  • Page 1 Kit Instructions Biometrics Module 5954-K960/K961 Issue A...
  • Page 2 NCR, therefore, reserves the right to change specifications without prior notice. All features, functions, and operations described herein may not be marketed by NCR in all parts of the world. In some instances, photographs are of equipment prototypes. Therefore, before using this document, consult with your NCR representative or NCR office for information that is applicable and current.

  • Page 3: Table Of Contents

    Table of Contents Biometrics Module Introduction Kit Components Installation Procedures Removing the Access Cover Identifying the Screws Removing the Keypad Bezel Installing a Biometrics Module Installing the Access Cover...
  • Page 4 Revision Record Issue Date Remarks Jul 2018 First Issue...

  • Page 5: Biometrics Module

    Biometrics Module Introduction This document provides procedures on how to install the Biometrics module. Kit Components...

  • Page 6: Installation Procedures

    Biometrics Module Installation Procedures Installing the Biometrics module include the following procedures: 1. Remove the Access Cover. 2. Remove the old Keypad Bezel. 3. Install the Biometrics module. 4. Re-install the Access Cover. Removing the Access Cover Remove the Access Cover by gently bumping it in the direction shown below and then remove it from the cabinet.

  • Page 7: Identifying The Screws

    Biometrics Module Identifying the Screws As an aid for disassembling the DynaKey, several of the cabinet screws have been labeled. Use the illustration below along with the following sections to correctly identify the screws that are referenced.

  • Page 8: Removing The Keypad Bezel

    Biometrics Module Removing the Keypad Bezel 1. Disconnect the Keypad Ribbon Harness (2) and the Keylock Harness. 2. Remove the screws (4) labeled Keypad. For more details, refer to Identifying the Screws on the previous page. Note: Secure the screws. They will be used later to install the Biometrics module. 3.

  • Page 9: Installing A Biometrics Module

    Biometrics Module Installing a Biometrics Module 1. Position the Biometrics module on the Front Bezel. 2. Secure the Biometrics module using the screws (4). For more details, refer to Identifying the Screws on page 3. 3. Connect the Keypad Ribbon Harness (2) and the Biometrics Cable.

  • Page 10: Installing The Access Cover

    Biometrics Module Installing the Access Cover Slide the Access Cover into place.
