Benchtop Convection Oven with
Hot Plates
Model: MRBO32BK
INSTRUCTION MANUAL
Read these instructions carefully before
using this appliance for the first time.
STORE THESE INSTRUCTIONS CAREFULLY
For product hints and tips plus more join us at
www.morphyrichards.com.au
facebook.com/MorphyRichardsAUS
instagram.com/morphyrichardsau
Advertisement
Table of Contents
Summary of Contents for Morphy Richards MRBO32BK
- Page 1 Benchtop Convection Oven with Hot Plates Model: MRBO32BK INSTRUCTION MANUAL Read these instructions carefully before using this appliance for the first time. STORE THESE INSTRUCTIONS CAREFULLY For product hints and tips plus more join us at www.morphyrichards.com.au facebook.com/MorphyRichardsAUS instagram.com/morphyrichardsau...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING To reduce the risk of fire, electric shock, injury to persons or damage to property, follow basic precautions including the following: WARNING: Do not touch hot surfaces. • WARNING: Misuse of appliance could cause personal injury. •... - Page 3 IMPORTANT SAFETY INSTRUCTIONS In the absence of supervision, the cleaning and maintenance • work should not be done by a child. Use of accessories not recommended or sold by the original • manufacturer may cause risks of fire, electric shock or personal injury.
- Page 4 IMPORTANT SAFETY INSTRUCTIONS Do not store any items on top of the oven when in use. • Do not cover the top of oven with foil paper to avoid over • heating. Keep the appliance away from flammable materials such as •...
- Page 5 IMPORTANT SAFETY INSTRUCTIONS WARNING: After baking, the baking pan, racks and all cooked • foods are hot. Extreme caution must be used when handling the baking pan and racks. Place the baking pan and racks on a heat-resistant surface after use. Unplug from outlet when not in use and before cleaning.
-
Page 6: Specifications
SPECIFICATIONS Model: MRBO32BK Colour: Black Working Capacity: Temperature Range: 90°C-230°C Rated Power: 2500W Large Hot Plate Power: 1000W Small Hot Plate Power: 750W Rated Voltage: 220-240V~ 50-60Hz Dimensions (W x D x H): 525 x 432 x 358mm Net Weight: 11.1kg... -
Page 7: Control Panel
CONTROL PANEL Dial controls the hot plate functions Illuminates when hot plates are operational Dial controls the oven functions Illuminates when the oven is operational Dial controls the temperature of the oven Dial controls the oven timer and manual oven control... -
Page 8: Before First Use
BEFORE FIRST USE Remove all packaging materials. Remove all stickers and labels from the appliance. Do not remove the rating label on the bottom of the appliance. Clean all parts to remove any dust or manufacturing residue. Thoroughly wash the accessories by hand with warm soapy water and a non-abrasive sponge. -
Page 9: Using The Hot Plates
USING THE HOT PLATES • The oven is equipped with two hot plates. The largest hot plate operates at a maximum power of 1000W and is suitable for larger pans. • The smallest hot plate operates at a maximum power of 750W and is suitable for smaller pans. - Page 10 USING THE OVEN OVEN FUNCTION DIAL • The oven has an upper heating element to be used for warming and grilling food by turning the dial to the icon. The door can remain open when using this function. NOTE: The upper element function is only operated by the timer dial.
-
Page 11: Temperature Dial
USING THE OVEN TEMPERATURE DIAL • The temperature dial controls the oven cavity temperature and can be turned clockwise from 90°C to 230°C. • When warming food with both heating elements on, it is recommended to set the temperature to 90° or 110°C. NOTE: The oven upper element function is only operated by the timer dial. -
Page 12: Oven Timer Operation
USING THE OVEN TIMER DIAL MANUAL OVEN OPERATION • Turn the TIME dial anti-clockwise to ON to operate the oven without using the timer. Turn the dial to OFF when finished cooking. OVEN TIMER OPERATION • Rotate the time dial and the oven indicator lamp will illuminate. •... - Page 13 TIPS FOR YOUR BENCHTOP OVEN Condensation on the glass door may appear occasionally • while baking food, this is normal and will disappear after a while. Constantly check your cooking to avoid burning or to continue • cooking, if required. Keep food 3cm from the upper heating element to get an even •...
-
Page 14: Care And Cleaning
CARE & CLEANING WARNING: Unplug the Benchtop Oven and allow to cool • completely before cleaning. Use a mild detergent to clean all accessories. • Do not wash any accessories in a dishwasher. • Use a soft cloth to clean the inner cavity regularly. •... -
Page 15: Troubleshooting
TROUBLESHOOTING During first use, the Benchtop Oven may emit a slight odour • and smoke. This is normal. If smoking continues, ensure to remove extra fat from food • before cooking. Clean baking pan and inner cavity. If the door is not opening freely, pull the rack out, clean the slot •... - Page 16 Recycling: Do not dispose of electrical appliances as unsorted municipal waste. Use separate collection facilities. Contact your local government for information regarding the collection systems available. If electrical appliances are disposed of in landfills or dumps, hazardous substances can leak into the ground water, polluting the food chain and damaging health and wellbeing.
