Pioneer SX-2300 Service Manual

@) PIONEER'
The future of sound and vision.
Service
ORDER NO.
ARP1477
STEREO RECEIVER
SX=-23500
SsX=-1300
MODEL SX-2300 and SX-1300 HAVE FIVE VERSIONS:
Applicable model!
Type /~sx-2300 | sx-1300_ Power reguirement Destination
AC120V only U.S.A. and Canada
AC110V, 120V-127V, 220V, 240V Kingdom of SaudiArabia and general
(switchable) market
a a SE
fo | 0 |
AC220V, 240V (switchabie) United Kingdom
¢This manual is applicable to the SX-2300/KUC, SD, SX-1300/KUC and SD types.
eFor the SX-2300/SD, SX-1300/KUC and SD types, refer to pages 30-31
*For the other types, refer to additional service manuals.
¢Ce manuel pour le service comprend les explications en frangais de réglage. (p27)
*Este manual de servicio trate del método ajuste escrito en espafiol. (P28)
CONTENTS
1. SAFETY INFORMATION <--eceeereeeeee eee 2 B. PACKING vecceecescceteeceeceeeeeeeeetens eeee sarees 25
2. SPECIFICATIONS <<tcrtccreecteeeee rer eee teen eees 3 D: ADJUSTMENT Qaieitemmcieteagguseutenny 25
3. PANEL FACILITIES «-1-s0-000-eserereeeeereeees 4 EECA CEs wits sndanateehovlarecacealiasteeeed 97
4, EXPLODED VIEWS AND PARTS LIST --: 6 AAUST Esai Aietieeinetens 28
5. SCHEMATIC DIAGRAM «+--+ ++ errs eee 9 10> IC INFORMATION <0:s20ts-¢-s-2e tents veenees 29
6. P.C. BOARDS CONNECTION 11, FOR SX-2300/SD, SX-1300/KUC
DIAGRAM cortccsecsteresesenesresteeessesonseens 13 AND SX-1300/SD MODELS «18-1 3}
7. ELECTRICAL PARTS LIST -----+----+++7+++ 22
PIONEER ELECTRONIC CORPORATION = 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153, Japan
PIONEER ELECTRONICS SERVICE INC. P.O. Box 1760, Long Beach, California 90801 U.S.A.
PIONEER ELECTRONICS OF CANADA, INC. 505 Cochrane Drive, Markham, Ontario L3R 8E3 Canada
PIONEER ELECTRONIC [EUROPE] N.V. Keetberglaan 1, 2740 Beveren, Belgium
PIONEER ELECTRONICS AUSTRALIA PTY. LTD. 178-184 Boundary Road, Braeside, Victoria 3195, Australia TEL: [03] 580-9911
YO © DEC. 1987 Frimted in Japan
