DECT Site Planning Kit
(SPK) PRO

Advertisement

Table of Contents
loading

Summary of Contents for Gigaset DECT Site Planning Kit PRO

  • Page 1 DECT Site Planning Kit (SPK) PRO...

  • Page 2: Table Of Contents

    Table of Contents Table of Contents Safety precautions ..............3 Introduction .

  • Page 3: Safety Precautions

    Read the safety precautions and the user guide before use. Comprehensive user guides for all telephones and telephone systems as well as for accessories can be found online at wiki.gigaset.com. We thereby help to save paper while providing fast access to the complete up-to-date documentation at any time.
  • Page 4 (e.g. a pacemaker), please contact the device manufacturer. They will be able to advise you regarding the susceptibility of the device to external sources of high frequency energy (for the specifications of your Gigaset product see "Technical data").

  • Page 5: Introduction

    Detailed information on planning a multicell system and performing measure- ments to find the optimum positions for the base stations can be found online in the "N870 IP PRO - Site Planning and Measurement Guide" at wiki.gigaset.com. First steps Checking the package contents...

  • Page 6: Further Recommended Accessories

    Only use rechargeable batteries ( p. 27) recommended by Gigaset Communications GmbH, i.e., never use conventional (non-rechargeable) batteries, otherwise serious health risks and personal injury cannot be ruled out. For example, the outer casing of the batteries could be damaged or the batteries could explode.

  • Page 7: Setting Up The Measuring Base Station

    First steps Setting up the measuring base station To ensure freedom of movement when measuring and not be dependent on being able to reach a power connection, operate the measuring base station via a powerbank. The case contains a powerbank and a USB-C charger device for this purpose. If you reset the measuring base station to factory settings, you must restore its measuring functionality ( p.
  • Page 8 First steps Power level charging indicator In operation the charging indicator shows the power level, when it is charged it shows its charging status: Push the button to activate/deactivate the power level charging indicator In operation: No LED solid: 1 LED solid: ≤...
  • Page 9 First steps Mounting the powerbank and connecting to the base station Attach the powerbank to the tripod using the powerbank tripod mount Open the flap at the top of the base station Connect the power connector on the base station and the USB-C connector on the powerbank with a charging cable.

  • Page 10: Setting Up The Measuring Handsets

    First steps Setting up the measuring handsets Remove the measuring handsets and accessories from the case. For each handset there is: 1 One charging cradle 2 One USB-A to cradle cable 3 One USB-A power adapter 4 One battery cover 5 One belt clip 6 Four batteries (AAA), of which two are spares...
  • Page 11 First steps Connecting the charging cradle Connect the flat plug of the power cable to the charging cradle Plug the USB connector of the power cable into the USB-A power adapter Connect the power adapter to the mains socket To remove the plug from the charging cradle again: Press the release button and pull out...

  • Page 12: Measurement

    Measurement Measurement You can use the Gigaset DECT SPK PRO as planning tool for a new network or for checking the radio coverage of a base station in an existing network. There are two measurement procedures supported: • Advanced measurement mode This is the default procedure of the DECT Site Planning Kit (SPK) PRO and recommended for the measurement.

  • Page 13: Advanced Measurement Mode

    Measurement Advanced measurement mode To use this measurement procedure, the following requirements apply: • System software of the N870 SPK PRO base station: at least version 2.53.0 • Software of the measuring handsets: at least 12.02 Starting the measurement procedure Dial press the talk key .

  • Page 14: Display In Simple Metering Mode

    Press the Cancel display key Display in simple metering mode In the previous Gigaset Site Planning Kit this metering mode was used to show the current status values of the connection to the base station. In the DECT Site Planning Kit (SPK) PRO this metering mode has been replaced by the advanced measurement mode.
  • Page 15 Measurement Activating/deactivating simple metering mode Press and hold the off key . . . the handset is Service switched off. Press and hold the keys at the Metering Mode same time press and hold the talk key . . . the Measure Time handset is now in service mode.
  • Page 16 Measurement No Intercell HO Allows you to measure a single base station in an installed multicell system during an active call. The measuring handset will not switch to another base station in the multicell system, even if this provides a stronger signal (no handover). The handset does not switch to another base station in the multicell system, if this provides a stronger signal (default).
  • Page 17 Measurement Displaying measurement results in simple metering mode In simple metering mode, the display shows the current status values of the connection to the base station. The values are updated at brief intervals. You can change this measuring interval p. 15). Display in idle mode The display shows the following information in idle status: Values for determining the connection quality:...

  • Page 18: Evaluation Of The Measurement Data

    Evaluation of the measurement data Evaluation of the measurement data Using the advanced measurement procedure the measurement data are stored on the meas- uring base station. For evaluation they can be downloaded and stored in CSV format on your computer. Download measurement data The measurement files can be downloaded via: •...
  • Page 19 Example: Collecting the measurement data for all sites cli@base-dm-7c2f80cfe206:~$ measure-dump The files can be download via: • WinSCP • a Web browser, example: https://<IP address>/pub/measure-dump.tar • other SSH tools . . . Detailed information on the measure-dump CLI procedure can be found at wiki.gigaset.com.

  • Page 20: Check Measurement Data

    Evaluation of the measurement data Check measurement data You need to unzip the tar file two times to have the readable CSV files with the measurement data. Example Downloaded file: base-dm-int-589ec62904f3-measure-dump.tar unzip base-dm-int-589ec62904f3-measure-dump.tar base-dm-int-589ec62904f3-measure-dump/base-dm-int-589ec62904f3-measure-dump unzip base-dm-int-589ec62904f3-measure-dump measurements/<sitename>/ <sitename>_<hs location>_dps.csv <sitename>_<bs location>_<hs location>_measurement.csv CSV files There are two CSV files for each measurement: •...

  • Page 21: Administration And Provisioning

    Administration and provisioning timeslot DECT timeslot frame-quality DECT frame quality 0 - 100% dps.csv The dps.csv file contains information about all base stations seen by the handset. This feature can be used to measure in running installations. RPN 02 RPN 03 hs-position The handset measurement location entered via the handset when starting the measurement log...

  • Page 22: Changing The Antenna Mode

    During an active call, the antenna optimization (diversity) is used. Where automatically the best antenna is selected by the system to offer the best speech quality. This is the default setting for regular base stations of the Gigaset DECT PRO product family, to select best antenna in call state.
  • Page 23 Administration and provisioning Download the SPK_provisioning_template.xml file <?xml version="1.0" encoding="UTF-8"?> <provisioning version="1.1" productID="e2"> <nvm> <param name="DmGlobal.0.SystemRegDomain" value="EUR" /> <oper name="set_uci"> <!-- Change network to Static IP --> <param name="network.lan.proto" value="static" /> <param name="network.lan.ipaddr" value="192.168.143.1" /> <param name="network.lan.netmask" value="255.255.0.0" /> </oper> <!-- Provider settings to make internal calls between the DECT handsets -->...

  • Page 24: Change The Static Ip Address To Your Own Preferred Ip Address

    Administration and provisioning Change the antenna mode to A50 (50% per antenna) by adding the following lines to the provisioning template: <!-- 0x00 //current best antenna-diversity algorithm 0x13 //Dummy-Bearer Algorithm ~50% per antenna --> <param name="DmGlobal.0.DECTAntennaMode" value="0x13" /> Do not change parameters without a reason and pay attention to the syntax. Errors in the provisioning file can render the system unusable.

  • Page 25: Appendix

    Therefore please check all of these files. Data protection We at Gigaset take the protection of our customers’ data very seriously. It is precisely for this reason that we are ensuring all our products feature "Privacy by Design" as standard. All informa- tion we collect is used to make our products as good as possible.

  • Page 26: Environment

    Further information on environmentally friendly products and processes is available on the Internet at www.gigaset.com. Gigaset Communications GmbH is certified pursuant to the international standards ISO 14001 and ISO 9001. ISO 14001 (Environment): Certified since September 2007 by TÜV SÜD Management Service GmbH.

  • Page 27: Contact With Liquid

    Each handset is supplied with four recommended batteries. Operating times/charging times for batteries The operating time of your Gigaset devices depends on the capacity and age of the batteries and the way they are used (all times are maximum times).
  • Page 28 Appendix Power adapter (base station/powerbank) Manufacturer Salom Electric (Xiamen) Co. Ltd. Commercial registration number: 91350200612003878C 31 Building, Huli Industrial District, Xiamen, Fujian 361006, P.R. China Model identifier C793 (USB-C PD) Input voltage 100-240V Input AC frequency 50 / 60 Hz Output voltage 10 V 12 V...
  • Page 29 Appendix Accessories Ordering Gigaset products You can order Gigaset products from your specialist retailer. Case with measuring equipment Part number DECT Site Planning Kit (SPK) PRO S30852-S2737-R13 Spare parts for the DECT Site Planning Kit (SPK) PRO Spare part Part number...

  • Page 30: Index

    Index Index ....13 ......16 Advanced measurement mode Intercell handover .
  • Page 31 Index ......5 Package contents ......3, 28 Power adapter .
  • Page 32 Issued by Gigaset Communications GmbH Frankenstraße 2, D-46395 Bocholt © Gigaset Communications GmbH 2023 Subject to availability. All rights reserved. Rights of modification reserved. wiki.gigaset.com...
