P42i-TC Pellet Insert
Check building codes prior to installation.
• Installation MUST comply with local, regional, state and
national codes and regulations.
• Contact local building or 昀椀re o昀케cials about restrictions
and installation inspection requirements in your area.
Tested and approved for wood pellets only. Burning of
any other type of fuel voids your warranty. When burning
higher ash content pellets more frequent cleanings may
be required.
1
Installation Manual
Installation and Appliance Setup
CAUTION
CAUTION
Harman® • P42i Pellet Insert Installation Manual • 2023 -___ • 08/23
Please read this entire manual before
installation and use of this pellet fuel-
burning room heater.
Failure to follow these instructions could
result in property damage, bodily injury
or even death.
• Do not store or use gasoline or other 昀氀ammable vapors
and liquids in the vicinity of this or any other appliance.
• Do not over昀椀re - If any external part starts to glow, you
are over昀椀ring. Reduce feed rate. Over昀椀ring will void
your warranty.
• Comply with all minimum clearances to combustibles
as speci昀椀ed. Failure to comply may cause house 昀椀re.
HOT SURFACES!
Glass and other surfaces are hot during
operation and cool down.
Hot glass will cause burns.
• Do not touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room as
stove.
• Alert children and adults to hazards of high temperatures.
High temperatures may ignite clothing or other
昀氀ammable materials.
• Keep clothing, furniture, draperies and other 昀氀ammable
materials away.
NOTE
To obtain a French translation of this manual, please
contact your dealer or visit www.harmanstoves.com
Pour obtenir une traduction française de ce manuel, s'il
vous plaît contacter votre revendeur ou visitez www.
harmanstoves.com
WARNING
WARNING
8742-901D
