Installing The Server In A Rack - Cisco UCS C Series Installing

Installing the Server
Note
Rack Requirements
The rack must be of the following type:
• A standard 19-in. (48.3-cm) wide, four-post EIA rack, with mounting posts that conform to English
• The rack-post holes can be square 0.38-inch (9.6 mm), round 0.28-inch (7.1 mm), #12-24 UNC, or #10-32
• The minimum vertical rack space per server must be one rack unit (RU), equal to 1.75 in. (44.45 mm).
Supported Cisco Slide Rail Kits
The server supports the following rail kit options:
• Cisco part UCSC-RAIL-M6= (ball-bearing slide rail kit for UCS C220 and C240 M6 rack servers)
• Cisco part UCSC-CMA-C220M6= (reversible cable management arm for UCS C220 M6 ball-bearing
Rack Installation Tools Required
The slide rails sold by Cisco Systems for this server do not require tools for installation.
Slide Rail and Cable Management Arm Dimensions
The slide rails for this server have an adjustment range of 24 to 36 inches (610 to 914 mm).
The optional cable management arm (CMA) adds additional length requirements:
• The additional distance from the rear of the server to the rear of the CMA is 5.4 inches (137.4 mm).
• The total length of the server including the CMA is 35.2 inches (894 mm).
Front Bezel
An optional locking front bezel (UCSC-BZL-C220M5) is available to provide additional security by preventing
unauthorized access to the front-loading SFF drives. The same bezel is used for both M5 and M6 versions of
the UCS C220 server.

Installing the Server in a Rack

This section describes how to install the server in a rack using the supported rail kit (UCSC-RAIL-M6) that
is sold by Cisco.
These Cisco UCS servers are designed to boot up within 30 minutes provided the neighboring devices are
fully operational.
universal hole spacing, per section 1 of ANSI/EIA-310-D-1992.
UNC when you use the Cisco-supplied slide rails.
slide rail kit)
Rack Requirements
Installing the Server
5
