Vulcan-Hart ScaleBlocker SPS600V Specifications

SPECIFICATIONS:
Water filter system, Vulcan-Hart Model No. SPS___V. Single
cartridge design. Patented technology reduces limescale with-
out chemicals or additives. Reduces the need for deliming.
Mounting bracket with clear filter housing and red cap. Shutoff
valve and gauge. Incoming water parameters are pH 6 - 9,
Alkalinity ppm 80 - 100, Chlorine ppm 0 - 4, Hardness ppm
3
0 - 300. ⁄ NPTF inlet and outlet.
4
Exterior dimensions:
SPS600V: 14"w x 10"d x 18
SPS620V: 14"w x 10"d x 28"h.
NSF tested and certified.
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. 1-800-814-2028
F-32428 (6-04)
1 / "h.
2
502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602
Item # __________________________
™
ScaleBlocker
WATER FILTER SYSTEM
SPS600V
SPS620V
STANDARD FEATURES
Single cartridge design.
Patented technology reduces limescale with-out chemicals
or additives.
Reduces the need for deliming.
Mounting bracket with clear filter housing and red cap.
Shut off valve and pressure gauge.
Incoming water parameter:
pH 6-9
Alkalinity ppm 80 - 100
Chlorine ppm 0 - 4
Hardness ppm 0 - 300
3 ⁄ NPTF inlet and outlet.
4
Shut off valve with cold water
for unfiltered connection.
Water pressure gauge.
Water flow meter with reminder setting.
C.S.I. Section 11420
1 / " compression connection
4
