Important Safety Instructions
When using your telephone equipment, basic safety precautions should always be
followed to reduce the risk of fire, electric shock and injury, including the following:
1. Read and understand all instructions.
2. Follow all warnings and instructions marked on the product.
3. Unplug this product from the wall outlet before cleaning. Do not use liquid or aerosol
cleaners. Use a damp cloth for cleaning.
4. Do not use this product near water (for example, near a bath tub, kitchen sink or
swimming pool).
5. Do not place this product on an unstable surface, such as a table, shelf, or stand.
The product may fall, causing serious damage.
6. Slots and openings in the back or bottom of the base unit and handset are provided
for ventilation. To protect them from overheating, these openings must not be
blocked by placing the product on a soft surface such as a bed, sofa or rug. This
product should never be placed near or over a radiator or heat register. This
product should not be placed in any area where proper ventilation is not provided.
7. This product should be operated only from the type of power source indicated on
the marking label. If you are not sure of the type of power supply in your home, consult
your dealer or local power company.
8. Do not allow anything to rest on the power cord. Do not install this product where
the cord may have anyone walking on it.
9. Never push objects of any kind into this product through slots in the base or handset
as they may touch dangerous voltage points or short out parts that could result in
a risk of fire or electric shock. Never spill liquid of any kind on the product.
10. To reduce the risk of electric shock, do not disassemble this product, but take it to
an authorized service facility. Opening or removing parts of the base or handset
other than specified access doors may expose you to dangerous voltages or other
risks. Incorrect reassembling can cause electric shock when the product is
subsequently used.
11. Do not overload wall outlets and extension cords as this can result in the risk of fire
or electric shock.
12. Unplug this product from the wall outlet and refer servicing to an authorized service
facility under the following conditions:
A. When the power supply cord or plug is damaged or frayed.
B. If liquid has been spilled onto the product.
C. If the product has been exposed to rain or water.
D. If the product does not operate normally by following the operating instructions.
Adjust only those controls that are covered by the operating instructions, as
improper adjustment of other controls may result in damage and often requires
extensive work by an authorized technician to restore the product to normal
operation.
E. If the product has been dropped and the base and/or handset has been damaged.
1

Advertisement

Table of Contents
loading

Summary of Contents for VTech i5808

  • Page 1: Introduction

    Important Safety Instructions When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury, including the following: 1. Read and understand all instructions. 2. Follow all warnings and instructions marked on the product.
  • Page 2: Important Safety Instructions

    WARNING: To insure your safety from possible electric shock, only use the en- closed VTech audio patch cable to record custom ring tones. Do NOT leave the audio patch cable attached to the handset while charging in its base.
  • Page 3 Introduction EXPAND YOUR i 5858 or i 5871 SYSTEMS. YOUR BASE WILL WORK WITH UP TO 8 HANDSETS!!! IMPORTANT: The i 5808 is an accessory handset only for use with the i 5858 or i 5871 systems. You must have one of these base units in order to use the i 5808 accessory handset.
  • Page 4: Getting Started

    4. Handset Charger 5. Special Features Guide To purchase replacement batteries, visit us on the web at www.vtechphones.com or call VTech Communications, Inc. at 1-800-595-9511. In Canada, call VTech Telecommunications Canada Ltd. at 1-800-267-7377. NOTE: Use only VTech batteries P/N 89-1324-00-00.
  • Page 5: The Handset Layout

    The Handset Layout 1. Earpiece 2. USB Cable Jack 3. Headset Jack / Audio Patch Cable Jack (2.5mm) 4. On/Flash Key 5. Dialing Keys (0-9, *, #) 6. Speakerphone Key 7. LCD Display 8. Menu/Select Key 9. Softkeys 10. NavKeys (Navigation Keys) 11.
  • Page 6: Setup

    Setup Connecting Power to Handset Charger Because the i 5808 is an accessory handset to the i 5858 or i 5871system, all you need to do is choose the location for your handset charger, and plug in the power supply into an electrical outlet. Installation and Charge of Battery in Handset 1.
  • Page 7 Setup Battery Life A fully charged battery provides an average talk time of about seven hours or standby time of four days. NOTE: Talk time and standby time may vary depending on operating conditions. Battery Indicator Ten minutes before the battery charge level gets too low to operate the handset, an empty battery icon will start flashing, five short tones are generated and a Low Battery message is displayed.
  • Page 8: Registration

    Registration Installation and Registration of Accessory Handset Your i 5808 is an accessory handset ONLY and requires either a i 5858 or i 5871 base unit to operate. Registering the i 5808 handset for the first time After charging the handset will display registration directions, which are as follows: •...
  • Page 9: Basic Operation

    Handset Indicators Handset Icons Icon Description Line In Use Indicator • On steady when an extension handset or parallel set is in use. Hold Indicator • Flashes when a call is on hold. Mute Indicator • Flashes when the handset microphone is muted. Ringer Off Indicator •...
  • Page 10: Additional Information

    5808. For best results, use a VTech 2.5mm headset. To purchase a headset, visit us on the web at www.vtechphones.com or call VTech Customer Service at 1-800-595-9511.
  • Page 11: Maintenance

    Avoid water Your telephone can be damaged if it gets wet. Do not use the Handset outdoors in the rain, or handle it with wet hands. Do not install your Base Unit near a sink, bathtub, or shower.
  • Page 12: In Case Of Difficulty

    In Case Of Difficulty If you have difficulty operating your phone, the suggestions below should solve the problem. If you still have difficulty after trying these suggestions, call VTech Communica- tions at 1-800-595-9511. In Canada, call VTech Telecommunications Canada Ltd. at 1-800-267-7377.
  • Page 13 You hear other calls while using your phone • Disconnect your Base Unit from the telephone jack, and plug in a regular telephone. If you still hear other calls, the problem is probably in your wiring or local service. Call your local telephone company.
  • Page 14: Warranty Statement

    3. Product to the extent that the problem experienced is caused by signal conditions, network reliability or cable or antenna systems; or 4. Product to the extent that the problem is caused by use with non-VTech electrical accessories; or 5. Product whose warranty/quality stickers, Product serial numbers plates or electronic serial numbers have been removed, altered or rendered illegible;...
  • Page 15 • If the Product failure is not covered by this limited warranty, or proof of purchase does not meet the terms of this limited warranty, VTech will notify you and will request that you authorize the cost of repair prior to any further repair activity. You must pay for the cost of repair and return shipping costs for the repair of Products that are not covered by this limited warranty.
  • Page 16: Fcc, Acta And Ic Regulations

    20 cm or more. If you choose to use a clipping device, please make sure to only use the supplied VTech belt clip. FCC and ACTA Information...
  • Page 17 You will be given the opportunity to correct the problem and the telephone company is required to inform you of your right to file a complaint with the FCC. Your telephone company may make changes in its facilities, equipment, operation, or procedures that could affect the proper functioning of this product.
  • Page 18 If you do, please keep three things in mind: a. We recommend that you also write the telephone number on the directory card, so that you can still dial the emergency number manually if the memory dialing feature doesn’t work.
  • Page 19 FCC, ACTA and IC Regulations Users should ensure for their own protection that the electrical ground connections of the power utility, telephone lines and internal metallic water pipe system, if present, are connected together. This precaution may be particularly important in rural areas.
  • Page 20: Technical Specifications

    Technical Specifications FREQUENCY CONTROL Crystal controlled PLL synthesizer TRANSMIT FREQUENCY Base: 5725-5850 MHz Handset: 5725-5850 MHz RECEIVE FREQUENCY 5725-5850 Base: Handset: 5725-5850 MHz CHANNELS 95 Channels SIZE Handset: 190mm x 42mm x 31mm Charger: 87.0mmx90.0mmx 84mm (including antenna) NOMINAL EFFECTIVE RANGE Maximum power allowed by FCC and IC.
  • Page 21 VTECH TELECOMMUNICATIONS LTD. A member of THE VTECH GROUP OF COMPANIES. Distributed in the U.S.A. by VTech Communications Inc., Beaverton, Oregon, 97008 Telecommunications Distributed in Canada by VTech Canada Ltd., 7671 Alderbridge Way, Richmond, B.C. V6X 1Z9. Copyright 2005 for VTECH TELECOMMUNICATIONS LTD.
  • Page 22: Table Of Contents

    Table of Contents Introduction...1 Important Safety Instructions...2 Getting Started...4 Parts Check List...4 The Handset Layout...5 Setup...6 Registration...8 Basic Operation...9 Handset Indicators...9 Additional Information...10 Headset Operation...10 Belt Clip...10 Maintenance...11 In Case Of Difficulty...12 Warranty Statement...14 FCC, ACTA and IC Regulations...16 Technical Specifications...20...
  • Page 23: Need Help

    Congratulations on your purchase of this VTech product NEED HELP? Our representatives are here to help you with any questions concerning the operation of this product, available accessories, or any other related issues. Call Toll Free: 1-800-595-9511 In Canada, Call:...
