Vulcan-Hart 1T4024G Specifications

Model 1T4024G Shown
SPECIFICATIONS:
One 40 quart 2 / jacketed tilting steam kettle mounted on
3
a 24" wide gas boiler base, Vulcan-Hart Model No. 1T4024G.
Steam jacketed kettle mounted on 28" high base cabinet with
stainless steel frame, front full height door, stainless steel side
and aluminized rear panel with 6" adjustable legs with flanged
feet for anchoring. Fully welded hemispheric bottom kettle
with type 304 stainless steel jacket and type 316 stainless
steel liner. Jacket tested to 50 psi (3.4 kg/cm
valve on right trunnion leg. 12" single temperature deck mounted
faucet. 200,000 BTU/hr. gas steam boiler. Requires 120 volt,
60 Hz, 1 phase control circuit, 3 amp.
Exterior dimensions:
Cabinet: 24"w x 35.4"d x 28"h on 6" adjustable legs. Overall
height to the lip of the kettle - 47
- 58 5 / ".
8
SPECIFY TYPE OF GAS WHEN ORDERING.
SPECIFY ALTITUDE WHEN ABOVE 2,000 FT.
CSA design certified. Classified by U L to NSF Std. #4. Meets
ASME code.
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. 1-800-814-2028
F-32383 (2-06)
2
). Steam control
1
/ ", to the top of the flue
2
502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602
Item # __________________________
MODEL 1T4024G
2
40 QUART / JACKETED TILTING
3
KETTLE ON GAS BOILER BASE
STANDARD FEATURES
2 / jacketed tilting steam kettle, 40 quart capacity.
3
Steam jacketed kettle mounted on 28" high base cabinet
with stainless steel frame, front full height door, stainless
steel side and aluminized rear panel with 6" adjustable legs
with flanged feet for anchoring.
Fully welded hemispheric bottom kettle with type 304
stainless steel jacket and type 316 stainless steel liner.
Jacket tested to 50 psi (3.4 kg/cm
Steam control valve on right trunnion leg.
12" single temperature deck mounted faucet.
CSD-1 code compliant boiler.
Electronic ignition.
200,000 BTU/hr. gas steam boiler.
Requires a 120 volt, 60 Hz, 1 phase control circuit, 3 amp.
One year limited parts and labor warranty.
OPTIONS
Correction package.
- Cabinet door with hasp (lock by others).
- Security type tamper resistant fasteners.
Tilting kettle strainer.
12" dual temperature faucet.
Mount and interconnect kettle with boiler base at factory.
Includes steam supply piping. Shipped on one skid.
Second year extended limited parts and labor warranty.
ACCESSORIES
Stainless steel back panel.
Lift-off cover.
Contour measuring strip.
Single perforated stainless steel basket.
Water filter system, SPS620V. Includes second year extended
limited water associated parts and labor warranty.
C.S.I. Section 11420
