FCC Information and Copyright
This equipment has been tested and found to c omply with the limits of a
C lass B digital device, pursuant to Part 15 of the FCC Rules . T hese limits
are
designed
to
provide
interference in a residential installation. This equipment generates , uses
and can radiate radio frequency energy and, if not ins talled and used in
accordance with the instructions, may c ause harmful interference to radio
communications . There is no guarantee that interference will not occur in
a partic ular installation.
The vendor makes no representations or warranties with respec t to the
contents here of and specially disclaims any implied
merchantability or fitness for any purpose. F urther the vendor reserves
the right to revise this publication and to make changes to the c ontents
here of without obligation to notif y any party beforehand.
Duplication of this publication, in part or in whole, is not allowed without
firs t obtaining the vendor's approval in writing.
The c ontent of this user's manual is subject to be changed without notice
and we w ill not be responsible for any mistakes found in this us er's
manual. A ll the brand and product names are trademarks of their
respective c ompanies .
P
4
T
P
E
P
r
o
P
4
T
P
E
P
r
o
P
4
T
P
E
P
r
o
reasonable protection
i
agains t
harmful
of
warranties

Advertisement

Table of Contents
loading

Summary of Contents for Biostar P4TPE Pro

  • Page 1 FCC Information and Copyright This equipment has been tested and found to c omply with the limits of a C lass B digital device, pursuant to Part 15 of the FCC Rules . T hese limits designed provide reasonable protection agains t harmful interference in a residential installation.
  • Page 2: Table Of Contents

    LAYOUT OF P4TPE PRO (FOR VERS ION 7.0 ONLY)...... 1 LAYOUT OF P4TPE PRO (FOR VERS IONS ABOVE 7.2 ONL Y)..2 P4TPE PRO SYS TEM S TRUCTURE ............ 3 ENGLIS H....................4 P4TPE Pro Features ...................4 Package contents..................5 How to set up Jumper.................6 CPU Installation..................6...
  • Page 3: Layout Of P4Tpe Pro (For Version 7.0 Only)

    Layout of P4TPE Pro (for version 7.0 only)
  • Page 4: Layout Of P4Tpe Pro (For Versions Above 7.2 Only)

    Layout of P4TPE Pro (for versions above 7.2 only)
  • Page 5: P4Tpe Pro System Structure

    P4TPE Pro System Structure...
  • Page 6: English

    English P4TPE Pro Features A. Hardware Prov ides Socket 478. ® ® Supports Intel Pentium 4 processor up to 3.06GHz. ® ® Supports Intel Pentium 4 478 Presco tt CPU. ( f or v ersion 7.1 and abov e only ) Supports Hy per-Threading Technology.
  • Page 7: Package Contents

    Supports stereo microphone. Supports 6 channel s . Supports S /PDIF I/O function: Output: 96/ 48 kHz with 24/ 20/ 16 bits. (op tional) Input: 48/ 44.1/ 32/ kHz with 20/ 16 bits. (for version 7.0 only ) S/PDIF In is featured with interrupt, auto-lock, anti-noise, and anti-distortion f unctionalities support.
  • Page 8: How To Set Up Jumper

    User’s Manual X 1 Fully Setup Driv er CD X 1 USB 2.0 Cable X 1 (optional) S/PDIF Ou t/ In Cable X 1 (optional) Rear I/O Panel f or ATX Case X 1 How to set up Jumper The illustration shows how to set up a jumper. When the Jumper cap is placed on pins, the jumper is “close”.
  • Page 9: Ddr Dimm Modules: Ddr1, Ddr2

    CPU Fan Headers: JCFAN1 Assignment Ground JCFAN1 +12V FAN RPM rate Sense S ystem Fan Headers: JSFAN1 Assignment Ground JSFAN1 +12V FAN RPM rate Sense DDR DIMM Modules: DDR1, DDR2 DRAM Access Time : 2.5V Unbuffered DDR 200/266 Mhz Ty pe required.
  • Page 10: Jumpers, Headers, Connectors & Slots

    Jumpers, Headers, Connectors & Slots Floppy Disk Connector: FDD1 The motherboard provides a standard f loppy disk connector tha t supports 360K, 720K, 1.2M, 1.44M and 2.88M flopp y disk types. This connector supports the prov ided f loppy drive ribbon cables. Hard Disk Connectors: IDE1/ IDE2 The motherboard has a 32-bit Enhanced PCI IDE Controller that provides PIO Mode 0~4, Bus Master, and Ultra DMA 33/ 66/ 100 f un ctionality.
  • Page 11 Front Panel Connector: JPANEL1 P WR_LED S LP ON/ OF F JPANEL1 (+) (-) S PK HLED R ST Assignment Function Assignment Function Speaker Sleep Control Sleep Connector Ground Button Speaker Power LED (+) POWER HDD LED (+) Hard Drive Power LED (+) HDD LED (-) Power LED (-)
  • Page 12 Case Open Connector: JCL1 Assignment Case Open Signal JCL1 Ground CD-ROM Audio-In Header: JCDIN1 Assignment Left Channel Input Ground Ground JCDIN1 Right Channel Input Front Panel Audio Header: JAUDIO1 J AUDIO1 Assignment Assignment Mic In/ Center Ground Mic Power/ Bass Audio Power Right Line Out/ Speaker Right Line Out/ Speaker...
  • Page 13 Auxiliary Audio-In Connector: JAUX1 (o ptional for versions above 7.2 only) Assignment Left channel AUX _IN CD_Ground J AUX1 CD_Ground Righ channel AUX _IN Front USB Header: JUSB3/ (JUS B4=> optional) Assignment Assignment USBN- USBN- USBP+ USBP+ JUSB3/ JUSB4 Ground Ground Consumer Infrared Header: J_CIR (optional for versions above 7.2 only)
  • Page 14 Back Panel Connectors (optional) Line In Parallel Port (optional) Speaker Out MIC In PS/2 COM1 Mouse PS/2 Keyboard...
  • Page 15: Français

    Français Caractéristiques de P4TPE Pro A. Matériel Processeur Socket 478. ® ® Supporte le processeur Intel Pentium 4 jusqu’à 3.06GHz. ® ® Supporte le processeur Intel Pentium 4 Prescott. (seulement pour version 7.1 and abov e only) Supporte la technologie Hyper-Threading.
  • Page 16 ® Répond aux exigen ces de Microsoft PC2001. Supporte 6 canaux. Supporte le microphone stéréo. Gestion d’alimentation avancée et capacités d’économie d’énergie. Fonction S/PDIF En trée/ Sortie: Sortie : 96/ 48 kHz avec 24/ 20/ 16 bits Entrée: 48/ 44,1 kHz avec 20/ 16 bits (seulement pour version au-dessous de v ersion 1.2) Entrée S/PDIF est dotée du support des f onctionnalités d’interruption, auto-verrouillage, anti-bruit, et anti-distorsion.
  • Page 17: Warpspeeder

    WarpSpeeder Introduction [ WarpSpeeder™ ], a new powerf ul control utility, f eatures three user- f riendly functions including Ov erclock Manager, Ov ervoltage Manager, and Hardware Monitor. With the Ov erclock Manager, users can easily adjust the frequency they prefer or they can get the best CPU perf ormance with just one click.
  • Page 18: Installation

    Installation Execute the setup execution f ile, and then the following dialog will pop up. Please click “Ne xt” button and f ollow the de fault procedure to install. When y ou see the f ollowing dialog in setup procedure, it means setup is completed.
  • Page 19: Usage

    Usage The following figures are just only for reference, the screen printed in this user manual will change according to your motherboard on hand. [WarpSpeeder™] includes 1 tray icon and 5 panels: Tray Icon: Whenev er the Tra y Icon utility is launched, it will displa y a little tray icon on the righ t side of Windows Taskbar .
  • Page 20 This utility is responsible f or conveniently invoking [WarpSpeeder™] Utility. Y ou can use the mouse by clicking the left button in order to inv oke [WarpSpeeder™] directly from the little tray icon or you can right-click the little tray icon to pop up a popup menu as following f igure.
  • Page 21 Voltage Panel Click the Voltage button in Main Panel, the button will be highlighted and the Voltage Panel will slide ou t to up as the f ollowing figure. In this panel, you can decide to increase CP U core voltage and Memory voltage or not. The def ault setting is “No”...
  • Page 22 Overclock Panel Click the Ov erclock button in Main Panel, the button will be highlighted and the O verclock Panel will slide ou t to left as the f ollowing figure.
  • Page 23 Overclock Panel contains the these features: “–3MHz button”, “-1MHz button”, “+1MHz button”, and “+3MHz button”: provide user the ability to do real-time overclock adjustment. Warning: Manually overclock is potentially dangerous, especially w hen the overclocking percentage is over 110 %. We strongly recommend you verify every speed you overclock by click the Verify button.
  • Page 24 “Auto-ov erclock button”: User can click this button and [ WarpSpeeder™ ] will set the best and stable performance and frequency automatically. [ WarpSpeeder™ ] utility will execute a series of testing until system f ail. Then system will do f ail-saf e reboot by using Watchdog f unction.
  • Page 25 Abou t Panel Click the About button in Main Panel, the bu tton will be highlighted and the About Panel will slide out to up as the following f igure. In this panel, you can get model name and detail inf ormation in hints of all the chipset that are related to overclocking.
  • Page 26 Note: Because the overclock, overvoltage, and hardware monitor features are controlled by several separate chipset, [ WarpSpeeder™ ] divide these features to separate panels. If one chipset is not on board, the correlative button in Main panel will be disabled, but will not interfere other panels’ functions.
  • Page 27: Trouble Shooting

    Trouble Shooting PROBABLE SOLUTION No power to the system at all Power light don’t * Make sure power cable is securely plugged in illuminate, fan inside power supply does not turn * Replace cable on. Indicator light on keyboard does not turn on * Contact techn ical support PROBABLE SOLUTION...
  • Page 28 Dépannage PROBLÈME SOLUTION Pas d'alimentation au système. Les v oyants * Assurez-vous que le câble d'alimentation es lumineux ne s'allument pas, le ventilateur à bien branché l'intérieur du bloc d'alimentation ne se met pas * Remplacez le câble en marche. Le voy ant du clavier ne s'allume pas * Contactez le service d'ass istance technique.
  • Page 29 1/02/2004...
  • Page 30 P4TPE Pro BIOS Setup BIOS Setup..................1 1 Main Menu..................... 3 2 Standard CMOS Features ................6 3 Advanced BIOS Features................9 4 Advanced Chipset Features................12 5 Integrated Peripherals .................. 15 6 Power Management Setup ................19 7 PnP/PCI Configurations ................22 8 PC Health Status ..................
  • Page 31: Bios Setup

    P4TPE Pro BIOS Setup BIOS Setup Introduction This manual discussed Award™ Setup program built into the ROM BIOS. The Setup program allows users to modify the basic system configuration. This special information is then stored in battery-backed RAM so that it retains the Setup information when the power is turned off.
  • Page 32 P4TPE Pro BIOS Setup PCI Bus Support This AWARD BIOS also supports Version 2.1 of the Intel PCI (Peripheral Component Interconnect) local bus specification. DRAM Support DDR DRAM (Double Data Rate Synchronous DRAM) are supported. Supported CPUs ® This AWARD BIOS supports the Intel Pentium 4 CPU.
  • Page 33: Main Menu

    P4TPE Pro BIOS Setup 1 Main Menu Once you enter Award BIOS™ CMOS Setup Utility, the Main Menu will appear on the screen. The Main Menu allows you to select from several setup functions. Use the arrow keys to select among the items and press <Enter> to accept and enter the sub-menu.
  • Page 34 P4TPE Pro BIOS Setup Integrated Peripherals This submenu allows you to configure certain IDE hard drive options and Programmed Input/ Output features. Power Management Setup This submenu allows you to configure the power management features. PnP/PCI Configurations This submenu allows you to configure certain “Plug and Play” and PCI options.
  • Page 35 P4TPE Pro BIOS Setup Save & Exit Setup Save all configuration changes to CMOS(memory) and exit setup. Confirmation message will be displayed before proceeding. Exit Without Saving Abandon all changes made during the current session and exit setup. Confirmation message will be displayed before proceeding.
  • Page 36: Standard Cmos Features

    P4TPE Pro BIOS Setup 2 Standard CMOS Features The items in Standard CMOS Setup Menu are divided into 10 categories. Each category includes no, one or more than one setup items. Use the arrow keys to highlight the item and then use the<PgUp>...
  • Page 37 P4TPE Pro BIOS Setup Main Menu Selections This table shows the selections that you can make on the Main Menu. Item Options Description Date mm : dd : yy Set the system date. Note that the ‘Day’ automatically changes when you set the date.
  • Page 38 P4TPE Pro BIOS Setup Item Options Description Halt On All Errors Select the situation in which No Errors you want the BIOS to stop All, but Keyboard the POST process and All, but Diskette notify you. All, but Disk/ Key...
  • Page 39: Advanced Bios Features

    P4TPE Pro BIOS Setup 3 Advanced BIOS Features Figure 3. Advanced BIOS Setup Virus Warning This option allows you to choose the Virus Warning feature that is used to protect the IDE Hard Disk boot sector. If this function is enabled and an attempt is made to write to the boot sector, BIOS will display a warning message on the screen and sound an alarm beep.
  • Page 40 P4TPE Pro BIOS Setup On (default) Numpad is number keys. Numpad is arrow keys. Gate A20 Option Select if chipset or keyboard controller should control Gate A20. Normal A pin in the keyboard controller controls Gate A20. Fast (default) Lets chipset control Gate A20.
  • Page 41 P4TPE Pro BIOS Setup Summary Screen Show This item allows you to enable/disable the summary screen. Summary screen means system configuration and PCI device listing. The choices: Enabled, Disabled (default). Cache Setup CPU L1&L2 Cache Depending on the CPU/chipset in use, you may be able to increase memory access time with this option.
  • Page 42: Advanced Chipset Features

    P4TPE Pro BIOS Setup 4 Advanced Chipset Features This submenu allows you to configure the specific features of the chipset installed on your system. This chipset manage bus speeds and access to system memory resources, such as DRAM and external cache.
  • Page 43 P4TPE Pro BIOS Setup DRAM RAS# to CAS# Delay This field let you insert a timing delay between the CAS and RAS strobe signals, used when DRAM is written to, read from, or refreshed. Fast gives faster performance; and slow gives more stable performance.
  • Page 44 P4TPE Pro BIOS Setup of system memory usually2 discussed their memory requirements. The Choices: Disabled (default), Enabled. Delayed Transaction The chipset has an embedded 32-bit posted write buffer to support delay transactions cycles. Select Enabled to support compliance with PCI specification version 2.1.
  • Page 45: Integrated Peripherals

    P4TPE Pro BIOS Setup 5 Integrated Peripherals Figure 5. Integrated Peripherals On-Chip IDE Control On-Chip Primary / Secondary PCI IDE The integrated peripheral controller contains an IDE interface with support for two IDE channels. Select Enabled to activate each channel separately.
  • Page 46 P4TPE Pro BIOS Setup On-Chip PCI Device AC97 Audio/ Modem This item allows you to decide to enable/ disable to support AC97 Audio/Modem. The Choices: Auto (default), Disabled. Onboard LAN Boot ROM Decide whether to invoke the boot ROM of the onboard LAN chip.
  • Page 47 P4TPE Pro BIOS Setup board and you wish to use it. If install and FDC or the system has no floppy drive, select Disabled in this field. The Choices: Enabled (default), Disabled. Onboard Serial Port 1 Select an address and corresponding interrupt for the first and second serial ports.
  • Page 48 P4TPE Pro BIOS Setup Midi Port Address Midi Port Base I/O Address. The Choices: 330 (default), 300, Disabled. Midi Port IRQ This determines the IRQ in which the Midi Port can use. The Choices: 10 (default), 5.
  • Page 49: Power Management Setup

    P4TPE Pro BIOS Setup 6 Power Management Setup The Power Management Setup Menu allows you to configure your system to utilize energy conservation and power up/power down features. Figure 6. Power Management Setup ACPI Function This item displays the status of the Advanced Configuration and Power Management (ACPI).
  • Page 50 P4TPE Pro BIOS Setup Max Saving Maximum power management only available for sl CPU’s. Doze Mode = 1 min Standby Mode = 1 min. Suspend Mode = 1 min. HDD Power Down = 1 min. (default) User Defined Allow you to set each mode individually.
  • Page 51 P4TPE Pro BIOS Setup Suspend Mode When enabled and after the set time of system inactivity, all devices except the CPU will be shut off. The Choices: Disabled (default), 1Min, 2Min, 4Min, 8Min, 12Min, 20Min, 30Min, 40Min, 1Hour. HDD Power Down When enabled and after the set time of system inactivity , the hard disk drive will be powered down while all other devices remain active.
  • Page 52: Pnp/Pci Configurations

    P4TPE Pro BIOS Setup 7 PnP/PCI Configurations This section describes configuring the PCI bus system. PCI, or Personal Computer Interconnect, is a system, which allows I/O devices to operate at speeds nearing the speed of the CPU itself uses when communicating with its own special components. This section covers some very technical items and it is strongly recommended that only experienced users should make any changes to the default settings.
  • Page 53 P4TPE Pro BIOS Setup non-PnP ISA add-on cards. PCI / ISA PnP signifies that a resource is assigned to the PCI Bus or provides for ISA PnP add-on cards and peripherals. The Choices: Disabled (default), Enabled. Resources Controlled By By Choosing “Auto(ESCD)” (default), the system BIOS will detect the system resources and automatically assign the relative IRQ and DMA channel for each peripheral.By...
  • Page 54: Pc Health Status

    P4TPE Pro BIOS Setup 8 PC Health Status Figure 8. PC Health Status Shutdown Temperature This item allows you to set up the CPU shutdown Temperature. This item is only effective under Windows 98 ACPI mode. The Choices: 60 C/140...
  • Page 55 P4TPE Pro BIOS Setup Show H/W Monitor in POST If you computer contain a monitoring system, it will show PC health status during POST stage. The item offers several delay time to select you want. The Choices: Enabled (default), Disabled .
  • Page 56: Frequency Control

    P4TPE Pro BIOS Setup 9 Frequency Control Figure 9. Frequency Control CPU Clock Ratio This item allows you to select the CPU Ratio. CPU Voltage This item allows you to select CPU Voltage Regulator. The Choices: Default (default), +1.7%, +3.45%, +5.1%.
