Location
Parts No.
Description
No.
D887
23357164
DIODE, D1NL20U
D901
23316231
DIODE, 1SS355
D904
23316231
DIODE, 1SS355
D905
23316231
DIODE, 1SS355
D906
23316231
DIODE, 1SS355
DA60
23316231
DIODE, 1SS355
DB01
23358571
DIODE, LED, BT-H254N-31-SH
DB30
23316231
DIODE, 1SS355
MISCELLANEOUS
B405
23451788
HOLDER, POWER CORD
E912
23848729
WEDGE, YOKE HOLDING, 3 REQUIRED
E962
23929521
PIECE, WASHER T=0.5 ZS15
* F470
23144644
FUSE, CARTRIDGE 5X20, 250V 0.5A
F470A
23165433
FUSE HOLDER, 5.2 SOC
* F801
23144652
FUSE, CARTRIDGE 5X20, 250V 3.15A
F801A
23165433
FUSE HOLDER, 5.2 SOC
G101
24000445
CHIP JUMPER, 1608TYPE
G102
23103279
FILTER, FERRITR CHOKE 3.5X5X2,
TEM2014AO
G104
23103249
CORE, FERRITE BEAD 3.5X4.5, TEM2011AO
G110
23103249
CORE, FERRITE BEAD 3.5X4.5, TEM2011AO
G218
24366392
CARBON FILM, 1/6W 3.9K OHM J
G402
23103249
CORE, FERRITE BEAD 3.5X4.5, TEM2011AO
G902
24000824
CHIP JUMPER, 2125TYPE
G903
24000824
CHIP JUMPER, 2125TYPE
G941
24000445
CHIP JUMPER, 1608TYPE
G942
24000445
CHIP JUMPER, 1608TYPE
G943
24000445
CHIP JUMPER, 1608TYPE
GD433 24000824
CHIP JUMPER, 2125TYPE
GJ03
24000445
CHIP JUMPER, 1608TYPE
GJ06
24000445
CHIP JUMPER, 1608TYPE
GJ10
24000445
CHIP JUMPER, 1608TYPE
GJ11
24000445
CHIP JUMPER, 1608TYPE
GJ12
24000445
CHIP JUMPER, 1608TYPE
GJ15
24000445
CHIP JUMPER, 1608TYPE
GJ16
24000445
CHIP JUMPER, 1608TYPE
GJ17
24000445
CHIP JUMPER, 1608TYPE
GJ21
24000445
CHIP JUMPER, 1608TYPE
GJ22
24000445
CHIP JUMPER, 1608TYPE
GJ23
24000445
CHIP JUMPER, 1608TYPE
GJ25
24000445
CHIP JUMPER, 1608TYPE
GJ27
24000445
CHIP JUMPER, 1608TYPE
GJ30
24000445
CHIP JUMPER, 1608TYPE
GJ100
24000445
CHIP JUMPER, 1608TYPE
GL431 24000445
CHIP JUMPER, 1608TYPE
GL511 23289918
COIL, PEAKING, TRF4100AU
GL512 23103279
FILTER, FERRITR CHOKE 3.5X5X2,
TEM2014AO
GL525 24000445
CHIP JUMPER, 1608TYPE
GL874 23103279
FILTER, FERRITR CHOKE 3.5X5X2,
TEM2014AO
GL881 23248234
COIL, CHOKE, TLN3481AC
GL882 23248234
COIL, CHOKE, TLN3481AC
GL888 23103279
FILTER, FERRITR CHOKE 3.5X5X2,
TEM2014AO
GL890 23103249
CORE, FERRITE BEAD 3.5X4.5, TEM2011AO
GL891 23103249
CORE, FERRITE BEAD 3.5X4.5, TEM2011AO
GL892 23103249
CORE, FERRITE BEAD 3.5X4.5, TEM2011AO
GL893 23103249
CORE, FERRITE BEAD 3.5X4.5, TEM2011AO
GL896 23248234
COIL, CHOKE, TLN3481AC
GL897 23248234
COIL, CHOKE, TLN3481AC
GR01
24011102
CHIP, METAL FILM, 1/20W 1K OHM J
GR02
24011102
CHIP, METAL FILM, 1/20W 1K OHM J
GR03
24011102
CHIP, METAL FILM, 1/20W 1K OHM J
GR160 24011470
CHIP, METAL FILM, 1/20W 47 OHM J
GR303 24321109
OXIDE METAL FILM, 1/2W 1 OHM J
Location
Parts No.
Description
No.
GR884 24322688
OXIDE METAL FILM, 1W 0.68 OHM J
JR001
24000445
CHIP JUMPER, 1608TYPE
JR002
24000445
CHIP JUMPER, 1608TYPE
JR003
24000445
CHIP JUMPER, 1608TYPE
JR004
24000445
CHIP JUMPER, 1608TYPE
JR005
24000824
CHIP JUMPER, 2125TYPE
JR006
24000576
JUMPER CHIP, 3216TYPE
JR007
24000576
JUMPER CHIP, 3216TYPE
JR008
24000576
JUMPER CHIP, 3216TYPE
JR009
24000445
CHIP JUMPER, 1608TYPE
JR010
24000576
JUMPER CHIP, 3216TYPE
KB01
23009490
IC, REMOCON RECEIVER, PIC-TB19
N724
23965900
TAPE, GLASS-CLOTH, W/ADHESIVE W=18
T=0.18
N728
23960101
SILICONE RUBBER, TSE-382 RTV
P661
23023116
PLUG, HEAD PHONE JACK 3.5MM, PJ3-14-7
* P801
23372052
POWER CORD, 250V 2.5A
P802
23368249
POWER CORD, 2P 11.88MM VH-JST
P910
23164725
CONNECTOR, PLUG 2P
PV01
23023036
JACK, PIN 0S4P, MSP-226V22-19 NI
PV02
23023047
JACK, PIN JACK 2P KUN, KM04036C01-01
* S801
23344481
SWITCH, POWER, AAPY2211
SA01
23145227
SWITCH, PUSH, 1C1P
SA02
23145227
SWITCH, PUSH, 1C1P
SA03
23145227
SWITCH, PUSH, 1C1P
SA04
23145227
SWITCH, PUSH, 1C1P
SA05
23145227
SWITCH, PUSH, 1C1P
SA06
23145227
SWITCH, PUSH, 1C1P
* V901A
23903177
SOCKET, CRT ISMM08S-E ICE
V901M 23102909
MAGNET, PURITY-CONVERGENCE,
MAG-1052
W661
23351179
SPEAKER, 60X120 8-OHM 3W, SPK-1422AM
W662
23351179
SPEAKER, 60X120 8-OHM 3W, SPK-1422AM
XA01
23153571
CRYSTAL, 8.000 MHZ
Z101
23303136
CERAMIC TRAP, TCF1097
Z102
23303085
CERAMIC TRAP, TCF1092
Z103
23303271
FILTER, TRAP 4.5MHZ, TCF1138AM
Z130
23303230
FILTER, 38MHZ MULTI, F816KPL
ZC01
23303166
CERAMIC TRAP, 39.5MHZ, TCF1107
ZC02
23303224
CERAMIC TRAP, TCF1120AM
PC BOARD ASSEMBLIES
*
U902A 23761581
MAIN BOARD, PD1544-1
*
U902B 23761582
CRT/D BOARD, PD1544-2
PICTURE TUBE
* V901
23312934
PICTURE TUBE, A34LRQ90X(VW)
TUNER
H001
23321450
TUNER, ASIA HYPER FS D-J, ENV59DA7G3
ACCESSORIES
K902
23306459
REMOCON HAND UNIT IR, CTVPAL,
CT-90119
AT03
23588765
REMOCON PART, BATTERY COVER,
CT-90119
Y101A
23565995
OWNER'S MANUAL, 14S2R
Y120
23943846
BAG, POLY
CABINET PARTS
A201
23532340
COVER, FRONT COVER ASSY
A264
23445741
KNOB, CONTROL KEY
A265
23445743
KNOB, POWER BUTTON
A280
23035412
SCREW, BTB4X12 SZN
* A401
23530569
COVER, BACK COVER PROPER
A511
23035412
SCREW, BTB4X12 SZN
A512
23035412
SCREW, BTB4X12 SZN
