Important Safety Information
See the Important Safety and Product Information guide in the device product box for product warnings and
other important information.
To avoid possible personal injury, always wear safety goggles, ear protection, and a dust mask when drilling,
cutting, or sanding.
When drilling or cutting, always check what is on the opposite side of the surface to avoid damaging the vessel.
This transducer adapter box is not intended for use with a Garmin
Garmin differential 8-pin transducer cable. Connect it directly to the 8-pin port on the sonar module.
This adapter box connects a non-differential transducer, such as a Garmin or Airmar
Garmin 8-pin sonar module. To adapt a non-differential transducer for use with a Garmin differential sonar
module, you must cut the connector from your existing non-differential transducer and connect the wires to the
wire block inside this 8-pin adapter box by following these instructions.
Mounting the Transducer Adapter Box
Tools Needed
1
• Drill and 3.2 mm ( / in.) drill bit
8
• #2 Phillips screwdriver
• 3 mm flat screwdriver
• Cable ties (optional)
• Wire cutter
• Wire stripper
13
• 21 mm ( / in.) wrench
16
• 15 mm (or adjustable) wrench (optional)
Mounting Location Considerations
When selecting a mounting location, observe these considerations.
• The adapter cable from the device should reach the transducer connector on the sonar module easily when
the device is mounted. The adapter cable length is 60 cm (24 in.).
• You must not submerge the device in water.
• You must mount the device at least 15.25 cm (6 in.) from a source of electrical interference, such as a motor.
• When a mounting surface is unsuitable for screws, you must secure the device to a structure using cable ties
(not included).
April 2022
8-PIN TRANSDUCER ADAPTER BOX
INSTALLATION INSTRUCTIONS
WARNING
CAUTION
NOTICE
® differential 8-pin transducer. Do not cut a
GUID-DEB323BE-96FF-4D95-9C3E-75BF037B5402 v2
6-pin transducer, to a
™
