SECO-LARM SD-996C-NUHQ Manual

Low-profile door strike with horizontal adjustment
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Low-Profile Door Strike with
Horizontal Adjustment
SD-996C-NUHQ
Installation Manual
The SECO-LARM SD-996C-NUHQ Low-Profile Door Strike with Horizontal Adjustment can be
used with virtually any cylindrical-locking system and can be configured for use in wood or metal
frames. Included are two different ANSI-sized faceplates to match the door frame type. The strike
is easily field-configurable for fail-safe or fail-secure applications. For indoor use only.
 Field selectable for fail-safe or fail-secure
 12/24 VAC/VDC Operating voltage
 Static strength – 1,500-lb (6,673N)
 Dynamic strength – 70ft-lb (98J)
 Includes wiring harness and connectors for either 12VAC/VDC or 24VAC/VDC
 Trim plate included
 Mounting tabs included for mounting to hollow aluminum door
 Includes 2 faceplates for nearly any type of frame:
Metal door frames – SD-996SS-11Q
o
Wood door frames – SD-996SS-31Q
o
 Reversible non-handed design fits either right-hand or left-hand doors
 Low profile: Strike is only 1" (26mm) deep for use with aluminum frames
 Optional lip-extension brackets available:
SD-995C-LE25 1" Lip Extension
o
SD-995C-LE50 2" Lip Extension
o

Advertisement

Table of Contents
loading

Related Manuals for SECO-LARM SD-996C-NUHQ

Summary of Contents for SECO-LARM SD-996C-NUHQ

  • Page 1 SD-996C-NUHQ Installation Manual The SECO-LARM SD-996C-NUHQ Low-Profile Door Strike with Horizontal Adjustment can be used with virtually any cylindrical-locking system and can be configured for use in wood or metal frames. Included are two different ANSI-sized faceplates to match the door frame type. The strike is easily field-configurable for fail-safe or fail-secure applications.

  • Page 2: Table Of Contents

    SECO-LARM Low-Profile Door Strike with Horizontal Adjustment Table of Contents Parts List ............2 Selecting Fail-Secure or Fail-Safe ....5 Specifications ..........2 Sample Installations ........6 Basic Installation ........... 3 Metal Door Frame .......... 6 Measuring Latch Line and Center Line..3 Wood Door Frame ..........

  • Page 3: Basic Installation

    SECO-LARM Low-Profile Door Strike with Horizontal Adjustment Basic Installation 1. Select the type of faceplate that will be used (see Sample Installations, pgs. 6~7). If the door is pre-cut for a strike, skip to step 6. 2. Measure and mark the door latch line and the center line of the door (see Measuring Latch Line and Center Line, pg.

  • Page 4: Mounting The Template

    SECO-LARM Low-Profile Door Strike with Horizontal Adjustment Mounting the Template 1. Measure distance "X" from the side of Fig. 4 the door frame, and distance "Y" from the top of the door frame. Use a pencil to mark the exact spot where the two lines intersect.

  • Page 5: Mounting The Strike Using Mounting Tabs

    SECO-LARM Low-Profile Door Strike with Horizontal Adjustment Mounting the Strike Using Mounting Tabs To mount the strike where the hollow door frame Fig. 7 material is unsuitable for mounting, refer to Fig. 7 as you follow the instructions below. 1. Using the template, punch or drill holes for installation of the mounting tabs.

  • Page 6: Sample Installations

    SECO-LARM Low-Profile Door Strike with Horizontal Adjustment Sample Installations Metal Door Frame For installation to a hollow metal door frame, the short steel faceplate (SD-996SS-11Q) is recommended. " (32mm) " " " " (124mm) (105mm) (86mm) (37mm) " (16mm) NOTE:...

  • Page 7: Wood Door Frame

    SECO-LARM Low-Profile Door Strike with Horizontal Adjustment Sample Installations (Continued) Wood Door Frame For installation to a wooden door frame, the long, steel faceplate (SD-996SS-31Q) is recommended. " (37mm) " " " " (180mm) (86mm) (37mm) (202mm) " (18mm) Measurement Key "...

  • Page 8: Wiring Diagram

    SECO-LARM’s obligation is limited to the repair or replacement of any defective part if the unit is returned, transportation prepaid, to SECO-LARM. This Warranty is void if damage is caused by or attributed to acts of God, physical or electrical misuse or abuse, neglect, repair or alteration, improper or abnormal usage, or faulty installation, or if for any other reason SECO-LARM determines that such equipment is not operating properly as a result of causes other than defects in material and workmanship.
