Wasp WPA1200 Quick Start Manual

Caution: When the main battery is removed, the backup
battery retains RAM data in memory for 2 hours, please
charge the battery for the period to avoid the data loss in RAM
memory.
5. Using the SD/MMC Memory Card
a. Remove the two
screws from the SD
compartment cover
and remove the cover.
b. Insert the SD card with
the notched corner as
shown by the icon on
the case.
c. Push the card into the slot until you hear an
audible system sound; this will signal that the
card is already properly seated within the slot
6. Keypads and Function Buttons
When the Function button is pressed, an icon
appears in the operating system.
Function Activated Icon
Power Button
Function Keys
Tab, Open Windows
#1, Left Soft
#7, pqrs, Brightness
#2, abc, Up
#8, tuv, Down
#3, def, Right Soft
Enter key, OK
#9, wxzy, Brightness
Backspace, Escape
Alpha
#4, ghi, Left
Asterisk, Illuminate
#5, jkl Number 0, Spaces
Period, Pounds
#6, mno, Right
WPA1200

Quick Start

Guide
© 2007 Wasp Technologies
