- Page 1 machine numbers H 1934DT H2 0 34 DT H 2 5 3 4 DT H 2539 Y Concierge Direct View Television Receiver i n s t a l l a t i o n & o p e r a t i n g g u i d e / w a r r a n t y...
-
Page 2: Safety Warnings
Consult the dealer or an experienced radio/TV technician for help. • CAUTION: Do not attempt to modify this product in any way without written authorization from Zenith Electronics Corporation. Unauthorized modification could void the user’s authority to operate this product. Concierge is a trademark of Zenith Electronics Corporation. -
Page 3: Important Safety Information
IMPORTANT SAFETY INSTRUCTIONS Important safeguards for you and your new product Your product has been manufactured and tested with your safety in mind. However, improper use can result in potential electrical shock or fire hazards. To avoid defeating the safeguards that have been built into your new product, please read and observe the following safety points when installing and using your new product, and save them for future reference. - Page 4 IMPORTANT SAFETY INSTRUCTIONS (Continued from previous page) 14. Outdoor Antenna Grounding If an outside antenna or cable system is connected to the product, be sure the antenna or cable system is grounded so as to provide some protection against voltage surges and built-up static charges.
-
Page 5: Table Of Contents
Source/Channel Bank keys. The installer remote has Menu, Select, and Adjust Keys (Up/Down/Left/Right arrows) and Source/Channel Bank Keys. The LT1500 Clone Programmer is used to duplicate a TV’s setup and install it on another TV. See your Zenith Dealer. -
Page 6: Antenna
The wire that comes from an off-air antenna or cable service provider. Each end looks like a hex shaped nut with a wire sticking through the middle, and it screws onto the threaded jack on the back of your TV. -
Page 7: Cable Service
AA batteries. back of remote Plug in the TV. Do not plug it into a switched outlet. Your Concierge TV is designed to oper- ate on household current, 120-volt 60 Hertz AC. Do not attempt to operate it on DC Current. -
Page 8: Antenna With Vcr
Go to page 11 to Auto Program the Concierge TV. Remember, when screwing RF cables onto jacks, clockwise tightens, and counterclockwise loosens. No A/V cables are included with the Zenith Concierge TV. Model H2539Y does not have the MPI card. P A G E 8... -
Page 9: Cable Service With Vcr
AA batteries. back of remote Plug in the TV. Do not plug it into a switched outlet. The Concierge TV is designed to operate on standard current, 120-volt 60 Hertz AC. Do not attempt to operate it on DC Current. -
Page 10: External Speaker
Locate the Audio In jack on the back of the speaker. Connect a standard audio cable from the Matrix Out jack on the TV, to the Audio In jack on the external speaker. P A G E 1 0 TV back... -
Page 11: Auto Program
Press a Right or Left ADJ arrow to begin the Channel Search. Press ENTER when finished. Note: Auto Program finds channels being received by the TV tuner. Cable will not work unless the lodge provides a cable service. (If the Auto Program line appears in red, then it did not pass one of the internal tests. -
Page 12: Front Panel Controls
Front Panel Controls Using the front control panel to access the menus. Press ON/OFF to turn on your Concierge TV. To cycle through available channels, press the CHAN- NEL UP/DOWN button. To adjust the volume control, press the VOLUME UP/DOWN button. -
Page 13: Guest Remote Key Functions
Displays the available TV channels, including access to guest’s Parental Control menu. Allows guest to select the Aux Channel. (Use the Audio/Video jacks on the back of the TV as the source of the picture and sound.) remote control part number... -
Page 14: Installer's Remote Key Functions
Gives installer access to the guest’s menus. Displays the available TV channels and hotel guest’s Parental Control menu. Allows user to select the Aux Channel. (Use the Audio/Video jacks on the back of the TV as the source of the picture and sound.) 206-3490-O... -
Page 15: On-Screen Menus Overview
Channel Labels Labels your channels with their network names (ABC, CBS, HBO, etc.). Timer Setup Programs a time for the TV to turn itself on or off, or to turn itself off after a certain amount of time. Clock Set Sets the time. -
Page 16: Setting Add/Delete/Blank
Channel Preview list. Notes: Adding VCR 3 and/or VCR 4 as available channels forces TV Channel 3 and/or 4 to be retained, when run- ning Auto Program, even though the equipment connect- ed to the Antenna/Cable (RF) jack (like a cable convert- er and/or VCR) may be turned off. -
Page 17: Channel Labels
Setting Up Channel Labels Customizing the channel selection names. Overview Channel Labels help the user identify the channel or network being viewed. In the Setup menu with the CH LABELS option highlighted, use the Adjust Left/Right arrows to scroll through the available channel labels, such as, A & E, AMC, ESPN, HBO, etc. -
Page 18: Timer Setup
Timer Set Up Set times to turn the Concierge TV on or off automatically. Be sure to set the Clock first, see next page. With Timer Setup highlighted as shown above, press a Left/Right ADJ arrow to display the Timer setup menu. -
Page 19: Clock Set
6:30 on the clock. Use the TIMER key to specify AM or PM. Press ENTER to start the clock and return to TV viewing. The Sleep Timer may be instantly set by pressing the TIMER key repeatedly. when you have made your selection, press ENTER to set the timer and return to TV viewing. -
Page 20: Captions Caption/Text
Mini glossary CAPTIONS The term for the words that scroll across the bottom of your TV screen; usually the audio portion of the program provided for the hearing impaired. -
Page 21: Language
Use the SELECT key on the remote control, to highlight Language on your screen. Press a Right/Left ADJ arrow to choose one of the fol- lowing options: English, Spanish or French. Press ENTER to return to TV viewing. 206-3490-O ENGLISH ENTER... -
Page 22: Video Menu
Using a Right/Left ADJ arrow, change the contrast level to your preference. Press ENTER, or MENU one more time to return to TV view- ing, or repeat from step two to set the other menu options. Use SELECT to choose Picture Preference on your screen. -
Page 23: Installer Parental Control Menu
Overview To insure complete coverage for all TV programs, (movies and regular TV shows) choose a rating for MPAA, from the selec- tions below AND choose ratings from the TV Parental Guidelines Rating System on the next page, using the Age Block option for General Audiences and for Children. -
Page 24: Installer Parental Control Menu
After you have selected and adjusted the parental control menu options to your preferences: - Set the number of hours Advanced TV Control will be on. - Set a 4-number password. - Set the Lock On/Off option to either on or off. -
Page 25: Other Menus And On-Screen Displays
- - - - - - - - TO SELECT, ENTER TO QUI FOR PARENTAL CONTROL Ch Preview Menu Press CH PREV. Displays list of the available TV Channels, Guest Parental Control menu and Video Channel access. P A G E 2 5... -
Page 26: Managing The Channel Banks
Managing the Channel Banks The TV has four channel banks, where the administrator or installer can store groups of TV channels. PLANNING THE CHANNEL BANKS Generally, TV channels are grouped into “program pack- ages” with terms that are proposed to the end user. The user then opts for a package. - Page 27 Managing the Channel Banks Examples of typical channel banks charts. Figure 1. Typical channel banks after running Auto Program B Purpose A = Active - - Channel was found during AUTO PROGRAM Figure 2. Typical channel banks after running Auto Program, and customizing with Add/Del/Blnk B Purpose 1 Basic BC A...
- Page 28 Managing the Channel Banks PLAN YOUR CHANNEL BANKS BY FILLING IN THESE CHARTS (or use photocopies). B Purpose B Purpose 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 B Purpose 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 B Purpose...
-
Page 29: Installers Menus
Installer’s Menus Use the Installer’s Menus to make adjustments. Accessing the Installer’s Menu Installer’s menus can be accessed by using the installer’s remote control. Just press and hold MENU (about 8 seconds) until the display changes, then press 9, 8, 7, 6, then ENTER. To exit the Installer’s Menu, press ENTER again. -
Page 30: Installer Menus
The range is 0 to 63, with 63 as the default which gives the patient the full range of volume control. Change values with ADJUST keys. It may be best to set the same value on every TV. NOTE: The maximum volume level cannot have a value setting lower than the MIN VOLUME level (described above). - Page 31 Generally, this feature is used in connection with START CHAN/VOL (line 11) where the start channel may, for example, be set to 3 or 4. If the start channel is 3 then the TV will remain on channel 3. NOTE: When channel lock is active AUTO PROGRAM and CH.
-
Page 32: Lt1500 Quickset Clone Programmer
If you have previously stored a TV setup in a particular clone memory, it may be changed if desired by overwriting it with a new setup. There is no need for a separate memory clear operation. -
Page 33: Clone Selection Menu Choices
Item 4: Set TV Clock From Clone To set the real time clock in the TV, press (4), then press ON/OFF, POWER, or ENTER to copy the current clone time to the TV clock. Alternatively, use the TV front panel CHANNEL UP or CHANNEL DOWN keys to highlight your choice, then press ON/OFF, POWER, or ENTER to activate. -
Page 34: Operation Notes
Alternatively, use the TV front panel CHANNEL UP or CHANNEL DOWN keys to highlight your choice, then press ON/OFF, POWER, or ENTER to begin. The TV screen will display the items in the installer menu setups for you to observe. Use this function to quickly check the contents of a particular clone memory for the correct setup. -
Page 35: Guest Operation Section (Copy For Guest Usage) Guest Remote Control Key Functions
Displays the available TV channels and gives hotel guest access to the Parental Control menu. Allows guest to select the Video Channel. (Use the Audio/Video jacks on the back of the TV as the source of the picture and sound.) remote control part number SC652... -
Page 36: Guest Parental Control Menu
NC-17 Restricted Viewing Hard Core Films Note: Zenith Electronics Corporation is not liable for any program content that appears when using this rating system; as always, user discretion is advised. P A G E 3 6 When the Aux imput is set to block, your TV will block all programming you have set for cable or over-air broadcasts. -
Page 37: Parental Control Menu
After you have selected and adjusted the parental control menu options to your preferences: - Set the number of hours Advanced TV Control will be on. - Set a 4-number password. - Set the Lock On/Off option to either on or off. -
Page 38: Guest Menus And On-Screen Displays
- - - - - - - - - - - - TO SELECT, ENTER TO QU FOR PARENTAL CONTROL Ch Preview Menu Press CH PREV. Displays list of the available TV Channels, Guest Parental Control menu and Video Channel access. 206-3490-O... -
Page 39: Maintenance
Maintenance Routine TV cabinet and screen cleaning. Careful and regular cleaning can extend the the useful service life of the TV. Be sure to turn the power off and pull out the plug before you begin any cleaning. Screen Cleaning 1. -
Page 40: Troubleshooting
SOLUTIONS • Check your antenna connection or location • Check your cable input. • Check to see if the TV/.VCR button on your VCR has the TV selected • Check your antenna direction and/or location. • Check your cable input •... -
Page 41: Glossary
The wire that comes from an off-air antenna or cable service provider. The end looks like a hex-shaped nut with a wire sticking through the middle. It screws onto the threaded jack on the back of the TV. 300 TO 75 OHM... -
Page 42: Warranty For Concierge Series Tvs
Read your Operating Guide carefully so that you will understand the operation of your set and how to adjust the customer controls. Carry-In Service Models under 21” diagonal (U.S.A.) screen size must be taken to a Zenith authorized service center for warranty service and must be picked up by the owner.
