-18 *1: Chapter, section, and item numbers in the "Revised location" column refer to those in the latest edition of the document. However, a number marked with an asterisk (*) denotes a chapter, section, or item in a previous edition of the document.
  • Page 4 Similarly, one space line is inserted before and after the alert statement. Only Fujitsu certified service engineers should perform the following tasks on this product and the options provided by Fujitsu. Customers must not perform these tasks under any circumstances.
  • Page 5 Preface List of important alert items This manual does not contain important alert items. Warning labels Never remove the warning labels. Warning label location (the main cabinet top) Warning label location (the main cabinet left) C122-H007-01EN Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 6 Preface Warning label location (PCI_Box) C122-H007-01EN Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 7 For stable operation of the PRIMEQUEST 2000 series server, use only a Fujitsu-certified optional product as an added option. Note that the PRIMEQUEST 2000 series server is not guaranteed to operate with any optional product not certified by Fujitsu. Maintenance Only Fujitsu certified service engineers should perform the following tasks on this product and the options provided by Fujitsu.
  • Page 8 Product and service inquiries For all product use and technical inquiries, contact the distributor where you purchased your product, or a Fujitsu sales representative or systems engineer (SE). If you do not know the appropriate contact address for inquiries about the PRIMEQUEST 2000 series, use the Fujitsu contact line.
  • Page 9 Be sure to keep this manual in a safe and convenient location for quick reference. Fujitsu makes every effort to prevent users and bystanders from being injured and to prevent property damage. Be sure to use the product according to the instructions in this manual.
  • Page 10 Defines the PRIMEQUEST 2000 series related terms and C122-E179EN Glossary abbreviations. Related manuals The following manuals relate to the PRIMEQUEST 2000 series. You can access these manuals at the following site: http://www.fujitsu.com/global/services/computing/server/primequest/ http://manuals.ts.fujitsu.com/ Contact your sales representative for inquiries about the ServerView manuals...
  • Page 11 Provides technical information on using RAID controllers. None Refer to the manual from the SVS-ServerView Suite ServerBooks DVD(Manual)2 supplied with the product or from the following URL: The Fujitsu Technology Solutions manuals server http://manuals.ts.fujitsu.com/ MegaRAID SAS Device Driver Provides technical information on using RAID controllers. None...
  • Page 12 Font or symbols Meaning Example italics Title of a manual that you should refer to See the PRIMEQUEST 2000 Series Installation Manual (C122-E174EN). Window names as well as the names of Click the [OK] button. buttons, tabs, and drop-down menus in windows are enclosed in brackets.
  • Page 13 The PDF file of this manual is intended for display using Adobe® Reader® in single page viewing mode at 100% zoom. This manual shall not be reproduced or copied without the permission of Fujitsu Limited. Copyright 2014 FUJITSU LIMITED C122-H007-01EN...

  • Page 14: Table Of Contents

    Earthquake Preparedness Measures ............................34 Appendix A Racks ......................................35 A.1 Rack Mounting ..................................... 35 A.2 Rack Mounting Requirements ................................35 A.2.1 Requirements for mounting in a Fujitsu 19-inch rack ......................... 35 C122-H007-01EN xiii Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 15 Preface A.2.2 Requirements for mounting in a third party's rack ........................37 C122-H007-01EN Download from Www.Somanuals.com. All Manuals Search And Download.
  • Page 16 Preface Figures FIGURE 1.1 PRIMEQUEST 2400E/2800E front view ........................... 1 FIGURE 1.2 PRIMEQUEST 2400E/2800E rear view ..........................2 FIGURE 1.3 PRIMEQUEST 2400E/2800E top view..........................2 FIGURE 1.4 PRIMEQUEST 2400E/2800E right side view ........................2 FIGURE 1.5 PRIMEQUEST 2800B front view ............................3 FIGURE 1.6 PRIMEQUEST 2800B rear view ............................
  • Page 17 Preface FIGURE 2.24 200 V Redundant Power Feed Configuration (Single power feed, Redundant Power Feed) Power Distribution Box Connection ...................................... 29 FIGURE 2.25 200 V Dual Power Feed Configuration with Power Distribution Box Connection ............29 FIGURE 2.26 When Underfloor Height is less than 300mm (11.8 in) ....................31 FIGURE 2.27 When the under floor height is 300 mm (11.8 in) or more.
  • Page 18 TABLE 2.5 Characteristic Condition of Distribution Panel Breaker ..................... 32 TABLE 3.1 Elevator load conditions ..............................34 TABLE A.1 Recommended racks for mounting ........................... 35 TABLE A.2 PRIMEQUEST 2000 series external dimensions......................35 TABLE A.3 Structural condition of rack ..............................37 C122-H007-01EN xvii Download from Www.Somanuals.com.

  • Page 19: Chapter 1 Installation Data

    CHAPTER 1 Installation Data 1.1 Configuration Contents of Device CHAPTER 1 Installation Data It explains the various data used while installing various drawings for device configuration, device overview, installation specification and layout. Configuration Contents of Device It shows the name and contents of configuration of each device. TABLE 1.1 Name and Contents of Configuration of Each device Equipment Name Content Configuration...

  • Page 20: Figure 1.2 Primequest 2400E/2800E Rear View

    CHAPTER 1 Installation Data 1.2 External Overview of Device FIGURE 1.2 PRIMEQUEST 2400E/2800E rear view FIGURE 1.3 PRIMEQUEST 2400E/2800E top view FIGURE 1.4 PRIMEQUEST 2400E/2800E right side view C122-H007-01EN Download from Www.Somanuals.com. All Manuals Search And Download.

  • Page 21: Figure 1.5 Primequest 2800B Front View

    CHAPTER 1 Installation Data 1.2 External Overview of Device PRIMEQUEST 2800B FIGURE 1.5 PRIMEQUEST 2800B front view FIGURE 1.6 PRIMEQUEST 2800B rear view FIGURE 1.7 PRIMEQUEST 2800B top view C122-H007-01EN Download from Www.Somanuals.com. All Manuals Search And Download.

  • Page 22: Figure 1.8 Primequest 2800B Right Side View

    CHAPTER 1 Installation Data 1.2 External Overview of Device FIGURE 1.8 PRIMEQUEST 2800B right side view C122-H007-01EN Download from Www.Somanuals.com. All Manuals Search And Download.

  • Page 23: External Overview Of Device (Pci_Box)

    CHAPTER 1 Installation Data 1.2 External Overview of Device 1.2.2 External Overview of Device (PCI_Box) Device External Overview (Front view, Rear view, Top view, Right side view) of PCI_Box is shown below. FIGURE 1.9 Front View of PCI_Box FIGURE 1.10 Rear View of PCI_Box FIGURE 1.11 Top View of PCI_Box FIGURE 1.12 Right Side View of PCI_Box C122-H007-01EN...

  • Page 24: Installation Specifications

    CHAPTER 1 Installation Data 1.3 Installation Specifications Installation Specifications This section explains installation specification of each equipment. 1.3.1 Installation specifications (PRIMEQUEST 2400E) TABLE 1.2 Installation Specifications (PRIMEQUEST 2400E) Item Contents External Width 445(17.52) Dimensions Length(*1) 782(30.79) [mm(in.)] Height 438(17.25) 10U Mass [kg(lb)] (*2) 128(282) Conditions for...
  • Page 25 CHAPTER 1 Installation Data 1.3 Installation Specifications *2: Numeric value when each optional device is mounted for maximum number of options. However, rail for mounting rack (5.7kg) and cable type are not included. Mass as per the installation configuration can be calculated using formula as shown below. Device Mass: 78 + (11.1* A) + (2.5* B) + (1.8* C) + (3.3* D) [kg] A= Number of mounted SB (Minimum 1 to Maximum 2) B=Number of mounted IOU (Minimum 1 to Maximum 4)

  • Page 26: Installation Specifications (Primequest 2800E)

    CHAPTER 1 Installation Data 1.3 Installation Specifications 1.3.2 Installation Specifications (PRIMEQUEST 2800E) TABLE 1.3 Installation Specifications (PRIMEQUEST 2800E) Items Contents Dimensions Width 445(17.52) [mm (in.)] Depth (*1) 782(30.79) Length 438(17.25) 10U Mass [kg (lb)] (*2) 150(331) Conditions for Max. calorific Interruptible power source 17,712(16,787) air conditioner...
  • Page 27 CHAPTER 1 Installation Data 1.3 Installation Specifications For 2000 to 3000 m (6562 to 9843 ft) above sea level, temperature range at the time of installation: 5 to 29°C (41 to 84.2°F) Error of + 100m in the sea level settings of the location of installation is permissible. *6: Downtime is the condition in which the device is packed and maintained.

  • Page 28: Installation Specifications (Primequest 2800B)

    CHAPTER 1 Installation Data 1.3 Installation Specifications 1.3.3 Installation Specifications (PRIMEQUEST 2800B) TABLE 1.4 Installation Specifications (PRIMEQUEST 2800B) Items Contents Dimensions Width 445(17.52) [mm (in.)] Depth (*1) 782(30.79) Length 438(17.25) 10U Mass [kg (lb)] (*2) 143(315) Conditions for Max. calorific Interruptible power source 16,992(16,105) air conditioner...
  • Page 29 CHAPTER 1 Installation Data 1.3 Installation Specifications For 1000 to 1500 m (3281 to 4921 ft) above sea level, temperature range at the time of installation: 5 to 33°C (41 to 91.4°F) For 1500 to 2000 m (4921 to 6562 ft) above sea level, temperature range at the time of installation: 5 to 31°C (41 to 87.8°F) For 2000 to 3000 m (6562 to 9843 ft) above sea level, temperature range at the time of installation: 5 to 29°C (41 to 84.2°F)

  • Page 30: Installation Specifications (Pci_Box)

    CHAPTER 1 Installation Data 1.3 Installation Specifications 1.3.4 Installation Specifications (PCI_Box) TABLE 1.5 Installation Specifications (PCI_Box) Item Contents Dimensions Width 482 (18.98) [mm (in)] Depth 740 (29.13) Length 175 (6.89) 4U Mass [kg (lb)] (*2) 35 (77) Conditions Max. calorific value [kJ/h (BTU/h)] 1656 (1570) for air Displacement [m3/min...

  • Page 31: Installation Area

    *12: Value of 1 device Installation Area Here, the installation area and the service area when the PRIMEQUEST 2000 series or the PCI_Box is installed on 19-inch made by Fujitsu rack are explained. The installation area and the service area differ according to the installed 19-inch rack.

  • Page 32: Flow Of Cooling Air And Exhaust Air Of Installation

    CHAPTER 1 Installation Data 1.5 Flow of Cooling Air and Exhaust Air of Installation Flow of Cooling Air and Exhaust Air of Installation Here, the flow of the cooling air and the exhaust of each device are explained. Note Flow of cooling air and exhaust air should be considered while studying the installation of a device. If device is installed without considering them, it may get affected by inhaling the exhaust air from the other device.

  • Page 33: Installation Environment

    CHAPTER 1 Installation Data 1.6 Installation Environment Installation Environment This section describes the installation environment of the base cabinet and PCI_Box. 1.6.1 Dust Suspended Particles Suspended particles in a computer room should not exceed 0.15mg/m . A computer is designed in such a way that it withstands the suspended particles.

  • Page 34: Chapter 2 Connected Information

    2.1 Connection summary CHAPTER 2 Connected Information This section describes the connection summary of cable and cable used in PRIMEQUEST 2000 series. Connection summary This section shows the Device connection summary of PRIMEQUEST 2000 series. FIGURE 2.1 Summary of Device Connection C122-H007-01EN Download from Www.Somanuals.com.

  • Page 35: Connection Of Signal Cable

    “PRIMEQUEST 2000 series system mounting” 2.2.2 Details of external interface connection Mounting position of external interface connecting part of PRIMEQUEST 2000 series is shown in the section below. When calculating the length of the connection cable, you should take account into the mounting position.

  • Page 36: Figure 2.2 External Interface Connection Figure Of (Primequest 2400E (Front Surface))

    CHAPTER 2 Connected Information 2.2 Connection of signal cable External interface connection (PRIMEQUEST 2400E in base cabinet) External interface connection figure of PRIMEQUEST 2400E in base cabinet is shown in the section below. The figure below is uncovered front surface (face). The front cover must be attached in normal operation.

  • Page 37: Figure 2.4 External Interface Connection Figure Of (Primequest 2800E (Front Surface))

    CHAPTER 2 Connected Information 2.2 Connection of signal cable External interface connection (PRIMEQUEST 2800E in base cabinet) External interface connection figure of PRIMEQUEST 2800E in base cabinet is shown in the section below. This figure is uncovered front surface (face). The front cover must be attached in normal operation.

  • Page 38: Figure 2.6 External Interface Connection Figure Of (Primequest 2800B (Front Surface))

    CHAPTER 2 Connected Information 2.2 Connection of signal cable External interface connection (PRIMEQUEST 2800B in base cabinet) External interface connection figure of PRIMEQUEST 2800B in base cabinet is shown in the section below. This figure is uncovered front surface (face). The front cover must be attached in normal operation.

  • Page 39: Figure 2.8 Details Of External Interface (Mmb)

    CHAPTER 2 Connected Information 2.2 Connection of signal cable Details of external interface (MMB) FIGURE 2.8 Details of external interface (MMB) Details of external interface (IOU_1GbE/IOU_10GbE) FIGURE 2.9 Details of external interface (IOU_1GbE) FIGURE 2.10 Details of external interface (IOU_10GbE) Details of external interface (DU) FIGURE 2.11 Details of external interface (DU) C122-H007-01EN...

  • Page 40: Power Cable Connection

    CHAPTER 2 Connected Information 2.3 Power cable connection Details of external interface (PCI_Box) FIGURE 2.12 Details of external interface (PCI_Box) PCIC:PCI slot LNKC:LINK card Power cable connection Input power system of PRIMEQUEST 2000series and PCI_Box is described in this section. 2.3.1 Power Supply Cable Connection (PRIMEQUEST 2400E) Input power system diagram of PRIMEQUEST 2400E is as shown below.

  • Page 41: Figure 2.14 100V Redundant Power Feed Configuration (Single Power Feed, Redundant Power Feed)

    CHAPTER 2 Connected Information 2.3 Power cable connection 100 V Redundant Power Feed Configuration (Single power feed, Redundant Power Feed) It is necessary to arrange four PSUs, two FANUs and four power supply cables (100 V NEMA 5-15P) for 100V redundant power feed configuration (single power feed, redundant power feed). FIGURE 2.14 100V Redundant Power Feed Configuration (Single power feed, Redundant Power Feed) Number Description...

  • Page 42: Figure 2.16 200 V Redundant Power Feed Configuration (Single Power Feed, Redundant Power Feed) With Power Distribution

    CHAPTER 2 Connected Information 2.3 Power cable connection 200 V Redundant Power Feed Configuration (with single power feed, redundant power feed) with Power Distribution Box Connection It is necessary to arrange three PSUs, three FANUs, three Power cables (200 V IEC60320 C20) and two power distribution box (200 V IEC60320 C19×3type) for of 200 V Redundant Power Feed Configuration (single power feed, redundant power feed).

  • Page 43: Power Cables Connections (Primequest 2800E/2800B)

    CHAPTER 2 Connected Information 2.3 Power cable connection 2.3.2 Power Cables Connections (PRIMEQUEST 2800E/2800B) This section shows the figure of input power of PRIMEQUEST 2800E/2800B. Standard Configuration of 200 V (Single power feed and no Redundant Power Feed) with Power Distribution Box Connection It is necessary to arrange three PSUs, three FANUs, three power cables (200 V IEC60320 C20) and two power distribution box (200 V IEC60320 C19×3type) for 200 V standard configuration.

  • Page 44: Figure 2.19 200 V Redundant Power Feed Configuration (Single Power Feed, Redundant Power Feed) With Power Distribution

    CHAPTER 2 Connected Information 2.3 Power cable connection 200 V Redundant Power Feed Configuration (single power feed, redundant power feed) with Power Distribution Box Connection It is necessary to arrange four PSUs, two FANUs, four Power cables (200 V IEC60320 C20) and two power distribution boxes (200 V IEC60320 C19×3type) for 200 V Redundant Power Feed configuration (with single power feed, redundant power feed).

  • Page 45: Power Cable Connections (Pci_Box)

    CHAPTER 2 Connected Information 2.3 Power cable connection 200 V Dual Power Feed Configuration with Power Distribution Box Connection It is necessary to arrange six PSUs, six power cables (200 V IEC60320 C20) and four power distribution boxes (200 V IEC60320 C19×3type) for 200 V dual power feed configuration. When the power distribution box is used, it is necessary to secure the breaker characteristic of distribution panel.

  • Page 46: Figure 2.22 100 V Redundant Power Feed Configuration (Single Power Feed, Redundant Power Feed)

    CHAPTER 2 Connected Information 2.3 Power cable connection 100 V Redundant Power Feed Configuration (single power feed, redundant power feed) It is necessary to arrange two PSUs and two power cables (100 V NEMA 5-15P) for 100 V redundant power feed configuration (single power feed, redundant power feed).

  • Page 47: Figure 2.24 200 V Redundant Power Feed Configuration (Single Power Feed, Redundant Power Feed) Power Distribution Box

    CHAPTER 2 Connected Information 2.3 Power cable connection 200 V Redundant power feed configuration (single power feed, redundant power feed) power distribution box connection It is necessary to arrange two PSUs, two power cables (200 V IEC60320 C14) and power distribution box (200 V IEC60320 C13×4type) for 200 V redundant power feed configuration (single power feed, redundant power supply).

  • Page 48: Connection Specifications Of Input Power

    Connection Specifications of Input Power This section describes the connection specifications of Input power of the base cabinet or PCI_Box of PRIMEQUEST 2000 series. 2.4.1 Input Power Connection Specifications (Base Cabinet) Following table shows the input power connection specifications of the main unit.

  • Page 49: 2.4.3 Power Distribution Box And Distribution Panel

    CHAPTER 2 Connected Information 2.5 Free Access Underfloor Connection of Power Cable 2.4.3 Power Distribution Box and Distribution Panel Following table shows the power supply cable specifications of power distribution box and distribution panel. TABLE 2.4 Power Supply Cable Specifications of Power Distribution Box and Distribution Panel Destination Plug format Remarks...

  • Page 50: Cutoff Characteristics Of Distribution Panel (At The Time Of Connecting Power Distribution Box)

    300 mm (11.8 in) or more Recipient power distribution Remarks The above figure shows an example of 19-inch rack made by Fujitsu Limited mounted with the device. Cutoff Characteristics of Distribution Panel (At the time of connecting power distribution box)

  • Page 51: Figure 2.28 Characteristics Of Breaker Of Distribution Panel

    CHAPTER 2 Connected Information 2.6 Cutoff Characteristics of Distribution Panel (At the time of connecting power distribution box) FIGURE 2.28 Characteristics of Breaker of Distribution Panel Number Description Operating time Minutes Seconds Electric current (Amplification of rated current) C122-H007-01EN Download from Www.Somanuals.com. All Manuals Search And Download.

  • Page 52: Chapter 3 Notes On Carrying In And Installing The Product

    Notes on Carrying In and Installing the Product This chapter provides notes on carrying in and installing the PRIMEQUEST 2000 series server. Elevator Load Conditions The rack with the device mounted is wider than the average computer. Therefore, to use an elevator to carry in the rack, the rack may need the side boards or doors removed before loading on the elevator.

  • Page 53: Appendix A Racks

    The PRIMEQUEST 2000 series (including peripheral devices) has been developed and its operation guaranteed with the basic assumption that it is mounted in a Fujitsu rack. For safe use of a unit mounted in a Fujitsu rack, contact the distributor where you purchased your product, or your sales representative.

  • Page 54: Figure A.1 Example Of Rack Mounting

    Model Mounting area mountable units The bottom of the mounted device must not be below 1U. (*1) PRIMEQUEST 2000 series The top of the mounted device must not be above 1,066 mm from floor. (*2). PCI_Box No mounting requirements (*1) For the models 2742/2737/2724/2642/2624/2616 and PCR M1 742S/724S/642S/624S/616S/742A/724A, the bottom of the mounted device must not be below 2U.

  • Page 55: Figure A.2 Length Of Rack

    Note Fujitsu does not guarantee there will be no problems arising from the mounting of the PRIMEQUEST 2000 series server (including peripheral devices) in a rack manufactured by another company. Examples: Cooling problem due to an insufficient supply of cooling air because of the rack structure, and...

  • Page 56: Figure A.3 Width Of Rack

    Appendix A Racks A.2 Rack Mounting Requirements FIGURE A.2 Length of rack Number Description Front cover Front post Rear post Rear cover Width of rack FIGURE A.3 Width of rack Number Description Front cover Front post Rear post Rear cover Bracket installation area Width of Bracket installation Width of chassis of PRIMEQUEST...

  • Page 57: Figure A.4 Format Of Rack Posts

    Securing the maintenance work area (service area) Secure the service area required for the maintenance work performed by a Fujitsu certified service engineer. Referring to the Fujitsu rack service areas in 1.4 Installation Area...
