BUILT-IN ELECTRIC
CONVECTION OVEN
Use & Care Guide
For questions about features, operation/performance,
parts, accessories or service, call: 1-800-253-1301
or visit our website at www.whirlpool.com
In Canada call 1-800-807-6777 or visit our website at
www.whirlpoolappliances.ca
Table of Contents ................................................. 2
Models GSC308, YGSC308
8303652
Advertisement
Table of Contents
Related Manuals for Whirlpool GSC308PRS
Summary of Contents for Whirlpool GSC308PRS
- Page 1 CONVECTION OVEN Use & Care Guide For questions about features, operation/performance, parts, accessories or service, call: 1-800-253-1301 or visit our website at www.whirlpool.com In Canada call 1-800-807-6777 or visit our website at www.whirlpoolappliances.ca Table of Contents ... 2 Models GSC308, YGSC308...
-
Page 2: Table Of Contents
OVEN SAFETY ...2 PARTS AND FEATURES...4 ELECTRONIC OVEN CONTROL ...5 Displays ...5 Start ...5 Off/Cancel ...5 Clock ...5 Tones...5 Fahrenheit and Celsius...6 Timer...6 Control Lock...6 Oven Temperature Control ...6 OVEN USE...7 Aluminum Foil...7 Positioning Racks and Bakeware ...7 Bakeware...7 Meat Thermometer...8 Your safety and the safety of others are very important. -
Page 3: Important Safety Instructions
Never Use the Oven for Warming or Heating the Room. Do Not Leave Children Alone – Children should not be left alone or unattended in area where oven is in use. They should never be allowed to sit or stand on any part of the oven. -
Page 4: Parts And Features
This manual covers different models. The oven you have purchased may have some or all of the items listed. The locations and appearances of the features shown here may not match those of your model. A. Upper oven (see separate Use and Care Guide) B. -
Page 5: Electronic Oven Control
If “RETRY” flashes on the display for 1 second, an invalid pad was touched. Retry the entry. When the upper oven is not in use, this display shows the time of day or Timer countdown. Start The Start pad begins any oven function except the Timer. If the Start pad is not pressed within 5 seconds after pressing a pad, “START?”... -
Page 6: Fahrenheit And Celsius
All of the above tones are preset on, but can be turned off. To Turn Off/On: Touch and hold STOP TIME for 5 seconds. A tone will sound, and “Snd oFF” will appear on the lower oven display for 3 seconds. Repeat to change back to “Snd on.”... -
Page 7: Oven Use
Odors and smoke are normal when the oven is used the first few times, or when it is heavily soiled. IMPORTANT: The health of some birds is extremely sensitive to the fumes given off. Exposure to the fumes may result in death to certain birds. -
Page 8: Meat Thermometer
A. Upper oven B. Oven vent C. Lower oven The oven vent should not be blocked or covered since it allows the release of hot air and moisture from the oven. Blocking or covering vents will cause poor air circulation, affecting cooking and cleaning results. -
Page 9: Broiling And Custom Broiling
Broiling Chart. Position food on the grid in the broiler pan, then place it in the center of the oven rack with the longest side parallel to the door. It is not necessary to preheat the oven before putting food in, unless recommended in the recipe. -
Page 10: Convection Baking And Roasting
325°F (163°C). The convection bake range can be set between 170°F and 500°F (77°C and 260°C). 2. Press START. “Lo°” will appear on the lower oven display if the actual oven temperature is under 170°F (77°C). When the actual oven temperature reaches 170°F (77°C), the lower oven display will show the oven temperature increasing in 5°... -
Page 11: Convection Broiling
Broiling” section for general broiling guidelines and rack positioning. Allow the oven to preheat for 5 minutes. Position food on the grid in the broiler pan, then place it in the center of the oven rack with the longest side parallel to the door. Close the door. -
Page 12: Oven Care
The Self-Cleaning cycle uses very high temperatures, burning soil to a powdery ash. The oven is preset for a 3 hour 30 minute clean cycle, but the time can be changed. Suggested clean times are 2 hours 30 minutes for light soil and between 3 hours 30 minutes to 4 hours 30 minutes for average to heavy soil. -
Page 13: General Cleaning
Oven Lights The oven lights are standard 40-watt appliance bulbs. They will come on when the oven door is opened. They will not work during the Self-Cleaning cycle. When the oven door is closed, press OVEN LIGHT to turn them on or off. -
Page 14: Troubleshooting
On some models, is the Sabbath Mode set? See “Sabbath Mode” section. On double oven models, is one oven self-cleaning? When one oven is self-cleaning the other oven cannot be set or turned on. On double oven models, has the correct oven been selected? Choose UPPER OVEN or LOWER OVEN first. -
Page 15: Assistance Or Service
To locate the Whirlpool designated service company in your area, you can also look in your telephone directory Yellow Pages. For further assistance If you need further assistance, you can write to Whirlpool Corporation with any questions or concerns at: Whirlpool Brand Home Appliances Customer eXperience Center... -
Page 16: Warranty
CLEANTOP Whirlpool Corporation warrants that the ceramic glass cooktop will not discolor, the cooktop pattern will not wear off, the rubber seal between the ceramic glass cooktop and porcelain edge will not crack, the ceramic glass cooktop will not crack due to thermal shock and the surface unit elements will not burn out.
