Installation, Service and
Operating Instructions
for use by heating contractor
Vitocal 100-AW AM2V
Models 020028, 0340043 and 051078
Outdoor Air to Water Heat Pump
Indoor Distribution and Control Unit
Heating Capacity: 20.5 to 58 MBH
6 to 17 kW
Cooling Capacity: 1.4 to 4.3 Ton
5 to 15 kW
VITOCAL 100-AW
6221389 - 02 03/2024
viesmann
Product may not be exactly as shown
IMPORTANT
Read and save these instructions
for future reference.
Please file in Service Binder
